Atwood APC45 Installation, Operation And Maintenance

ENGLISH
SAFETY ALERT SYMBOLS
Safety Symbols alerting you to potential personal safety hazards. Obey all safety
messages following these symbols.
WARNING
avoid possible
injury or death
FOR YOUR SAFETY READ ALL INSTRUCTIONS
BEFORE INSTALLATION AND OPERATION
INSTALLATION MUST COMPLY WITH ALL APPLICABLE STANDARDS AND CODES.
Installer:
Provide these instructions to the consumer.
Consumer:
Keep documents for future reference.
The Converter/Charger is designed to convert 120 VAC to
12 VDC. This allows operation of 12 VDC devices while being
connected to shore power; using power from a generator; or
using power from on board storage batteries. It also provides
exceptionally clean low voltage power for charging on board
batteries. This Converter/Charger is a 'switch mode' type
supply. Its high frequency electronic design is maintenance
free with superior performance.
The APC Series offers a wide range of power - 32,45, 55 and
75 amp models - in a compact design weighing just six
pounds. Atwood technology maintains safe, cool, reliable
converter/charging operation, ensuring the performance of
electrical systems with sophisticated controls. The
thermostatically controlled cooling fan also reduces noise and
increases warm weather performance. The APC's circuitry
includes over-temperature and over-current protection,
safeguarding against power supply damage. External fuses
provide "reversed battery" protection, preventing damage from
cross-wiring.
APC filtered power provides smooth, optimum DC appliance
operation and the full output rating is available for battery
charging.
SPECIFICATIONS FOR CONVERTERS
PART
.
NO MODEL LBS
35411 APC32 6
35412 APC45 6
35413 APC55 6
35414 APC75 6
9
CAUTION
avoid possible
injury and/or property damage
EXTERNAL
. .
AMPS DIM IN INCHES
32 10.36 x 7.75 x 3.5
45 10.36 x 7.75 x 3.5
55 10.36 x 7.75 x 3.5
75 10.36 x 7.75 x 3.5
LITERATURE NUMBER
CONVERTER/CHARGER
APC MODELS: 32, 45, 55 & 75 AMP
•Installation •Operation •Maintenance
COMMON FEATURES
• Regulated output voltage ensures against erratic charging and
damage to amenities.
• Over current protection prevents battery damage caused by over-
charging.
• Short circuit protection prevents damage to power supply.
• Reverse battery hook-up protection prevents power supply damage
due to cross-wiring.
• Fan cooled prevents unit from over-heating.
• 100% burn-in tested ensures stringent quality assurance.
• 2-year limited warranty.
• ETL listed to UL 458.
INSTALLATION
1. DISCONNECT POWER. Disconnect the RV battery POS (+) wire
at the battery before connecting the Converter/Charger.
PERSONAL INJURY/PRODUCT DAMAGE
• Never store electrical devices in a compartment where
flammable liquids are stored.
• Do not mount the unit in a compartment designed for the
storage of batteries or flammable liquids (such as gasoline).
2. LOCATION. Mounting location may be on any interior (out of
direct weather) surface. Location chosen must be
accessible after installation. When mounted inside a
cabinet, the cabinet must be vented and large enough to
allow dissipation of heated air. Make sure that there is a
minimum of 1" (one inch) free air space from sides and back
of the unit so that cooling air can move through the unit
properly.
AVOID foreign contaminants such as dirt, metal particles or
moisture.
3. MOUNTING. Flanges with holes are provided for ease of
mounting using standard fasteners. Surface must support
the converter's weight (6 lbs) during vehicle operation.
INPUT OUTPUT
VOLTAGE VOLTAGE
AC DC
105-130 13.6
105-130 13.6
110-130 13.6
110-130 13.6
1
MPD 39065
Effective 2/04/08
WARNING
INPUT OUTPUT
CURRENT CURRENT
AMPS AMPS
7 32
10 45
13 55
15 75
INPUT
.
FREQ
HZ
58 to 62
58 to 62
58 to 62
58 to 62
