3.1

Electrical Specifications

Number of Channels: 1
Measurement Range: L610: 32° to 1380°F (0° to 750°C)
Input: L610: J Thermocouple
L620: K Thermocouple
L630: T Thermocouple
Input Connection: M iniature color-coded thermocouple jacks
Resolution: 12 Bit (better than 0.5°C)
Sample Rate: 4096/hr max; decreases by 50% each time memory is full
Data Storage: 16,384 readings
Data Storage Technique: TXR™ Time Extension Recording™
Power: 9V Alkaline NEDA 1604, 6LF22, 6LR61
Battery Life Recording: Up to 1 year of recording @ 77°F (25°C)
Output: RS-232 via DB9 connector (4800 Baud)
Reference condition: 23°C ± 3K, 20 to 70% RH, Frequency 50/60Hz, No AC external mag-
netic field, DC magnetic field ≤ 40A/m, battery voltage 9V ± 10%.
Accuracy: ±0.5% of Reading + 1°C + T/C Accuracy
3.2

Mechanical Specifications

Size: 2-7/8 x 2-5/16 x 1-5/8" (73 x 59 x 41mm)
Weight (with battery): 5 oz (140g)
Mounting: Base plate mounting holes or Velcro
Case Material: Polystyrene UL V0
6
CHAPTER 3

SPECIFICATIONS

L620: -325° to 2280°F (-200° to 1250°C)
L630: -325° to 660°F (-200° to 350°C)
Black - J, Yellow -K, Blue -T
Thermocouple Simple Logger
pads
®
Models L610 / L620 / L630
®
