7
2
6
3
4
1
5
_____________________
TSI and TSI logo are registered trademarks of TSI Incorporated. LogDat is a trademark of TSI Incorporated.
Bluetooth is a registered trademark of Bluetooth SIG Inc. Android is a trademark of Google Inc.
CAPTURE HOOD STAND
ASSEMBLY AND USAGE
APPLICABLE TO CAPTURE HOOD MODELS EBT731, PH731, AND 8380
INSTRUCTIONS
Item #
Description
1
Tripod
2
Top Bracket
3
Bottom Bracket
4
Bracket Mount
5
Caster Wheels
6
Thumbscrew, Large
7
Thumbscrew, Small
Qty
1
1
1
1
3
2
4
Advertisement
Table of Contents
Related Manuals for TSI Instruments CH-STAND
Summary of Contents for TSI Instruments CH-STAND
- Page 1 CAPTURE HOOD STAND ASSEMBLY AND USAGE INSTRUCTIONS APPLICABLE TO CAPTURE HOOD MODELS EBT731, PH731, AND 8380 Item # Description Tripod Top Bracket Bottom Bracket Bracket Mount Caster Wheels Thumbscrew, Large Thumbscrew, Small _____________________ TSI and TSI logo are registered trademarks of TSI Incorporated. LogDat is a trademark of TSI Incorporated. Bluetooth is a registered trademark of Bluetooth SIG Inc.
- Page 2 Attaching Capture Hood to Stand 1. Mount the capture hood base onto the quad bracket corners. Use thumbscrews to tighten. 2. Raise the hood using the adjustable extension poles. 3. Make sure to make a tight seal against the outlet. 4.
