User Manual LNB Configuration Azbox HD Premium Plus...
Page 2
Azbox HD Premium Plus – LNB Configuration The Azbox HD Premium Plus allows you to configure your TWIN DVB-S2 tuners into 3 modes. To change the mode press the Home button, select: 11. Settings TV Channel Tuner A. DVB-S and press the left or right arrow to change mode.
Page 3
In this configuration you have only one cable that come from your LNB (Antenna) to your Azbox and you loop through both tuner (Out of tuner-A is connected to In of Tuner-B). In this setup, the Azbox handles both tuners (so you don’t have to care about tuner-A or B) but it has disadvantages.
