King Pigeon S266 User Manual

King Pigeon S266 User Manual

Gsm/sms/gprs/3g/4g, temperature & humidity data logger, temperature & humidity monitoring alarm
Hide thumbs Also See for S266:
Table of Contents

Advertisement

Quick Links

Inquiry Onsite Temperature &
Humidity with SMS!
High-Low Threshold alarm
with SMS text Message alert!
Interval Report Onsite
temperature & humidity to
Your Mobile Phone by SMS!
GSM/SMS/GPRS/3G/4G
Temperature & Humidity Data Logger
Temperature & Humidity Monitoring Alarm
S264/S265/S266
User Manual
Ver 2.1
Date Issued: 2018-04-09
King Pigeon Hi-Tech. Co.,
Ltd.
www.GPRS-M2M.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S266 and is the answer not in the manual?

Questions and answers

Related Manuals for King Pigeon S266

Summary of Contents for King Pigeon S266

  • Page 1 SMS text Message alert! Interval Report Onsite temperature & humidity to Your Mobile Phone by SMS! GSM/SMS/GPRS/3G/4G Temperature & Humidity Data Logger Temperature & Humidity Monitoring Alarm S264/S265/S266 User Manual Ver 2.1 Date Issued: 2018-04-09 King Pigeon Hi-Tech. Co., Ltd. www.GPRS-M2M.com...
  • Page 2 We recommend that the advice of a registered electrician be sought before any Installation work commences. King Pigeon Hi-Tech.Co., Ltd, its employees and distributors, accept no liability for any loss or damage including consequential damage due to reliance on any material contained in this handbook.

  • Page 3: Table Of Contents

    Do not use the unit when using GSM/3G/4G equipment is prohibited or might bring disturbance or danger. Interference All wireless equipment might interfere network signals of the unit and influence its performance. Page 3 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...

  • Page 4: Standard Packing List

     Support configure parameters, load profiles, export historical data and upgrade the firmware via PC;  Wall mount or 35mm standard DIN rail Design, convenient installation,  Metallic cover, small size, exterior dimension is L70*W88*H30mm. 5. Specifications Item Reference Scope Page 4 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...

  • Page 5: Physical Layout And Installation Diagram

    Relay indicator, any one relay close, will turn on. 6.2 Interface Instructions for installation At the backside of the panel, please use the tool to remove the screw, and you can see the below: Page 5 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 6 Connect to DS18B20 sensor VCC wire, (Red wire). Temperature & Humidity GND , Connect to AM230x or DS18B20 GND wire, (black wire). Data port, connect to the 1 AM230x or DS18B20 Data wire, (Yellow/Green wire). Page 6 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...

  • Page 7: Initialize/Reset The Gsm Unit

    Step3: Connect the RTU to the PC by USB Cable. And connect the external DC Power to DC Power Ports, Power on, and switch on the device, see below: Page 7 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 8 Details please check the picture as below: Tips: If not connect successfully, pls check if USB connect well, or COM port and password correct or not. Drop-down menu interpretation: Page 8 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 9 【Reboot】：Restart the device and open the configuration software. 【Language】： 【Chinese】：Set the configurator language to Chinese. 【English】：Set the configurator language to English. 【Skins】：Choose color for configuration software (Reserved). 【Help】： 【About】：Configuration software relative information. Basic Setting Page 9 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 10 Write: Click it to save the time into the device after adjust the time. Read: Read device current time. PC Time: Read PC current time. Reminder: Please remember that click "Setting" -"Write Setting" button to save it after parameter be written. Page 10 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 11 Current Status: Relay current status: Open or Close. Reminder: Please remember that click "Setting" -"Write Setting" button to save it after parameter be written. Manual Switch: Close or Open the relay immediately, used for on-site testing. Page 11 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 12 Current Value: To show the current value of the sensors, used for testing. Reminder: Please remember that click "Setting" -"Write Setting" button to save it after parameter be written. Page 12 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 13 All: Tick it stands for enable all of options in this line, from “Dial ~ Relay Close/Open”. Reminder: Please remember that click "Setting" -"Write Setting" button to save it after parameter be written. Page 13 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 14 If the action is for DOUT (relay),then the relay working time is depend on the DOUT parameter. Reminder: Please remember that click "Setting" -"Write Setting" button to save it after parameter be written. Page 14 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 15 “www.rtu-m2m.com”, port “8001”. Login Message: For Modbus protocol, ASCII or hexadecimal optional, Max. 50 characters Reminder: Please remember that click "Setting" -"Write Setting" button to save it after parameter be written. Page 15 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 16 Search: After setting the time period, click the button to search historical records in this time. Export CSV: Export current display historical records to CSV format file. Import CSV: Import the historical record file to current page. Page 16 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...

  • Page 17: Sms Commands & App (Recommend To Use The App)

    3) External DC Power Lost Delay Time to Alarm SMS Command Return SMS Content PWD+ ACxxx External DC Power Lost Delay time to Alarm: xxx Setup (Notice: xxx stands for delay time, minutes range 000~999 minutes. =000, Page 17 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 18 Device ID: Armed/Disarmed GSM Signal Value: PWD+ EE External DC Power Goes OFF/ON Temperature 1 Channel Name:Current Value,Normal/High Alarm/Low Alarm Humidity 1 Channel Name: Current Value, Normal/High Alarm/Low Alarm Page 18 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 19 PWD+ DOO+ channel number<nn> DOx: OFF Inquiry all DO Current DO1: ON/OFF PWD+ DOE Status DO2: ON/OFF Set Pulse Output time PWD+ DOP+ channel number<nn>+ T+ xxxx DOx Pulse Output Time: xxxxS Page 19 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
  • Page 20 Temperature T+ Channel Name AIN1:Temperature(Default) & Humidity 1234AIN03TCooling Room (Series number: two digits, S264 AIN2:Humidity(Default) Channel is 01~08, S265/S266 is 01~16; ..Name Name max 40 digits) AIN15:Temperature(Default) Inquiry the AIN16:Humidity(Default) PWD+ AIN+ Series Number 1234AIN0102 to inquiry 1 and 2 Channel <nn>...
  • Page 21 GPRS OFF PWD+ GPRSOFF GPRS/3G Off 18) Setup the GPRS Communication Protocol SMS Command Return SMS Content PWD+ GPRSON+ x Setup Notice: GPRS/3G: x=1/2; 1:Modbus; 2:Definition Protocol) Inquiry PWD+ INTE Page 21 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...

  • Page 22: Data Communication Protocol

    The S264/5/6 support GPRS/3G/4G data transfer to cloud server, support Modbus RTU protocol, TCP/IP protocol and GPRS definition protocol. For Definition Communication protocol, please refer to <S264/5/6 GPRS/3G/4G Temperature Humidity Data Logger Protocol Instruction>. 1.Modbus Register Address（support function 01 05 15） Page 22 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...

  • Page 23: Upgrade Firmware

    Operating Instructions. In no event shall the manufacturer be liable for any alarm system altered by purchasers Any questions please help to contact us feel free. Http://www.GPRS-M2M.com --- The End! --- Page 23 of 23 King Pigeon Hi-Tech. Co., Ltd. Ver 2.1...
