- Page 1 VELUX INTEGRA ® KLF 200 VELUX INTEGRA ® Directions for use ENGLISH VAS 454069-2016-10...
-
Page 2: Table Of Contents
Two instructions are supplied with the interface (A and B). Congratulations on your new VELUX INTEGRA product! ® Thank you for buying this VELUX INTEGRA product. ® The product can be used as an interface or as a repeater. Set-up via a VELUX INTEGRA ®... -
Page 3: Contents Of Packaging
6 Outputs 7 Inputs Default settings Inputs (control) An external control signal shorter than 1.5 second makes the VELUX product travel to end position. • Even inputs (2, 4, 6, 8) are used for close/down: The product travels to end position •... -
Page 4: Important Information
(Jens Aksel Thomsen, Market Approval) • Spare parts are available from your VELUX sales company. • If you have any technical questions, please contact your VELUX sales com- 01.05.2016 Ådalsvej 99, DK-2970 Hørsholm .......... -
Page 5: Function As Interface
. The bottom rows in the INPUT terminals are A B C D E 2 3 4 common ground Thermostatic control of a VELUX roof window by a non io-homecontrol compatible thermostat ® A thermostat can be used for controlling automatic opening and closing of windows depending on the temperature. -
Page 6: Registration Of Products
A B C D E 2 3 4 5 6 7 8 9 10 Note: If you have both a one-way and a two-way control, you can copy the registered products from both controls using VELUX INTEGRA ® two-way control pad KLR 200. ENGLISH... - Page 7 Function as interface Function as interface Registration with VELUX INTEGRA two-way control pad KLR 200 Registration with VELUX INTEGRA two-way control pad KLR 200 ® ® The illustrations below show how to copy the contents from control pad KLR 200 to interface KLF 200.
- Page 8 Function as interface Function as interface Registration with VELUX INTEGRA two-way control pad KLR 200 Registration with VELUX INTEGRA two-way control pad KLR 200 ® ® The illustrations below show how to choose products from the control pad and how to assign them to inputs on the interface.
-
Page 9: Registration With Velux Integra ® Two-Way Control Pad Klr 200
Function as interface Function as interface Registration with VELUX INTEGRA two-way control pad KLR 200 Registration with VELUX INTEGRA one-way remote control ® ® The illustrations below show how to copy the contents from a one-way remote control to interface KLF 200. -
Page 10: One-Way Remote Control
Function as interface Function as interface Registration with VELUX INTEGRA one-way remote control Registration with VELUX INTEGRA one-way remote control ® ® 1 sec When the white light-emitting diode is on, interface KLF 200 has been configured as an interface. -
Page 11: Function Of Outputs
This may take up to 1 minute. A B C D E 2 3 4 5 6 7 8 9 10 OUTPUT A connects to INPUT 1 and 2. OUTPUT B connects to INPUT 3 and 4 etc. ENGLISH ENGLISH 20 VELUX ® VELUX ®... -
Page 12: Function As Repeater
Connect the interface to the mains supply. When the light- emitting diode flashes yellow, the interface is ready to be configured. ENGLISH ENGLISH 22 VELUX ® VELUX ®... -
Page 13: Function As Repeater
You can now operate the products. If this image appears, turn off the control pad. You can now operate the products. When the blue light-emitting diode is on, the interface is configured as a repeater. ENGLISH ENGLISH 24 VELUX ® VELUX ®... -
Page 14: Own Notes
Own notes Own notes OUTPUT INPUT INPUT A B C D E 2 3 4 5 6 7 8 9 10 Product 9 10 ENGLISH ENGLISH 26 VELUX ® VELUX ®... - Page 15 VELUX Company Ltd. 02245/32 3 50 01 848 8775 VELUX Australia Pty. Ltd. VELUX Italia s.p.a. 1300 859 856 045/6173666 VELUX Bosna i Hercegovina d.o.o. VELUX-Japan Ltd. 033/626 493, 626 494 0570-00-8145 VELUX Belgium VELUX Lietuva, UAB (010) 42.09.09 (85) 270 91 01 ВЕЛУКС...
