SOUNDMASTER KR4 Manual

1. Left Microphone Switch
2. Left Microphone
3. Cassette Compartment
4. Pause Button
5. Stop/Eject Button
6. F.FWD Button
7. Rewind Button
8. Play Button
9. Record Button
10. Right Microphone
11. Right Microphone Switch
12. DC 6V In Jack
13. Volume/Power Control
14. Speaker
15. Battery Compartment (Bottom of Unit)

BATTERY OPERATION

1. Open the Battery Door located on the bottom of the unit by loosing the screw.
2. Insert four ( 4 ) C size batteries into the Battery Compartment with polarities aligned as shown in the
diagram outside the compartment and replace the Battery Compartment Cover.

BATTERY PRECAUTIONS

Follow these precautions when unsing batteries in the device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing the Batteries as indicated next to the battery compartment.
Reversed batteries may cause damage to the device and/or present an explosion hazard.
3. Do not mix different types of batteries together
(e.g. Alkaline and Carbon-zinc) or old batteries with fresh ones
4. If the device is not to be used for a long period of time, remove the batteries to prevent damage or injury from
possible battery leakage.
5. Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.
(Follow battery manufacturer´s directions.)
6. Never dispose of batteries in a fire as an explosion hazard exists. Dispose of batteries according to battery
manufacturer´s instructions.

AC OPERATION

To operate the unit unsing AC power, connect an AC adaptor (not included) having a 6V negative center (
the DC jack on the side of the unit and to a wall outlet having 120V, 60Hz AC only. The batteries are automatically
disconnected when the AC adaptor is used.
Model KR4

LOCATION OF CONTROLS

POWER SOURCES

1
) to
