Summary of Contents for SOUNDMASTER UR2050
- Page 1 DEUTSCH FRANÇAIS ENGLISH NEDERLANDS UR2050...
-
Page 2: Environmental Protection
ENVIRONMENTAL PROTECTION Do not dispose of this product with the normal household waste at the end of its life cycle. Return it to a collection point for the recycling of electrical and electronic devices. This is indicated by the symbol on the product, user manual or packaging. - Page 3 UR2050 operating instruction of English UR2050 Manual General Description FM radio by Digital Tuning System (DTS) with PLL technology RDS feature provide radio station name display & automatic time up-date CD/MP3/WMA and USB playback function provided AUX in function provide for play back external audio product...
-
Page 4: Operating Components
UR2050 operating instruction of English Operating Components Preset+ ： Call back preset station for up Preset-： Call back preset station for down Prog. | MEM： Station Memory CD、AUX、FM 、USB selector / user select Func | user： 5. Timer Operate for timer function AOT | Dim：... - Page 5 UR2050 operating instruction of English Control of CD tray 14. Power: Power on/Off 15. Display 16. Disc 17. USB Sock 18. Remote control window 19. Mounting Plate Spacer for under-cabinet installation 21. FM antenna 22. AUX IN 23. DC-Socket Current connection socket(5.5V) for power adapter...
- Page 6 UR2050 operating instruction of English 1. Start the device When unit is powered up first time, Automatic update function will start automatically and “PLEASE WAIT FOR SETTING THANKS “is flashing on LCD, When press any key to terminate this function.
- Page 7 UR2050 operating instruction of English 2.2.7 Press other key to start its corresponding function. 2.2.8 When no key has been pressed for 10 seconds, the current setting is confirmed and it switches to auto-run mode 2.2 Set the date 2.2.1 Press <Mode>...
- Page 8 UR2050 operating instruction of English 2.6 Set Automatic dimmer timer 2.6.1 Press <Mode> once in dimmer switch mode, 2.6.2 Press <UP> or <DOWN> turn off or turn on dimmer function 2.6.3 When the timer switch on, back light will automatically dimmer from 23:00 ~ 05:59, press any key could be brighter for 60 second.
- Page 9 UR2050 operating instruction of English 2.10.10 When no key has been pressed for 10 seconds, the system goes back to auto-run mode 2.11 Cooking Timer Value Preset 2.11.1 There are 6 preset Cooking timer 2.11.2 Press <Timer> once to enter the timer mode.
- Page 10 UR2050 operating instruction of English B, The duration of the alarm is 60 minutes 3.3.5 If CD alarm is selected, A, CD On B, The duration of the alarm is 60 minutes 3.3.6 Press any key to terminate the currently active alarm, even key-lock has been switched on .
- Page 11 UR2050 operating instruction of English When AMS function active, the stored memories will replace by the new scanned radio station. 3.5 Using CD/MP3 3.5.1 Start the CD/MP3 • Press <Power> once to turn on the unit • Press <FUNC/User> key to select CD/MP3 •...
- Page 12 UR2050 operating instruction of English 3.7 Using Aux function • Turn on your sound source device, connect audio cable with 3.5mm jack from source device output into hole of “ AUX” • Select output levels refer to “3.8 Output level control” to select a sound output you want.
Need help?
Do you have a question about the UR2050 and is the answer not in the manual?
Questions and answers
Ieslēdzot disku atskaņotāju pēc 10 sekundēm nevar noregulēt skaņu?
The SOUNDMASTER UR2050 does not prevent sound adjustment after 10 seconds of being turned on. However, in certain setting modes, if no key is pressed for 10 seconds, the device automatically confirms the current setting and switches to auto-run mode. This may give the impression that adjustments are restricted, but normal sound controls like volume adjustment are still functional when the device is in standard operation mode.
This answer is automatically generated
Kāpēc skaņa uz pogas + vai - ir bez skaņas un klusē. Kāpēc? Lūdzu izskaidrojiet sīkāk un kā rīkoties? Ar cieņu.
The SOUNDMASTER UR2050 may be silent when pressing the or buttons if the volume is set too low or muted. Additionally, if the device is not in radio, CD, or Aux mode, volume control may not function. Ensure the device is powered on and in the correct mode before adjusting the volume.
This answer is automatically generated
Kāpēc nevaru ieslēgt skaņu?
There could be several reasons why the SOUNDMASTER UR2050 has no sound:
` to increase the volume.
1. Incorrect Output Level – Ensure the volume is not set too low. Press `
2. AUX Connection Issues – If using AUX, confirm the audio cable is properly connected and the source device is playing.
3. Standby Mode – If the unit is in standby mode, turn it on.
4. Alarm or Timer Settings – If an alarm or timer is active, it may override normal audio functions.
5. Power Issues – Ensure the device is properly powered and the battery backup is not interfering.
If none of these solve the issue, check for additional settings or errors on the LCD display.
This answer is automatically generated
MY soundmaster ur 2050Si will not go past wait in the led screen. Why?
The SOUNDMASTER UR2050 displays "wait" on the LED screen when a CD is inserted, and the device is reading the data from the CD. This process takes about 5-10 seconds while the system confirms the CD format and prepares for playback.
This answer is automatically generated
