TURBOTWISTER
ASSEMBLY AND INSTALLATION
INSTRUCTIONS
CORPORATE HEADQUARTERS
WESTERN SALES AND MANUFACTURING PLANT
P.O. Box 400 • • • • 1017 SW Berg Parkway
Canby, Oregon 97013
Phone: (503) 266-2231 • • • • Fax: (503) 266-4334
www.srsmith.com
06-693
JULY 09
©S.R. SMITH, LLC 2008

Advertisement

loading
Need help?

Need help?

Do you have a question about the TURBOTWISTER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for S.R.Smith TURBOTWISTER

Summary of Contents for S.R.Smith TURBOTWISTER

  • Page 1 INSTRUCTIONS CORPORATE HEADQUARTERS WESTERN SALES AND MANUFACTURING PLANT P.O. Box 400 • • • • 1017 SW Berg Parkway Canby, Oregon 97013 Phone: (503) 266-2231 • • • • Fax: (503) 266-4334 www.srsmith.com 06-693 JULY 09 ©S.R. SMITH, LLC 2008...
  • Page 2 Proper installation cannot be overstressed, as an improper installation voids S.R. Smith’s warranty and may affect the safety of the user. Left curve shown for illustration - FIG.
  • Page 3 Garden Hose Adapter 1 ea. 8-532 .5" High X .5” Wide X 32” Long Rubber Gasket 1 ea. 8-531 .25” High X .375” Wide X 33” Long Rubber Gasket 1 ea. ™ TURBOTWISTER PARTS LIST (11) (10) (13) (12) (18) (15) (14)

  • Page 4: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Tools Required: 1. Ratchet handle 8. 1/4" drill bit 2. 9/16” deep socket 9. Power drill 3. 9/16” wrench 10. PVC pipe primer & glue 4. 3/4" socket or wrench 11. Anti-seize 5. 7/32” allen wrench 12. Saw to cut PVC pipe 6.
  • Page 5 Assembly: 1. Place the pedestal on the ground and set the exit slide section on top. 2. Attach the exit slide section to (10) the middle slide section using the hardware shown. If necessary lift up on the exit end to keep the joint tight while fastening.
  • Page 6 3. Remove the assembled exit and middle slide sections from the pedestal. Turn over and fasten from the underside as (11) shown. 4. Attach the pedestal to the middle and exit slide sections as shown in (3) locations. 5. Install the 3/8” studs into the threaded inserts in the top of the ladder as shown in (4) locations.
  • Page 7 6. Assemble the top and bottom ladder sections as shown. Install hardware in the appropriate locations but do not fully tighten. This will help aid in alignment. Once all hardware is in place, fully tighten. 7. Lay the ladder flat and attach the top slide section as shown.
  • Page 8 9. Attach the base unit as shown in (6) locations. Mark and drill a ¼” pilot hole in the center of each recess before fastening with the lag screws. (17) (14) (18) (12) (16) (15) 10. Assembly of Water Supply Plumbing Parts: •...
  • Page 9 “stub up” as necessary to the plumbing assembly installed in the ladder. 4. The TurboTwister can handle 25-30 gallons per minute. Water flow is to be regulated using the ball valve near the base of the ladder.
  • Page 10 6. Ensure the slide ladder is plumb by placing a level on a ladder tread. If necessary, shims can be provided by S.R. Smith to place beneath the base of the ladder to ensure it is plumb due to varying deck slopes.
  • Page 11 MANUFACTURER’S PLACEMENT INSTRUCTIONS 1. The critical dimensions for placement of the TURBOTWISTER are as shown in FIG.’S 8 and 9. A. The slide exit runway surface shall not exceed twenty inches (20”) above the water surface as shown in FIG. 8.
  • Page 12 CHART 1 BOARD MINIMUM CLEARANCE AREA POOL TYPE “C” DIMENSION “W” DIMENSION 14’-6” 5’-0” 14’-6” 6’-0” 16’-6” 6’-0” 18’-6” 7’-6” 21’-0” 7’-6” See Article 5 contained in ANSI/NSPI-5 2003 STANDARD FOR RESIDENTIAL INGROUND SWIMMING POOLS and refer to FIGURE 3 and Table 1 for Minimum Water Envelope Dimensions AB, BC and Width at Point C.
  • Page 13 6. Observe the position of the exit of the slide as shown in FIG.’S 8, 9 and 11 on pages 11 and 12. IMPORTANT PERSONALLY GIVE TO SLIDE OWNER THE TURBOTWISTER OWNER’S MANUAL, THE WARRANTY CARD AND ANSWER ALL QUESTIONS.
