Leonics OA EXTRA 525 User Manual

SPECIFICATION
MODEL
CAPACITY Power factor = 0.6
SYSTEM UPS system
Control system
Stabilizer function
LOAD The number of PC*
APPLICATION
INPUT Input Voltage
Nominal Input (single phase)
Frequency
OUTPUT Voltage stabilizer mode (sine wave)
Voltage backup mode for 1 PC
(modify sine wave)
Frequency (backup mode)
PROTECTION Transfer time
Output short circuit
Overload protection
Surge energy dissipation
Power dissipation
Acoustic noise
BATTERY Type
Capacity
Backup time
Continuous recharging time to 80%
OUTPUT OUTLET Number of backup outlet
Number of surge protection outlet
FEATURE Power Watcher
Noload shutdown option switch
Backup test switch
DC start
Communication interface
Easy-Mon software
Restart voltage checking system
Surge protection for telephone line
Surge protection for LAN line
Surge protection for laser printer
Operating with generator
User replaceable battery
ENVIRONMENT Temperature
Humidity
PHYSICAL W x H x D (cm.)
DIMENSIONS
WEIGHT Approximate in kg.
CONFORMANCE Design regulation
*PC = Pentium 4 , 1.8GHz with 15" monitor respectively., **Printer = Bubble jet or Dot matrix printer.
Continuous product development is our commitment. In that manner, the above specifications may be changed without prior notice.
SAFETY INSTRUCTIONS
Please read carefully and follow this OA EXTRA series UPS guide.
Important : Please keep this user's guide for reference in order to use the UPS properly
and safety. This user's guide contains instructions for installation, operation
and specifications.
For product safety, please check this product annually by our service qualified per-
sonnel or if there are any symptoms of problems which are not mentioned in this guide or
an queries, please contact your LEONICS local distributors,LEONICS Service Center, send
e-mail to support@leonics.com or visit www.leonics.com.
Risk of electric shock, DO NOT remove cover. No user serviceable part
inside, please refer servicing to qualified service personnel.
1.1 Electrical Safety
1.1.1 Do not work alone where there are electrically hazardous conditions.
1.1.2 Contact with live conductors will cause burns and dangerous electric shock.
1.1.3 Only qualified electricians allow to install and wiring this unit and the system.
1.1.4 Periodically check your cable, terminal and power source to make sure that
they are in good condition.
1.1.5 To reduce risk from electric shock if you can not find the electrical ground
( ) of the building, unplug the UPS from the AC source before plug in your
load at the rear side of the UPS. Then, plug in the UPS to AC source.
1.1.6 Do not touch any metal parts or any electrical connection when UPS is operating.
1.1.7 Use ONLY one hand when plugging and unpluging the load in order to avoid
electric shock from touching two surfaces with different potential.
1.1.8 It is recommended to connect the UPS to a three wire AC source (two live wires
and ground) which connects to a protected circuit such as employs a fuse or
circuit breaker.
1.2 CAUTION ! Safety guide for installation and operation
1.2.1 Before installing or using this unit, read all instructions, caution markings on
the UPS and all connected load, and all sections of this user guide.
1.2.2 Install this unit in a temperature and humidity controlled indoor area with
adequate air flow and away from chemical particles or flammable substances .
Avoid installing the unit near radio transmission station, heat dissipation equip-
ment and direct sunlight.
1.2.3 This unit has ventilation grills. Ensure that sufficient ventilation is provided.
DO NOT block the ventilation grills.
OA EXTRA 525 OA EXTRA 750 OA EXTRA 1000 OA EXTRA 1500
525 VA (315W) 750 VA (450W) 1000 VA (600W) 1500 VA (900 W)
Digital Line Interactive UPS
Microprocessor 8 bit
Buck / Boost
1 set + printer** 2 sets + printer** 3 sets + printer** 4 set + printer**
220 Vac ± 25% (230 Vac option)
220 Vac (230Vac option)
50Hz ± 6% (60Hz ± 6%) (auto sensing) (50Hz ± 10% option)
220 Vac ± 10% (230 Vac option)
220 Vac ± 5% (230 Vac option)
50Hz ± 0.1% (60Hz ± 0.1%) (auto sensing)
5 ms. (in-phase transfer)
Auto cut - off with audio & visual alarm
Fuse protection Circuit breaker
STD. UL1449 : 160 Joules (IC = 6500A)
1,600,000 W within 100 microsec.
Less than 40 dBA at 1 metre
Sealed lead acid (maintenance free)
12 V 7 Ah 12 V High Rate 2 x 12 V 7 Ah 2 x 12 V High Rate
(12 V High Rate option)
15 - 40 min. (depend on load)
3 - 8 hours
3 6
1 1
yes
yes
yes
yes
Level communication (DB-9)
UPS status, Backup time remaining, Schedule shutdown computer and UPS
yes
yes
option
yes
yes
yes
0 - 45°C
0 - 95% (non - condensing)
10 x 16.5 x 30 10 x 16.5 x 30 12.5 x 21 x 36
8 8.5 14
EN 50091-2, EN 50022 (B), EN 61000-4-2, (4), (6), IP 21
Caution
12.5 x 21x 36
17
1.2.4 Use insulated tools to reduce your risk of electric shock.
1.2.5 Remove all jewelry or other metal objects such as rings, necklace, bracelets
and watches when installing this product.
1.2.6 Properly wiring the cables as shown in the wiring diagram.
1.2.7 Before connecting the communication interface signal cable, Turn off the UPS
by pressing the front panel button until the Utility Line OK/Fail (
Overload Alarm (
once. Then, release the button.
1.2.8 Turn on the UPS before turn on the load to prevent surge from the loads.
1.2.9 DO NOT connect utility power to the UPS OUTPUT. This may cause the UPS
damaged.
1.2.10When heavy rain, avoid using electronic equipments including UPS to prevent
it from lightning.
1.2.11Use soft cloth to clean the UPS when it is turned OFF. DO NOT clean it with
solvent.
1.2.12DO NOT use the UPS with life recovery instruments. The failure of UPS may
cause life recovery instruments failure or effect to their performance or effect
to the safety system of those instruments.
1.3 Warning ! Battery Safety
1.3.1 Although the UPS is not connected to any power source, its outlets may be
energized because it has a battery inside.
1.3.2 The UPS has hazardous voltages inside, do not disassemble any parts of UPS
except for the battery. Users are allowed to replace battery by turning off power
switch at the rear side of the UPS, then unplug the AC input cable. Users are not
allowed to repair, recondition or disassemble the UPS. This must be done by
Leonics qualified technicians only.
This product contains sealed lead acid battery and must be recycled
properly. For recycling please return it to a LEONICS local distributor or
LEONICS Service Center or contact your local recycling center for proper
disposal information.
1.3.3 Do not dispose of batteries in a fire. They may be exploded.
1.3.4 Do not disassemble batteries. They contains poisonous electrolyte which is
harmful to your skin and eyes.
1.3.5 Replace batteries with the same type and rating and follow the proper battery
replacement procedure.
1.3.6 When replacing a battery, use tools with insulated handles and remove any
watch, rings or other metal objects that you wear in order to avoid electric shock.
1.3.7 If user has to keep the UPS or does not use if for long time, recharge the battery
every 3 months in order to preserve the battery. To recharge the battery,
connect it to the AC utility and turn on the UPS for 8 hours.
) lamps are lit at the same time and the alarm sounds
) and
