DEMA 162HCGHT Installation Instructions

DEMA 162HCGHT DRUM MOUNT INJECTOR
PARTS CHECKLIST:
1.
ITEM
A.
B.
C.
D.
E.
F.
*This unit does not have threads in the hose barb for metering tips. By eliminating the threads, the ID of the hose barb could be made
larger to accommodate the maximum chemical draw. You can cut down the maximum draw by using the 61-9K metering tip kit. The
metering tips will fit loosely in the hose barb but the intake tube will hold them in place.
INSTALLATION:
2.
a) Attach tubing to barb fitting under bung cap and screw bung cap into drum mount opening.
b) Attach garden hose with spray gun assembly to the injector outlet. Note: Make sure that the ball valve under
the spray gun is turned to the off position.
c) Water inlet is garden hose swivel. Use high-grade garden hose.
OPERATION:
3.
Turn on water supply. Turn the ball valve under the spray gun to full open for immediate chemical injection. Note:
Water pressure must be at least 30 psi, in order for the injector to prime.
SERVICING:
4.
CAUTION: Turn off water supply before servicing.
A. Failure to inject chemical:
a)
Low water pressure. At least 30 psi is required.
b) Chemical passage clogged. Remove the injector and soak in hot water.
c) Lime deposits in water passage. Remove the injector and soak in deliming solution.
B. Injection continues after water is turned off:
a) Turn the ball valve under the spray gun counterclockwise to close position.
1 cps (centipoise) is equal to the viscosity of water
75 cps is approximately equal to the viscosity of 10 weight motor oil
200 cps is approximately equal to the viscosity of most dishwashing detergents
RETURN: NO MERCHANDISE MAY BE RETURNED FOR CREDIT WITHOUT DEMA'S WRITTEN
PERMISSION.
ADVANCE OF RETURN.
WARRANTY: DEMA products are warranted against defective material and workmanship under normal use and service for
one year from the date of manufacture. This limited warranty does not apply to any products which have a
normal life shorter than one year or failure and damage caused by chemicals, corrosion, improper voltage
supply, physical abuse, or misapplication. Rubber and synthetic rubber parts such as "o"-rings, diaphragms,
squeeze tubing and gaskets are considered expendable and are not covered under warranty. This warranty is
extended only to the original buyer of DEMA products. If products are altered or repaired without prior
approval of DEMA, this warranty will be void.
Defective units or parts should be returned to the factory with transportation prepaid. If inspection shows
them to be defective, they will be repaired or replaced without charge, F.O.B. factory. DEMA assumes no
liability for damages. Return merchandise authorization number, to return units for repair or replacement,
must be granted in advance of return.
I-725
Rev. G-30334 2/07/05
INSTALLATION INSTRUCTIONS
Injector Assembly
Supply Tubing with Strainer
Ceramic Weight
Garden Hose
Spray Gun Assembly
Metering Tip Kit, 61-9K *
RETURN MERCHANDISE AUTHORIZATION NUMBER REQUIRED IN
DESCRIPTION QTY.
1
1
1
1
1
1
Pg. 1 of 3
