- Page 1 Notice d’iNstaLLatioN iNstaLLatioN iNstRUctioNs (Etiquette signalétique) (Data label) k 60 d 070 z kit RéGULatioN système poUR pompe à chaLeUR iNveRteR avec chaUFFaGe d’appoiNt éLectRiqUe system coNtRoL kit FoR iNveRteR heat pUmp with eLectRic sUppoRt heateR Mai 2013 10 11 566 - F.GB - 02...
- Page 2 1 - PURPOse - Use • Control kit designed to control heating installations with heat pump and electric support heater for residential purposes within the scope of applications meant for TECHNIBEL. See technical control file enclosed with kit. 2 - PReCAUTIONs...
-
Page 3: Operating Principle
3 - COMPOsITION • The kit includes: - A control box to be installed in the comfort zone (see • Control unit: paragraph 5.1). - Plastic wall-mounted control unit. - An outside temperature sensor unit placed on the facade - Dimensions: height = 128 mm of the building (see paragraph 5.2). - Page 4 5 - INsTAllATION 5.1 - CONTROl UNIT INsTAllATION • As the control unit is equipped with a temperature sensor, it must be installed in a location that is representative of the temperature of the comfort zone. • Wall mounting: the unit must not be installed in corners, on shelves or behind curtains, near sources or heat or directly exposed to sunlight.
- Page 5 Control unit With built-in ambient temperature sensor. To be installed in zone 1. Outside air temperature System board Load shedding (if any) Installation Installation Control board Power board water outlet water return temperature temperature PhRIe Control by pilot wire for 2 zone (if any) with electric convectors.
- Page 6 Pilot wire for electric convectors (if any) - The pilot wire sends shut-down, "anti-freeze" (long term absence) or "economy" mode instructions to the electric convectors in zone 2, and possibly in the case of 1 floor zone or 1 terminal unit zone applications. Convector control (not supplied) must be adapted to receive this type of signal (standard GIFAM 4).
- Page 7 6.3 - MAINTeNANCe KeyPAD / DIsPlAy UNIT CONNeCTION • A specific keypad / display unit can be connected for maintenance and troubleshooting operations. See maintenance manual. Terminal Caution: R1 R2 This keypad / display unit must not be used for the installation's normal operation.
- Page 8 Par souci d'amélioration constante, nos produits peuvent être modifiés sans préavis. Due to our policy of continuous development, our products are liable to modification without notice. Z.I. Route départementale 28 CS 40131 Reyrieux 01601 TRévoux Cedex FRanCe Tél. 04 74 00 92 92 - Fax 04 74 00 42 00 Tel.
