Arnott AS-3070 Installation Manual

Remanufactured front left air strut land rover range rover l494
Hide thumbs

Advertisement

Quick Links

Download this manual
Congratulations on your purchase of an Arnott
to offer a high quality product at the industry's most competitive pricing. Thank you for your confidence in us
Proper installation is essential to experience and appreciate the benefits of this system. Please take a moment
to review these installation instructions before you begin to install these components on your vehicle. The
removal and installation of air suspension products should only be performed by a fully qualified, ASE
It is equally important to be aware of all necessary safety measures while installing your new Air Suspension
System. This includes proper lifting and immobilizing of the vehicle and isolation of any stored energy to
WARNING: The air suspension system is under pressure (up to 10 bar, or 150 lbf/in). Verify pressure has been relieved
and disconnect power to the air suspension system prior to disassembly. Do not allow dirt or grease to enter the system.
Always wear standard hand, ear, and eye protection when servicing the air suspension system.
1
AS-3070
ARNOTT REMANUFACTURED
FRONT LEFT AIR STRUT
LAND ROVER RANGE ROVER (L494)
air suspension product. We at Arnott Incorporated are proud
®
and our product.
Certified, professional.
prevent personal injury or property damage.
"Engineered to Ride, Built to Last
3070
AS-
"
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the AS-3070 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arnott AS-3070

Summary of Contents for Arnott AS-3070

  • Page 1 LAND ROVER RANGE ROVER (L494) Congratulations on your purchase of an Arnott air suspension product. We at Arnott Incorporated are proud ® to offer a high quality product at the industry’s most competitive pricing. Thank you for your confidence in us and our product.

  • Page 2: General Information

    3070 ARNOTT REMANUFACTURED FRONT LEFT AIR STRUT LAND ROVER RANGE ROVER (L494) GENERAL INFORMATION: Reading this manual signifies your agreement to the terms of the general release, waiver of liability, and hold harmless agreement. • Not to be stored below 5...

  • Page 3: 5. Remove The Air Line Fitting. To Do So, Spread The Collet Open And The Remaining

    3070 ARNOTT REMANUFACTURED FRONT LEFT AIR STRUT LAND ROVER RANGE ROVER (L494) LOOSEN AND REMOVE THE AIR LINE FROM THE TOP OF THE STRUT. (FIGURES 2, 3) FIGURE 2 FIGURE 3 REMOVE THE AIR LINE FITTING. TO DO SO, SPREAD THE COLLET OPEN AND THE REMAINING FITTING WILL SLIDE OFF OF THE AIR HOSE.
  • Page 4 3070 ARNOTT REMANUFACTURED FRONT LEFT AIR STRUT LAND ROVER RANGE ROVER (L494) FIGURE 7 LOOSEN AND REMOVE THE TOP MOUNTING NUTS. (FIGURES 8, 9) FIGURE 8 FIGURE 9 LOOSEN AND REMOVE THE SENSOR WIRE AND BRAKE LINE BRACKET. (FIGURES 10, 11, 12)
  • Page 5 3070 ARNOTT REMANUFACTURED FRONT LEFT AIR STRUT LAND ROVER RANGE ROVER (L494) FIGURE 12 LOCATE AND REMOVE THE UPPER CONTROL ARM BALL JOINT NUT. SEPERATE THE BALL JOINT FROM THE SPINDLE ASSEMBLY. (FIGURES 13, 14, 15) FIGURE 13 FIGURE 14...
  • Page 6 3070 ARNOTT REMANUFACTURED FRONT LEFT AIR STRUT LAND ROVER RANGE ROVER (L494) LOOSEN AND REMOVE THE LOWER STRUT MOUNTING BOLT. (FIGURE 16) FIGURE 16 REMOVE THE SENSOR WIRE BRACKET AND SEPERATE THE END LINK FROM THE LOWER STRUT CLEVIS. (FIGURES 17, 18, 19)
  • Page 7 3070 ARNOTT REMANUFACTURED FRONT LEFT AIR STRUT LAND ROVER RANGE ROVER (L494) LOOSEN THE STRUT CLEVIS. (FIGURE 20) FIGURE 20 PULL THE SPINDLE ASSEMBLY OUTWARD AND REMOVE THE STRUT. (FIGURES 21, 22) FIGURE 21 FIGURE 22 REMOVAL COMPLETE. AS-3070...
  • Page 8 3070 ARNOTT REMANUFACTURED FRONT LEFT AIR STRUT LAND ROVER RANGE ROVER (L494) AIR STRUT INSTALLATION Tighten all nuts and bolts to manufacturer's specifications during the installation process. Do not remove the air fitting from the air strut. Doing so may cause damage and/or void warranty. Remove the white shipping pin from the new air fitting and insert the air line until fully seated.
  • Page 9 3070 ARNOTT REMANUFACTURED FRONT LEFT AIR STRUT LAND ROVER RANGE ROVER (L494) REINSTALL THE UPPER CONTROL ARM TO THE SPINDLE ASSEMBLY AND TIGHTEN TO MANUFACTURER'S SPECIFICATIONS. (FIGURES 25, 26) FIGURE 25 FIGURE 26 REINSTALL THE SENSOR WIRE BRACKET AND REATTACH THE END LINK TO THE LOWER STRUT CLEVIS.

  • Page 10: Manufacturer's Specifications. (Figures

    3070 ARNOTT REMANUFACTURED FRONT LEFT AIR STRUT LAND ROVER RANGE ROVER (L494) RETIGHTEN THE STRUT CLEVIS TO MANUFACTURER'S SPECIFICATIONS. (FIGURE 30) FIGURE 30 REINSTALL THE SENSOR WIRE AND BRAKE LINE BRACKET. (FIGURES 31, 32) FIGURE 31 FIGURE 32 REINSTALL THE TOP STRUT MOUNTING BOLTS AND TIGHTEN TO MANUFACTURER'S SPECIFICATIONS.
  • Page 11 3070 ARNOTT REMANUFACTURED FRONT LEFT AIR STRUT LAND ROVER RANGE ROVER (L494) REMOVE THE WHITE PLASTIC SHIPPING PIN FROM THE AIR LINE FITTING AND DISCARD. (FIGURE 34) FIGURE 34 INSTALL THE AIR LINE INTO THE AIR LINE FITTING. (FIGURES 35, 36, 37) AS RECEIVED REMOVE &...
  • Page 12 3070 ARNOTT REMANUFACTURED FRONT LEFT AIR STRUT LAND ROVER RANGE ROVER (L494) REINSTALL THE WHEEL. INSTALLATION COMPLETE. Arnott provides the best in replacement suspension parts equipment.
