LI-COR LI-210SA Instruction Manual

Radiation sensors, quantum/pyranometer/photometric/line quantum sensor

Advertisement

LI-COR Radiation Sensors
Instruction Manual
Terrestrial Type SA:
G
G
G
G
LI-190SA Quantum Sensor
LI-200SA Pyranometer Sensor
LI-210SA Photometric Sensor
LI-191SA Line Quantum Sensor

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LI-210SA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LI-COR LI-210SA

  • Page 1 LI-COR Radiation Sensors Instruction Manual Terrestrial Type SA: LI-190SA Quantum Sensor LI-200SA Pyranometer Sensor LI-210SA Photometric Sensor LI-191SA Line Quantum Sensor...
  • Page 2 Sensors, Type SA Instruction Manual Publication No. 8609-56 November, 1986 Revised July, 1991 LI-COR, inc. 4421 Superior Street P.O. Box 4425 Lincoln, NE 68504 USA Telephone: 402-467-3576 FAX: 402-467-2819 Toll-free 1-800-447-3576 (U.S. & Canada) © Copyright 1986, LI-COR, Lincoln, Nebraska USA...
  • Page 3: How To Use This Manual

    NOTICE The information contained in this document is subject to change without notice. LI-COR MAKES NO WARRANTY OF ANY KIND WITH REGARD TO THIS MATERIAL, INCLUDING, BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. LI-COR shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
  • Page 4: Table Of Contents

    Use of the Pyranometer Sensor ..............14 LI-200SA Spectral Response ..............15 Calibration ....................15 LI-200SA Specifications ................17 Section 4. LI-210SA Photometric Sensor Use of the Photometric Sensor ..............18 Photometric Terms ................... 19 Spectral Response ..................20 Calibration ....................20...
  • Page 5 Figure 3. Cosine response of terrestrial sensors ........Figure 4. LI-190SA spectral response curve .......... 11 Figure 5. LI-200SA spectral response curve .......... 16 Figure 6. LI-210SA spectral response curve .......... 18 Figure 7. LI-191SA cosine response ............24 List of Tables...
  • Page 6: Section 1. General Information

    Section I General Information Type "SA" Sensors LI-COR SA type sensors are characterized by having the coaxial sensor cable terminated with a BNC connector. Figure 1 shows a typical SA type sensor. Type SA terrestrial sensors include the LI-190SA Quantum Sensor, the LI-191SA Line Quantum Sensor, the LI-200SA Pyranometer Sensor, and the LI-210SA Photometric sensor.
  • Page 7: Operation

    LI-185A, LI-188, LI-510, and LI-550 require the use of the 9901-014 connector conversion cable. Contact LI-COR for further details. When a LI-COR Light Meter or data logger is not used, the sensors can be used with other millivolt recorders or data loggers by connecting a millivolt adapter.
  • Page 8 1000 mol s m Or, = 4.83 mV/1000 µmol s The shield of the coaxial cable on LI-COR light sensors is positive and the center conductor is negative. (The trans-impedance amplifier used in LI-COR light meters requires a negative signal). For data logger or...
  • Page 9: Cosine Response

    Figure 2. Lambert's Cosine Law. Cosine Correction Properties Cosine corrected LI-COR terrestrial type sensors are all designed for the same cosine response characteristics. The percent of true cosine response is presented in Figure 3. The error is typically less than ± 5% for angles less than 80°...
  • Page 10: Cleaning Information

    DO NOT use alcohol, organic solvents, abrasives, or strong detergents to clean the diffusor element on LI-COR light sensors. The acrylic material used in LI-COR light sensors can be crazed by exposure to alcohol or organic solvents, which will adversely affect the cosine response of the sensor.
  • Page 11: Section 2. Li-190Sa Quantum Sensor

    The vertical edge of the diffuser must be kept clean in order to maintain appropriate cosine correction. LI-190SA Spectral Response In 1976, LI-COR had sensor calibration data verified by the National Research Council of Canada (NRC), one of the major standards laboratories in the world.
  • Page 12: Figure 4. Li-190Sa Spectral Response Curve

    Figure 4. LI-190SA Sensor Response Curve. The spectral response of the quantum sensor is obtained by use of a light source and a monochromator. A thermopile or calibrated silicon photodiode which has a known spectral response over the spectral range of interest is used to determine the monochromator output in energy flux density, W(λ), at the wavelength setting λ.
  • Page 13: Calibration

    The NRC performed an absolute calibration of the LI-COR Quantum Sensor. Information concerning these tests is available from LI-COR. The calibration is obtained at LI-COR by using a standard light source calibrated against a National Bureau of Standards lamp. The photon flux density from the standardized lamp is known in terms of micromoles s where one micromole = 6.022 x 10...
  • Page 14: Li-190Sa Specifications

    LI-190SA Specifications Absolute Calibration: ± 5% traceable to the U.S. National Institute of Standards and Technology (NIST). Sensitivity: Typically 8 µA per 1000 µmol s Linearity: Maximum deviation of 1% up to 10,000 µmol s Stability: < ± 2% change over a 1 year period. Response Time: 10 µs.
  • Page 15: Section 3. Li-200Sa Pyranometer Sensor

    The LI-COR pyranometer may be handheld or mounted at any required angle, provided that reflected radiation is not a significant portion of the total.
  • Page 16: Li-200Sa Spectral Response

    Spectral Pyranometer (PSP) of which the calibration is periodically confirmed. The calibration was performed under daylight conditions by a computer sampling of instantaneous readings from the Eppley and LI-COR pyranometers. Instantaneous readings were taken continuously for 10 minutes and then averaged. Sequential ten minute averaging periods were run from sunup to sundown for 3-4 days.
  • Page 17: Figure 5. Li-200Sa Spectral Response Curve

    Figure 5. LI-200SA Spectral Response Curve.
  • Page 18: Li-200Sa Specifications

    LI-200SA Specifications Calibration: Calibrated against an Eppley Precision Spectral Pyranometer (PSP) under natural daylight conditions. Absolute error under these conditions is ± 5% maximum, typically ± 3%. Sensitivity: Typically 80 µA per 1000 W m Linearity: Maximum deviation of 1% up to 3000 W m Stability: <...
  • Page 19: Section 4. Li-210Sa Photometric Sensor

    LI-210SA Photometric Sensor Use of the Photometric Sensor The LI-210SA Photometric Sensor is designed to measure illumination in terms of lux (1 footcandle = 10.764 lux). This is radiation as the human eye sees it. The spectral response is shown in Figure 6.
  • Page 20: Photometric Terms

    Photometric Terms Although characteristics of the human eye vary from person to person, standard luminosity coefficients for the eye were defined by the Commission Internationale de Eclairage (C.I.E., International Commission on Illumination) in 1931. An absolute "sensitivity" figure established for the standard eye relates photometric units and radiant power units.
  • Page 21: Spectral Response

    A footcandle is one candela at a distance of one foot. Spectral Response The spectral response of a typical LI-COR LI-210SA Photometric Sensor compared to the C.I.E. standard observer curve is presented in Figure 6. In...
  • Page 22: Li-200Sa Specifications

    Beginning June 1, 1978, all LI-COR photometric sensors have been calibrated using 683 lumens per watt as the value of spectral luminous efficacy at a wavelength of 555 nm, rather than the previously accepted C.I.E. standard value of 680 lumens per watt.
  • Page 23: Section 5. Li-191Sa Line Quantum Sensor

    LI-191SA Line Quantum Sensor Use of the Line Quantum Sensor The LI-191SA Sensor is designed for measuring PAR (photosynthetically active radiation) in applications where the radiation to be measured is spatially non-uniform (such as within plant canopies). To achieve this, the sensor features a sensing area that is one meter in length.
  • Page 24: Cosine Correction Properties

    Spectral Response The spectral response of the LI-191SA is comparable to that of the LI-190SA Quantum Sensor. All LI-COR quantum sensors use computer tailored filter glasses to achieve a response that closely approximates the desired ideal quantum response. See Figure 4.
  • Page 25: Absolute Calibration

    Figure 7. Cosine Response of LI-191SA Line Quantum Sensor Measurement of the spectral response requires a stabilized light source, monochromator, lock-in amplifier and calibrated reference detector. Measurements taken with the test sensor and reference detector at many wavelengths yield data points used to plot the relative spectral response. Absolute Calibration The uncertainty of the calibration is ±...
  • Page 26: Li-191Sa Specifications

    LI-191SA Specifications Absolute Calibration: ± 10% traceable to NIST. The LI-191SA is calibrated via transfer calibration using a reference LI-190SA Quantum Sensor. Transfer error is ± 5% (included in the ± 10%). Sensitivity: Typically 3 µA per 1000 µmol s Linearity: Maximum deviation of 1% up to 10,000 µmol s Stability: <...
  • Page 27: Appendix

    Accessories 2003S Mounting and Leveling Fixture. The 2003S is for use with all LI-COR terrestrial type sensors (2.38 cm Dia.). The base is anodized aluminum with stainless steel leveling screws and a weatherproof spirit level for leveling the sensors during operation.
  • Page 28: Warranty

    Warranty Each LI-COR, inc. instrument is warranted by LI-COR, inc. to be free from defects in material and workmanship; however, LI-COR, inc.'s sole obligation under this warranty shall be to repair or replace any part of the instrument which LI-COR, inc.'s examination discloses to have been...
  • Page 29 LI-COR, inc.'s authorized distributor, whichever is earlier.
  • Page 30 ® 4421 Superior Street P.O. Box 4425 Lincoln, Nebraska 68504 USA Phone: 402-467-3576 FAX: 402-467-2819 Toll-free 1-800-447-3576 (U.S. & Canada) E-mail: envsales@env.licor.com Internet: http://www.licor.com...
