- Page 1 VS2500 PageCall Compact Paging Center User's Manual / Installation Guide Version 1.1 VISIPLEX, INC. 2008...
- Page 2 VS2500 PageCall Compact Paging Center Copyright The product described in this manual includes copyrighted Visiplex computer programs stored in semiconductor memories. As such these programs may not be copied or reproduced in any manner without the express written permission of Visiplex, Inc.
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION Standard Features of the VS2500 Optional Features of the VS2500 Encoder Options Transceiver Options Service Options PROGRAMMING THE VS2500 GENERAL SCREEN INFORMATION Page Menu Send a Page Page By Phone Option MENUS AND PROGRAMMING MENUS Menu A – Single Alarm Programming Menu B –... -
Page 4: Introduction
(remote) basis. Non- Visiplex transmitters can also be used with the VS2500. Some connect on a standard basis; others may require a local to tone control adapter (consult Visiplex). Standard Features of the VS2500 • 2 lines by 16 characters LCD display •... -
Page 5: Standard Features Of The Vs2500
These options may be classified in 3 basic categories. These are: Encoder, RF, and Service. Each of these categories is listed below with the available features. In addition, customization is possible (consult your Visiplex Sales Representative with your special requirements). Encoder Options •... -
Page 6: Programming The Vs2500
Prior to any VS2500 programming, make sure all the connections to power and the external (if used) transmitter are done properly. Refer to the installation section for more details. General Screen Information The VS2500 menu screens that require data entry are made up of a series of visual prompts. The prompt for each field appears on the top line of each screen. -
Page 7: Page By Phone Option
To end any message, press the # key or hang up. After the page is sent, the system will prompt, “page sent”. Menus and Programming Options To access each menu, select the corresponding letter key on the keypad. Menu A – Single Alarm Programming Enter Password: 2500 Enter Input Number: Enter alarm point number 001-048, you wish to program. -
Page 8: Menu B - Administration Menu
Update Changes? Press # key to save, or * key to escape without saving. Enter Input Number: Enter the next alarm point you wish to program, or press the * key to exit. Menu B – Administration Menu Enter Password: 2500 Select Option: 1: Pager Programming 2: Enter new time... -
Page 9: Menu C - Multiple Alarm Point Programming
Programming Pagers Into VS2500 From Menu B, select option 1 Pager To Edit: Enter three-digit pager ID number (001-999) Pager Cap code: Enter the seven-digit cap code from the back of the pager. Pager Type: (Select pager type 1-4), followed by the # key. 1: Alpha pager 2: Numeric pager 3: Voice pager... -
Page 10: Setting Up Group Paging
Resetting the Database The Reset Database feature deletes all information stored in the VS2500 database, including all pager information and all pre-programmed alarm messages. Selecting <8> in the Administration menu will bring the next screen: RESET DATABASE: ARE YOU SURE? If you are sure you want to reset the database, hit the #(pound) key to confirm. -
Page 11: Vs2500 Installation
Plug the power cord supplied with your external transmitter to the back of the transmitter box and the other end into a 120VAC wall outlet. Turn the transmitter power switch (located on the back of the transmitter box) to ON. Note: Contact Visiplex tech support for connections to non- Visiplex transmitters. -
Page 12: Transceiver Options
• Visiplex will ship you (Overnight) an Advanced Replacement unit identical to the one in the field. • Ship us the defective unit. Visiplex will repair it and return it to you within 10 business days, if possible. • You must return the Advanced Replacement unit to Visiplex within 30 days, otherwise you will be invoiced for the full cost of the replacement unit. -
Page 13: Specifications
SPECIFICATIONS General Operating Temperature Range: 0 to +40° C Storage Temperature Range: -10 to +60° C Operating Humidity Range: 10 to 65 % Frequency Range: 403-433 MHz 438-470 MHz Data Rate (RF): 500-2400 BPS Speaker Audio Level: 500mW Page Types: Tone alert, Tone &... - Page 14 RF Modules RECEIVER, UHF: Frequency Stability: (30C to +60 C at +25 C reference) +0.00025% Sensitivity (12 dB SINAD): 0.35 µV max Intermodulation (EIA SINAD): 70 dBm Channel Spacing: 25 kHz Adjacent Channel Selectivity (EIA): 70 dB Modulation Acceptance: +5.0 kHz, min. Spurious Rejection: EIA: 75 dB CEPT: 70 dB...
-
Page 15: Vs2500 Menu And Programming Quick Reference Sheets
VS2500 MENU AND PROGRAMMING QUICK REFERENCE GUIDE... - Page 16 Menus and Programming Quick Reference Sheets To access each menu, select the corresponding letter key on the keypad Menu A – Single Alarm Programming Enter Password: 2500 Enter Input Number: Enter alarm point number 001-048 you wish to program. Select Input type: (1-4) or (5-8)**, followed by the # key 1: Dry Contact, Normally Open (N.O.) 2: Dry Contact, Normally Closed (N.C) 3: Voltage, High –...
- Page 17 Menu B – Administration Enter Password: 2500 Select Option: 1: Pager Programming Enter three-digit pager ID Enter seven-digit pager cap code (address) Select pager type, followed by the # key 1: Alphanumeric 2: Numeric 3: Voice 4: Tone Only Page Select pager format, followed by the # key 1: POCSAG 2: GOLAY...
