- Page 1 Add: Buchmatt strasse 19 3400 Burgdorf Email: sales@raytools.net Email: peter.cam@raytools.ch Tel: +41 78 827 49 63 BT240 Series Product Manual...
- Page 2 BT240 Product Manual Version： V1.0 Date： 2016/2/4 Historical Versions： History Date Description of Editor Reviewer Date of Edition change Review V1.0 2016/01/27 Mandy Alex 2016/2/4 Version Change V1.0 RayTools AG. Copy Right 1 | 15 www.raytools.net...
-
Page 3: Table Of Contents
Changing Focusing Lens ......................12 Removing Tip Assembly ........................13 4.3.1 Replacing the ceramic head ....................13 4.3.2 Replacing 3D Module Tm ......................13 4.3.3 Replacing Gas Jet Tip ....................... 14 V1.0 RayTools AG. Copy Right 2 | 15 www.raytools.net... -
Page 4: Introduction
TM & WM Figure 1 the structure of laser heads BT230 is a cutting head applied to low-power industrial laser production of RAYTOOLS AG company. The wholly optimized optical focus quality, the design of gas channel inner chamber, breathing gas flow... - Page 5 4） Module WM: protect the optics, protect the focusing lens from being damaged by residues and lengthen the life span of the optics. 5） Module TM: guide the focused light beam to the processing workpiece and spray high-speed gas flow to achieve high-quality cutting. V1.0 RayTools AG. Copy Right 4 | 15 www.raytools.net...
-
Page 6: Installation-Mechanicals
Figure 3-1 Hose Location Of The 2D Figure 3-2 Hose Location Of The 2D laser head laser heads V1.0 RayTools AG. Copy Right 5 | 15 www.raytools.net... -
Page 7: Assist Gas
Figure 4-1 Fiber Orientation input straight. To reoriented the connector, you may do as follows. See V1.0 RayTools AG. Copy Right 6 | 15 www.raytools.net... - Page 8 BT240 QCS connector input manual (1)loosen locking ring 1 and 2. (2)Input the fiber connector horizontally (3)Tighten locking ring 1 and 2. Use a wrench if necessary. Figure 4-2 Fiber Orientation V1.0 RayTools AG. Copy Right 7 | 15 www.raytools.net...
-
Page 9: Operation-Mechanicals
Adjust the Focus Dial Knob to the largest scale and power up the laser at a power setting of 80-100W Take a laser shot on the crepe paper each movement of less than 0.55mm (the nearer the movement is, the better) V1.0 RayTools AG. Copy Right 8 | 15 www.raytools.net... - Page 10 Turn the Focus Dial Knob and adjust the focal distance according to the scale Once the focus position is properly set, tighten the Lock Nut by rotating it clockwise Figure 6 Setting Focus Position V1.0 RayTools AG. Copy Right 9 | 15 www.raytools.net...
-
Page 11: Service
The seal ring and cover slide will pop out (save the seal ring). • Clean or change the cover slide Figure 8 The Structure Of The Cover Drawer V1.0 RayTools AG. Copy Right 10 | 15 www.raytools.net... -
Page 12: Changing 3D Laser Head Cover Slide
4.2.3 Changing Collimating Lens Assembly Changing the collimating lens assembly can be performed while the head is mounted to the machine. This menu only covers the servicing of a Raytools’ collimator. Refer to third-party collimator’s instructions for its servicing. Caution：Remove fiber with great care. Damaging fiber end may result in fiber replacement. -
Page 13: Changing Focusing Lens
4.2.4 Changing Focusing Lens Changing the focusing lens assembly can be performed while the head is mounted to the machine. This menu only covers the servicing of a Raytools’focusing lens. Refer to third-party focusing lens’instructions for its servicing. Caution：As lens holder is removed, be sure to keep it vertical to prevent the lens from falling out. -
Page 14: Removing Tip Assembly
Unscrew the outside cover of Module TM Unscrew the locking screws with a wrench Install the new Module TM on the laser head with screws Screw the outside cover V1.0 RayTools AG. Copy Right 13 | 15 www.raytools.net... -
Page 15: Replacing Gas Jet Tip
4.3.3 Replacing Gas Jet Tip Unscrew the gas jet tip Insert the new gas jet tip. Tinghten with appropriate force. calibration capacitor needed after replacement. Figure 17. Replace Module TM V1.0 RayTools AG. Copy Right 14 | 15 www.raytools.net...
