Proxicast PocketPORT 2 Quick Start Manual

Automatic Configuration

The PocketPORT 2 can automatically configure
itself for dozens of popular 3G & 4G USB modems:
• Insert the USB modem into a PC and use the
software on the modem or the CD to activate it
and make a successful connection to your cellular
service provider.
This step is REQUIRED !
• Configure your Ethernet device to automatically
receive an IP address (DHCP)
• Connect your Ethernet device to the PocketPORT
• Insert the USB modem into the PocketPORT
• Power on the PocketPORT
• Wait 45-60 sec. for the LED to flash Blue
Slow Red
Status LED
Fast Red
Fast Blue
PocketPORT

Quick Start Guide

Bridge / IP Pass-Thru Mode
• Visit http://www.proxicast.com/PocketPORT to find the
settings for your USB modem
• Power on the PocketPORT & wait for the LED to flash Red
• Press the Reset button for 2 sec. (LED = solid Red)
• Set your PC to obtain an IP address automatically (DHCP)
• Connect an Ethernet cable between PC & PocketPORT
• Open PC's web browser to:
Username =
• Enter the required modem settings and your carrier's APN
• Click Generate Configuration, then Write Configuration
• Configure your Ethernet device to obtain an IP address
automatically and connect the device to the PocketPORT
•
Wait 45-60 sec. for the LED to flash Blue
Offline
Connecting
Online
2
TM

Manual Configuration

http://192.168.1.1:8080
admin Password =
Solid Red Configuration Mode
Red/Blue Factory Reset
Fast Violet Firmware Upgrade
1234
