Quick Start Guide
SK-DVR-DIY-CVI
Scan QR code for complete version user manual
Lifetime Tech Support | 1 Year US-Based Warranty
1-866-514-8998
9am-5pm CST, Monday-Friday
Support@poedepot.com
DIY Kits Setup Instuctions
**Total 4 boxes: DVR box*1, Camera box*2,
Accessories box*1 (at the bottom)
1. Connect each camera to the 65ft power and video cables.
2. Connect the 1-to-4 power splitter to the power adapter (in the
accessories box).
**NOTE: Accessories box is under all other boxes.
3. Plug the video (yellow) connector to the DVR, and plug the power
(red) connector to the 1-to-4 power splitter.
4. Plug the power adapter (in the DVR box) to the DVR.
5. Connect DVR with monitor by using VGA or HDMI cable.
6. Connect DVR to your router using an Ethernet cable.
7. Plug the mouse into USB port on the DVR.
8. Plug both power adapters into wall outlet.
9. Turn on the power switch on the back of the DVR (if applicable).
Initial Settings
1. Boot up device, which will display device initialization interface.
2. Setup password for admin (default username).
3. Set security questions and click "OK."
2
Advertisement
Summary of Contents for BV Security SK-DVR-DIY-CVI
- Page 1 **Total 4 boxes: DVR box*1, Camera box*2, Accessories box*1 (at the bottom) Quick Start Guide SK-DVR-DIY-CVI 1. Connect each camera to the 65ft power and video cables. 2. Connect the 1-to-4 power splitter to the power adapter (in the accessories box).
- Page 2 Quick Settings App Setup – Simpliview Require to connect DVR to network The startup and configuration wizards can guide you through the basic settings to get the device working properly. 1. Scan the QR code below and download “Simpliview.” 1. Login with default username admin and the password you created. 2.
- Page 3 Schedule 6. Input your device name, click and scan/input the device SN. To find the device SN: 1. Enter Schedule interface: Right click mouse -> Main Menu -> Setup -> Network -> P2P Right click mouse -> Main Menu -> Setup -> Storage -> Schedule 2.
- Page 4 Motion Detection Playback Motion detection allows you to save hard drive space and maximize 1. Enter Playback interface: recording time by only recording when motion is detected in selected areas. Right click mouse -> Main Menu -> Search. 1. Enter Motion Detection interface: Device Selection Right click ->...
