BC100SSC Dolphin Clad Stainless Steel
Nappy Changing Unit Surface Mounted
Recessed and Surface Mounted
Installation Instructions
• Failure to follow these warnings and the installation instructions could result in serious injury
or death.
• Read all instructions before installing diaper changing station. Keep these instructions.
DO NOT discard.
WARNING
DOLPHIN
SI258R-D
Advertisement
Table of Contents
Related Manuals for Dolphin BC100SSC
Summary of Contents for Dolphin BC100SSC
- Page 1 BC100SSC Dolphin Clad Stainless Steel Nappy Changing Unit Surface Mounted Recessed and Surface Mounted Installation Instructions DOLPHIN WARNING • Failure to follow these warnings and the installation instructions could result in serious injury or death. • Read all instructions before installing diaper changing station. Keep these instructions.
- Page 2 INSTALLATION INSTRUCTIONS BC 100SSC-R Recessed Version Installation BC 100SSC-R Recessed Version Installation ADULT INSTALLATION REQUIRED. TOOLS REQUIRED: Level (A) Measuring tape (B) Power drill with 3/16” masonry bit (C) Power screwdriver with bull nose phillips bit (D) Truss head spanner bit (E) •...
- Page 3 BC 100SSC-R Recessed Version Installation Continued BC 100SSC-R Recessed Version Installation Continued INSTALLATION Recommended Blocking: 35 5/8" 1" (905 (25.4 3 7/8" Wood double stud blocking is necessary. Contact an architect and (98.4 building official to make sure the blocking is adequate and complies with building codes (Fig.
- Page 4 INSTALLATION INSTRUCTIONS BC 100SSC-SM Surface Mounted BC 100SSC-SM Surface Mounted ADULT INSTALLATION REQUIRED. TOOLS REQUIRED: Level (A) Measuring tape (B) Power drill with 3/16”, 1/2” and 1/8” masonry bit (C) Power screwdriver with bull nose phillips bit (D) Truss head spanner bit (E) •...
- Page 5 BC 100SSC-SM Surface Mounted Continued BC 100SSC-SM Surface Mounted Continued INSTALLATION Recommended Blocking: Wood double stud blocking is necessary. Contact an architect and building official to make sure the blocking is adequate and complies with building codes (Fig. a). For A. D. A. Compliance 45”...
- Page 6 BC 100SSC-SM Surface Mounted Continued BC 100SSC-SM Surface Mounted Continued Using Toggle Anchors (Fig. f) Toggle Wood Stud Anchor 1. Insert metal end of toggle anchor into 1/2” hole. 2. Slide zip strip down snugly against wall. Break-Away 3. Snap off break-away pieces of toggle anchor (Fig. h). 4.
- Page 7 2 Locate the gas shock and inspect the brackets that the gas shocks are secured to in order to determine if there is any damage to these brackets or the structure of the changing station. 3 If damage is present contact Dolphin for a replacement inner unit as fitting new struts to a damaged unit is not safe 4 If no damage to the unit or basketry surrounding the shock is evident.
