Eurotech ZyWAN User Manual

Cellular routing modem
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
ZyWAN
Cellular Routing Modem
Rev F – April 2010 – 110150-1001F
DIGITAL TECHNOLOGIES FOR A BETTER WORLD
www.eurotech.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZyWAN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eurotech ZyWAN

Summary of Contents for Eurotech ZyWAN

  • Page 1 USER MANUAL ZyWAN Cellular Routing Modem Rev F – April 2010 – 110150-1001F DIGITAL TECHNOLOGIES FOR A BETTER WORLD www.eurotech.com...

  • Page 2: Trademarks

    HTTPS option, support for 3G and Novatel modems, and rules for default gateway/DHCP/DNS. Added configuration examples. Updated RS-485 wiring detail. Updates for ZyWAN release 1.7 and style changes. June 2009 (rev 2.0) Added Modem Status pages, DNS option for Cellular, and masquerade option for port forwarding.

  • Page 3: Table Of Contents

    Technical Assistance ............................8 Conventions ................................ 8 Introduction ..............................9 Product Overview ............................... 9 Features ................................... 9 ZyWAN Model Numbers ............................10 Accessories ................................10 Operating Characteristics ..........................11 Electrical Characteristics ............................11 Temperature Range ............................... 11 PART 1: GETTING STARTED ........................13 Chapter 1 Interfaces ...........................
  • Page 4 Unable to Load Web Page ............................. 36 Ping the ZyWAN ..............................36 Check the PC’s Network Configuration ........................37 Using ZyWAN COM1 for Diagnostics ........................37 Check with Network Administrator ......................... 38 PART 2: SOFTWARE CONFIGURATION ...................... 39 Chapter 1 Web Configuration Page ......................
  • Page 5 Networking Setup ............................122 Configuration Example 4: GPS interface ....................123 Cellular Setup ..............................123 GPS Setup ..............................123 Networking Setup ............................124 Appendix ..............................125 A.1. Mechanical Specifications ........................125 A.2. Electromagnetic Compatibility (EMC) ..................... 127 Eurotech Worldwide Presence ........................129 110150-1001F...

  • Page 6: Important User Information

    Eurotech reserves the right to revise this document and to change its contents at any time without obligation to notify any person of such revision or changes.

  • Page 7: Warranty

    The ZyWAN contains a coin-type, replaceable Lithium battery to maintain its real-time clock when input power is removed. The ZyWAN is normally shipped with the battery jumper connected. If the unit will be sitting unused for lengthy periods of time, it is recommended to remove the jumper to extend the life of the battery.

  • Page 8: Technical Assistance

    Before returning any Eurotech supplied product, for any reason whatsoever, you must first send an e-mail to the Technical Support Team. You will receive an RMA number (Returned Material Authorization) for the return of the material.

  • Page 9: Introduction

    Introduction Introduction The ZyWAN is a cellular routing modem for GSM/GPRS, EvDO/1xRTT CDMA, iDEN and 3G networks. It is ideally suited for wireless applications wireless applications such as Internet access, AVL, telemetry, SCADA, mobile computing, and AMR. The ZyWAN operates as a fully configurable embedded Linux router enabling firewall, DHCP, DNS and NAT.

  • Page 10: Zywan Model Numbers

    ZyWAN - User Manual ZyWAN Model Numbers The standard model numbers for the ZyWAN are determined by the hardware options which are part of the product. The list of features and model number variations are explained next. ZyWAN CCCC ####...

  • Page 11: Operating Characteristics

    DESCRIPTION Temperature: Operating: -20 to +65 C Note: Certain models of cellular modems or WiFi cards may have a lower operating temperature range. Contact your local Eurotech representative for more details. Storage: -40 to +85 C Humidity: 10% to 90% relative humidity (non-condensing)
  • Page 12 ZyWAN - User Manual (This page intentionally blank) 110150-1001F...

  • Page 13: Part 1: Getting Started

    PART 1: GETTING STARTED PART 1: GETTING STARTED 110150-1001F...

  • Page 14: Chapter 1 Interfaces

    ZyWAN - User Manual Chapter 1 Interfaces The front panel of the ZyWAN contains the following ports and indicators: GPS – Antenna connection COM3 – RS-232 or RS-422/485 for GPS receiver (SMA) for data communication DIV – Diversity antenna, COM1 – RS-232 serial port...

  • Page 15: Led Indicators

    Power and GPS On = On during startup of ZyWAN. Slow blink = ZyWAN is running, but there is no GPS lock. (Slow blink is approximately one blink every 2 seconds.) Fast blink = ZyWAN running, and GPS position lock obtained.

  • Page 16: Power Connector

    Power Connector The ZyWAN can be powered from 10 to 26 VDC. Power to the ZyWAN is supplied via the 4-pin power socket (mating connector: Kycon KPPX-4P plug). The power plug must be inserted with the flat part of the plug facing up (toward the top of the ZyWAN front panel).

  • Page 17: Antenna Connections

    PART 1: GETTING STARTED Antenna Connections The “CELL” connector on the front of the ZyWAN is typically a standard polarity SMA (female) connector. The cellular antenna to be connected here must be rated for operation within one or more of the ranges required by the ZyWAN model/cellular type, as given in the following table.

  • Page 18: Serial Ports

    In RS-485 or RS-422 systems, the ground connection is optional. Typically, it is used to connect the cable shield for a shielded, twisted pair cable. In the ZyWAN, the RS-485/422 ground is common with the RS-232 grounds, but it is isolated from the metal case. In order to avoid ground loops, connect the cable shield to the RS-485/422 GND AT ONLY ONE POINT in the network.

  • Page 19: Usb

    An older WiFi option used the bottom USB port internally, but the WiFi option now uses an internal PCMCIA card. If the ZyWAN includes either of these hardware options, the external USB socket will be plugged to indicate the port is in use, and it must not be used for external equipment.

  • Page 20: Sim Card

    SIM Card The ZyWAN for a GPRS, 3G, or IDEN network requires a SIM card from the network provider in order to operate on the cellular data network. The SIM card is accessible through an access panel on the bottom of the ZyWAN.

  • Page 21: Battery Link

    The ZyWAN contains a coin-type replaceable Lithium battery (CR2032, 3V) to maintain its real-time clock when input power is removed. A user jumper on the main circuit board enables this battery. The ZyWAN is normally shipped with the battery jumper connected. If the unit will be sitting unused for lengthy periods of time (months or years), it is recommended to remove the jumper to extend the life of the battery.

  • Page 22: Chapter 2 Accessing The Zywan

    What You Will Need Hardware Requirements The ZyWAN must be connected to a stand-alone computer and/or a network, so that the initial configuration may be loaded via the Web configuration page. In order to perform the initial configuration via a stand-alone computer, you need the following hardware: •...

  • Page 23: Optional Equipment

    Additional Documentation In addition to this manual, there are several Application Notes giving further documentation on specific subjects relating to the ZyWAN configuration. These can be found on the ZyWAN software CD or upon request. These Application Notes include: •...

  • Page 24: Serial Connection To Com1

    Serial Connection to COM1 The COM1 port of the ZyWAN is used for a serial console. Typically, this allows a local administrative (‘root’) login to the ZyWAN using a null modem serial cable. The next section describes the settings for Windows HyperTerminal.

  • Page 25: Setting Up Software

    Windows HyperTerminal Windows provides a serial terminal program, HyperTerminal, for serial communications. This can be used to access the console port of the ZyWAN for diagnostics. The following steps are the setup instructions for Windows HyperTerminal. 1. In the Windows Start menu, select Programs>Accessories>Communications>HyperTerminal. The Connection Description window is displayed.

  • Page 26: Ssh Client (Putty)

    Once the PuTTY application is installed on the Windows computer, run the application and enter the IP address of the ZyWAN. Set the protocol to “SSH” and the port to 22 (unless the port has been changed on the ZyWAN from its factory default). Click the Open button to connect.

  • Page 27: Sftp/Scp Client (Winscp)

    The first time a connection is made with PuTTY, a security warning is given as PuTTY tries to authenticate with the ZyWAN. Click Yes to continue, as long as you are sure that this is the correct ZyWAN device. Then log in with the correct username and password.
  • Page 28 ZyWAN - User Manual Run WinSCP after installing it. It may be useful to set the option “Remember last used directory” under the Environment>Directories menu. Also, click on the Preferences option, and the Preferences button. It may be useful to set the “Remember panels’...
  • Page 29 Once connected, WinSCP shows the local directories and files in the left panes. The right panes show the directories and files on the ZyWAN (using WinSCP’s Norton Commander interface only). If all four panes are not visible, they can be displayed by choosing the Options>Local Panel>Tree and Options>Remote Panel>Tree menu options.

  • Page 30: Initial Connection With Single Pc

    The simplest way to start the ZyWAN and perform an initial configuration is to use a direct connection to another computer (PC). To make a direct connection, complete the following steps: 1.
  • Page 31 PART 1: GETTING STARTED 3. Set Up the Network The PC must be set up to obtain its network address from the ZyWAN for this test. After initial configuration of the ZyWAN, the PC can be changed back to its normal network settings.
  • Page 32 ZyWAN - User Manual The PC automatically obtains its address from the ZyWAN. To check the address, complete the following steps: 1. In the Windows Start menu, select Accessories>Command Prompt. The Command Prompt window is displayed. 2. Enter the command .

  • Page 33: Initial Connection Over A Network

    PART 1: GETTING STARTED Initial Connection Over a Network An alternate way to start the ZyWAN and to perform an initial configuration is to connect it to an existing network which also contains the configuration computer (PC). Note: Ethernet port ‘1’ is used in this section, which typically comes configured to obtain its address automatically from a network using DHCP.
  • Page 34 One way to check the ZyWAN network address is to use a crossover (null modem) serial cable between the PC and the ZyWAN. The null modem cable can be purchased from Eurotech, or it may be obtained from an electronics supply store.
  • Page 35 4. Browse ZyWAN Configuration Page To browse the ZyWAN configuration page, complete the following steps: 1. Open a Web browser and enter the address of the ZyWAN into the address bar. A dialog box is displayed asking for the username and password.

  • Page 36: Troubleshooting Connection Problems

    1. In the Windows Start menu, select Accessories>Command Prompt. The Command Prompt window is displayed. 2. Type the command: ping address where is the numeric address of the ZyWAN. address A diagnostic message is sent to the ZyWAN to check communication. If successful, the Ping response receives the following reply. 110150-1001F...

  • Page 37: Check The Pc's Network Configuration

    ZyWAN, depending on the test being performed. If the ZyWAN is acting as a DHCP Server to the PC and is configured to serve the DNS addresses, these are displayed in the settings.

  • Page 38: Check With Network Administrator

    127.0.0.1 for the ZyWAN itself, and ip_address ip_port is the network port. Check with Network Administrator If you are still unable to get the ZyWAN to connect to an existing network, check with a network administrator for additional support. 110150-1001F...

  • Page 39: Part 2: Software Configuration

    PART 2: SOFTWARE CONFIGURATION PART 2: SOFTWARE CONFIGURATION 110150-1001F...

  • Page 40: Chapter 1 Web Configuration Page

    (page 113). Make sure the ZyWAN is connected to the network. To log on to a web page, complete the following steps: 1. Enter the appropriate address preceded by ‘http://’. If the ZyWAN has never been configured, see...
  • Page 41 PART 2: SOFTWARE CONFIGURATION In Mozilla Firefox version 2, select one of the “Accept this certificate” checkboxes, and then click OK. In Mozilla Firefox version 3, click “Or you can add an exception...”, and then click Add Exception. In the following dialog box, click Get Certificate and Confirm Security Exception. 110150-1001F...

  • Page 42: Switching Between Http And Https

    The tabs across the top (Cellular, Ethernet, etc.) identify each section or page of the configuration. The current settings for any page are read from the ZyWAN whenever a tab is clicked. Clicking on the tab of a page that is currently displayed reloads the existing configuration.

  • Page 43: Clearing The Browser Cache

    Temporary Internet Files, close all instances of the Web browser, and then re-open the ZyWAN Web page. The following section describes this procedure. To clear the browser cache in Mozilla Firefox, select Tools>Clear Private Data. Make sure the “Cache” box is checked, and then click the Clear Private Data Now button.

  • Page 44: Changing A Configuration

    ZyWAN - User Manual To clear the browser cache in Internet Explorer version 6, select Tools>Internet Options, and then click the Delete Files…button. Changing a Configuration The following sections describe the configuration details for each Web page. To make changes on any page of the configuration, complete the following steps: 1.

  • Page 45: Using Default Gateway, Dhcp, And Dns

    Yes). The WiFi interface can be configured in similar manner (in “managed mode”). In this case, it is likely that the ZyWAN will obtain a Default Gateway and DNS server from the network to which it is attached.

  • Page 46: Default Route

    ZyWAN’s network address as its Default Gateway. The ZyWAN is able to act as a gateway, but in order to route traffic from one interface to another, there must also be a NAT entry configured on the Networking page to route from the source network to the destination network.

  • Page 47: Chapter 2 System Status

    EVDO Provider Since the EvDO cellular provider has to be specified with the modem provided with the ZyWAN, this is set as part of the factory configuration (applies only to ZyWAN-EVDO models). Possible options for EvDO provider are: Sprint, Verizon, Bell Mobility, and Telus.

  • Page 48: Get Modem Status

    ZyWAN - User Manual Get Modem Status Click the arrow on the Status page to get modem and communication diagnostics for the cellular module. Before doing this action, the cellular configuration needs to be set, as described in Cellular Configuration on page 61.
  • Page 49 PART 2: SOFTWARE CONFIGURATION Click the Account Information link to show account details for the EVDO cellular module. FIELD/OPTION EXPLANATION Account Information Active NAM Selected profile, NAM0 or NAM1 (MC5725 only) IP Address Public IP address assigned by the cellular network Activation Status Status of whether the account is activated or not Activation Date...
  • Page 50 ZyWAN - User Manual Click the System Diagnostic Information link to show diagnostic data for the EVDO cellular module. FIELD/OPTION EXPLANATION System Diagnostic Information Bytes Sent Total number of bytes sent while a data call is active (The Sent and Received counters are reset after the call ends.)

  • Page 51: 3G Status

    PART 2: SOFTWARE CONFIGURATION 3G Status Click the Version Information link to show version details on the 3G cellular module. FIELD/OPTION EXPLANATION Version Information Hardware Version Hardware version of cellular module Firmware Version Firmware version in cellular module Firmware Date / Time Date of firmware version in cellular module Click the Modem Information link to show modem settings for the 3G cellular module.
  • Page 52 ZyWAN - User Manual Click the Account Information link to show account details for the 3G cellular module. FIELD/OPTION EXPLANATION Account Information (U)SIM card’s ICCID Integrated Circuit Card ID of the installed SIM card (U)Sim Card’s IP IP address obtained on cellular network Click the Operational Status Information link to show current operational details, such as the 3G cellular signal strength.
  • Page 53 PART 2: SOFTWARE CONFIGURATION FIELD/OPTION EXPLANATION Operational Status Information RX Level Received cellular signal level (dBm) PS State State of packet-switch (data) connection to cellular network Current Frequency Band Frequency band currently in use Current Network Technology Network technology currently used by cellular module Time Current time, in seconds from power-up of the cellular module Temperature...

  • Page 54: Iden Status

    ZyWAN - User Manual IDEN Status Click the Version Information link to show version details on the IDEN cellular module. FIELD/OPTION EXPLANATION Version Information Codeplug/Bandmap Version Codeplug and bandmap version loaded in iO270 cellular module, in the format AA.BB/CC.DD, where AA.BB is the codeplug revision, and CC.DD is the bandmap revision...
  • Page 55 Any port to which a connection must be made from the cellular network must have a port opened in the firewall, for a specified protocol (TCP, UDP). The ZyWAN opens ports 443, 80, and 22 (TCP) by default, plus any ports which are listed in the Networking page of its configuration (see page 81).
  • Page 56 ZyWAN - User Manual Click the Operational Status Information link to show current operational details, such as the IDEN cellular signal strength. FIELD/OPTION EXPLANATION Operational Status Information Signal Strength, RSSI Received signal strength of IDEN signal, in dBm IDEN cellular signal quality indication (SQE, higher number is better)

  • Page 57: Gprs Status

    PART 2: SOFTWARE CONFIGURATION Click the System Diagnostic Information link to show diagnostic data for the IDEN cellular module. FIELD/OPTION EXPLANATION System Diagnostic Information Usage The total sum of minutes used for dispatch, interconnect and circuit data calls on an iDEN network Registration Log –...
  • Page 58 ZyWAN - User Manual Click the Modem Information link to show modem settings for the GPRS cellular module. FIELD/OPTION EXPLANATION Modem Information ESN (electronic serial number) of the cellular module IMEI IMEI (International Mobile Equipment Identifier) of the cellular module...
  • Page 59 PART 2: SOFTWARE CONFIGURATION Click the Operational Status Information link to show current operational details, such as the GPRS cellular signal strength. FIELD/OPTION EXPLANATION Operational Status Information Signal Strength, RSSI Received signal strength, in dBm, calculated from CSQ value CSQ, BER CSQ is an indication of GSM received signal strength, 0-31 (31 is best).
  • Page 60 ZyWAN - User Manual Click the Network Information link to show information about the GPRS cellular network. FIELD/OPTION EXPLANATION Network Information Service Data Rate Data rate of the bearer service, used when data calls are originated or received GPRS Mobile Station Class Normally should be Class ‘B’...

  • Page 61: Chapter 3 Cellular Configuration

    PART 2: SOFTWARE CONFIGURATION Chapter 3 Cellular Configuration The Cellular properties, and therefore the ZyWAN base model, are determined by what model of cellular modem is installed. This is configured at the factory. See System Status on page to find out the ZyWAN model.
  • Page 62 EvDO network. The network service provider provides this information. 2. Configure the modem module with the NAM profile information. On the ZyWAN, this is done by filling in the correct fields and clicking the Set NAM Profile button.
  • Page 63 PART 2: SOFTWARE CONFIGURATION Activate EVDO Modem? Activation of an EvDO module may require information to be input by the user, as described previously. After selecting Yes to Activate EVDO Modem?, the following prompt is displayed. The activation process or changing of accounts on the module interrupts any existing cellular connection, if currently active.
  • Page 64 ZyWAN - User Manual The following screen capture shows the Cellular tab if the Novatel E725 is installed. The following table lists the fields and options offered on the Cellular tab. See the previous table for information related to activation with specific cellular carriers.
  • Page 65 PART 2: SOFTWARE CONFIGURATION The following table lists the available buttons. BUTTON EXPLANATION Get NAM Profiles Clicking this button reads from the module any existing account profiles in the modem. This reads the MDN, MSID, System ID, and Network ID and fills the NAM 0 and/or NAM 1 entries on the Web page with this data.
  • Page 66 ZyWAN - User Manual HTTP Reply Status – 200 (E725 response) E725: ---> at NO CARRIER ---> at ---> at$nwactivation? $NWACTIVATION: 8018337159, 8019539892 ------- IOTA STATUS ------- ---> at+iota? Iota Enabled In Progress: 0 Repeat Test OK: 0 Repeat Test Failed: 0...
  • Page 67 Make sure that a cellular antenna is connected to the ZyWAN and that the ZyWAN is located in an area where EvDO/CDMA service for the service provider is available.
  • Page 68 1 2970] DM session completed successfully (type=1 initiator=0) Please wait for ZyWAN unit to restart ... If this success message is not displayed here, another attempt may be made to provision the account. If necessary, the entire response text from the text area can be copied and pasted, in order to request troubleshooting assistance from the service provider.
  • Page 69 PART 2: SOFTWARE CONFIGURATION (E725 response) Status information is displayed in the large text area. The following message is displayed: Waiting for reply (this may take a few minutes to complete)… The normal response from this action should look something like the following: HTTP Reply Status - 200 --->...

  • Page 70: Zywan-3G Options

    ZyWAN - User Manual ZyWAN-3G Options The following screen capture shows the Cellular tab on the ZyWAN-3G. The following options may be configured to set up the 3G cellular network. OPTION EXPLANATION Obtain DNS from Normally, the cellular provider supplies one or more addresses Service Provider? of a DNS server to use while connected to the carrier.
  • Page 71 PART 2: SOFTWARE CONFIGURATION If Custom is chosen as the network provider for ZyWAN-3G, the following screen capture lists the fields and options that are available. FIELD/OPTION EXPLANATION Enter the APN (Access Point Name) of the cellular provider’s data connection. This is supplied by the cellular provider.

  • Page 72: Zywan-Iden Options

    ZyWAN - User Manual ZyWAN-IDEN Options The following screen capture shows the Cellular tab on the ZyWAN-IDEN. The following table lists the items that are available. FIELD/OPTION EXPLANATION Obtain DNS from Normally, the cellular provider supplies one or more addresses...
  • Page 73 T-Mobile APN: wap.voicestream.com Dial String: atd*99***1# Authentication: (none) If Custom is chosen as the network provider for ZyWAN-GPRS, the following screen capture lists the fields and options that are available. FIELD/OPTION EXPLANATION Enter the APN (Access Point Name) of the cellular provider’s data connection.

  • Page 74: Chapter 4 Ethernet Configuration

    DHCP Client If Use Dhcp? is set to Yes, the ZyWAN acts as a DHCP client to automatically obtain its Ethernet network address settings from a server on the LAN. Otherwise, set this parameter to No in order to configure specific TCP/IP addresses.

  • Page 75: Dhcp Server

    Run DHCP Server This option is used when the ZyWAN is to act as a DHCP server on the Ethernet network, assigning network addresses to other devices. Set this to No if this option is not used.
  • Page 76 1 and 254, greater than the Range From. Pass DNS Servers to Set this option to Yes if the ZyWAN should act as a DNS proxy DHCP Clients server on the network. The ZyWAN will pass requests to whatever DNS server is assigned on its default route, and will pass the responses back to the requesting client.

  • Page 77: Chapter 5 Wifi Configuration

    Ad-hoc: Network composed of only one group of wireless devices and without an Access Point. Managed: ZyWAN connects to an 802.11 Access Point on a network. Master: ZyWAN is the synchronization master, acting as an Access Point.

  • Page 78: Dhcp Client

    IP address settings, as discussed in the following sections. DHCP Client If Use Dhcp? is set to Yes, the ZyWAN acts as a DHCP client to automatically obtain its WiFi network address settings from a server on the WiFi network.

  • Page 79: Dhcp Server

    Run DHCP Server This option is available when the Mode is ad-hoc or master. This allows the ZyWAN is to act as a DHCP server on the WiFi network, assigning network addresses to other devices. Set this to No if this option is not used.
  • Page 80 1 and 254, greater than the Range From. Pass DNS Servers to Set this option to Yes if the ZyWAN should act as a DNS proxy DHCP Clients server on the network. The ZyWAN will pass requests to whatever DNS server is assigned on its default route, and will pass the responses back to the requesting client.

  • Page 81: Chapter 6 Networking Configuration

    NTP services. Open Ports Select Yes if you wish to open the ZyWAN firewall to inbound TCP or UDP connections. This applies to any traffic from other devices that terminates at the ZyWAN, not port forward or NAT traffic.
  • Page 82 Enter the numeric IP address, or range of addresses, which is Network the source of the connection to the ZyWAN. Each of the four fields must be a number between 0 and 255. For instance, entering an IP address network of 172.16.11.0 limits incoming connections from addresses 172.16.11.1 through...

  • Page 83: Enable Port Forwarding

    Select Yes if you wish to forward individual IP ports. If a host connection comes in on one network interface at a given port, its communication is redirected to the IP address and port number on another of the ZyWAN interfaces.

  • Page 84: Enable Nat

    Select Yes if you wish to enable Network Address Translation, also referred to as IP Masquerading. This allows devices on one interface of the ZyWAN (‘internal’ side) to access the network on a second interface (‘external’ side), typically to allow devices to connect to the Internet via a single external IP address. The...
  • Page 85 Enter the numeric IP address, or range of addresses, which the Address ZyWAN translates from the source (internal) network. Each of the four fields must be a number between 0 and 255. For instance, entering an IP address network of 172.16.11.0 translates all addresses from 172.16.11.1 through...

  • Page 86: Time Synchronization

    ZyWAN - User Manual Time Synchronization Select the method of synchronizing the internal clock of the ZyWAN. Available options are: None, GPS, and NTP. The GPS option allows the time to be acquired from the GPS receiver (if installed). The NTP (Network Time Protocol) updates the clock using NTP protocol from a network server.

  • Page 87: Chapter 7 Gps Configuration

    GPS data over a network connection in NMEA format. See page 89. GPS UDP Message Format? Select a data format to enable the ZyWAN to send GPS data over a network connection using UDP protocol. Available options are None, Arcom Format, and ActSoft Format.

  • Page 88: Forward Gps To Physical Com Port

    Select the serial COM port to which the GPS data is sent. Important: Make sure this COM port is not configured for another service in the ZyWAN. Otherwise, both services may conflict for the port and not operate correctly. Baud Rate Select the baud rate to use for the serial GPS output.

  • Page 89: Enable Gps Terminal Server

    GPS data to a host. Port numbers must be an unused port number between 1 and 65535. Maximum Number of Enter the maximum number (between 1 and 8) of simultaneous Connections Allowed: host connections which are allowed to connect to the ZyWAN to receive streaming GPS data. 110150-1001F...

  • Page 90: Gps Udp Message Format

    “Open Ports” section of the Networking page as UDP, so the firewall will allow acknowledgements to be sent back to the ZyWAN. This is required for the Actsoft Format mode, and for Arcom Format where the “Enable Cache” option is set to Yes.
  • Page 91 GPS positions have been obtained from the GPS receiver. Unit ID: Enter the unit ID which identifies the GPS data from this ZyWAN when reported to a host computer. This allows the host computer to have unique identifiers for data coming from multiple remote units.

  • Page 92: Arcom Format For Gps Messages (Udp)

    When using the Arcom Format for GPS data, the position message is transmitted using the User Datagram Protocol (UDP). If caching is enabled, the ZyWAN waits a minimum of 10 seconds to receive an acknowledgement message after transmission of a position message. If a response message is received that does not contain the characters ACK or no message is received within the timeout period, the position message is retransmitted.
  • Page 93 PART 2: SOFTWARE CONFIGURATION The following table describes the fields of the position message. FIELD BYTES DESCRIPTION This field indicates the start of message and is always set to 0x7E. snum This field contains the unit serial number in ASCII left justified and null(0) filled to the right.

  • Page 94: Chapter 8 Terminal Clients

    ZyWAN - User Manual Chapter 8 Terminal Clients The following screen capture shows the Terminal Clients tab. The Terminal Client makes an outbound TCP/IP connection to a remote server, allowing pass-through communication with a local serial port. Its serial port also provides AT command emulation to act similar to a dial modem.
  • Page 95 Select the serial COM port to which the Terminal Client data is sent. Important: Make sure this COM port is not configured for another service in the ZyWAN. Otherwise, both services may conflict for the port and not operate correctly. Baud Rate Select the baud rate to use for the Terminal Client port.
  • Page 96 Matching Dial String in the Host Connection rows to find which IP address to use for connection. If the DCD is received, the ZyWAN is connected to the IP address of the first Host Connection row with an empty field for the Matching Dial String.

  • Page 97: Host Connection Table

    PART 2: SOFTWARE CONFIGURATION Host Connection Table The Host Connection Table is part of the Terminal Client configuration, as shown in the following screen capture. At least one row must be configured in the Host Connection Table for it to work properly. Note: When adding or deleting rows of a Host Connection Table, make sure to click the Insert Row# or Delete Row# buttons within the brown section of the Terminal Client,...
  • Page 98 For instance, the Host Connection rows may contain Matching Dial Strings of ATDT1, ATDT555-1212, ATDTDIAL. When any of these strings is received on the serial port, the ZyWAN attempts to connect to the first configured IP address of its Host Connection row.
  • Page 99 PART 2: SOFTWARE CONFIGURATION FIELD/OPTION EXPLANATION Failure Message Enter a text message (such as “NO CARRIER”) sent to the network and/or serial port when the Terminal Client disconnects from a network connection and to the serial port when a connection attempt fails. This text is only sent when the Echo Connect Strings? is set to something other than Neither.

  • Page 100: Chapter 9 Terminal Servers

    ZyWAN - User Manual Chapter 9 Terminal Servers The following screen capture shows the Terminal Servers tab. The Terminal Server sets up a listening port for inbound TCP/IP connection, allowing communication directly to a local serial port. After setting all the Terminal Server properties, click the Submit New Configuration button before switching to a new tab or closing the window.
  • Page 101 Enter the IP port number (between 1 and 65535) to be used on the ZyWAN for incoming TCP/IP connections from a network client application. The IP address to which the client connects may be any valid address configured for the ZyWAN on any interface. Time to Live Enter the Time To Live for the connection (in seconds).
  • Page 102 The Response Timeout and Duplex mode are ignored. Demark IP Packets If a large network packet is sent to the ZyWAN and gets broken up over the network, the fragments can sometimes arrive at slightly different times. Each packet is sent to the serial port, but if the time difference is too great, the serial device may not react properly.

  • Page 103: Serial Ports Table

    Demark Timer Enter the maximum time (in milliseconds, between 10 and 30000) the ZyWAN waits for inactivity on the serial port before sending a response to the network client, if at least one byte has been received.
  • Page 104 ZyWAN - User Manual Note: When adding or deleting rows of a Serial Ports Table, make sure to click the Insert Row# or Delete Row# buttons within the brown section of the Serial Ports Table, not the buttons at the very bottom of the main table.

  • Page 105: Chapter 10 Update

    PART 2: SOFTWARE CONFIGURATION Chapter 10 Update The following screen capture shows the Update tab. The Update tab on the Web interface provides one method to update the ZyWAN firmware to a later version. See the following section, Updating Using WinSCP on page 106, for a more recommended method of updating, especially for systems where the default network is a cellular or private network.

  • Page 106: Updating Using Winscp

    Updating Using WinSCP Several of the version updates for ZyWAN are fairly large. For this reason, it may not be recommended to use the Web interface described above because of the cost or length of time it requires to load files over the cellular network.
  • Page 107 “Zywan-1.xto1.yupdate.tar” file to the ZyWAN as shown in the following screen capture. After the files are loaded, connect to the ZyWAN using either HyperTerminal on the COM1 diagnostics port or over the network using PuTTY (or another SSH application). See the section Setting Up Software page 25, for help setting up HyperTerminal or PuTTY.

  • Page 108: Starting With Version 1.5

    “Zywan-1.5to1.7update.tar” file to the ZyWAN as shown in the following screen capture. After the files are loaded, connect to the ZyWAN using either HyperTerminal on the COM1 diagnostics port or over the network using PuTTY (or another SSH application). See the section Setting Up Software page 25, for help setting up HyperTerminal or PuTTY.
  • Page 109 PART 2: SOFTWARE CONFIGURATION A series of diagnostic messages will be displayed, ending with a system reboot. The following screen captures show these messages. Once the reboot has finished, the system has been updated to version 1.7. This can be verified on the Web configuration page or by typing the command cat /home/arcom/version.txt (The response should be ‘7’.)

  • Page 110: Chapter 11 Security

    ZyWAN - User Manual Chapter 11 Security The following screen capture shows the Security tab. The Security tab provides an option to change the ZyWAN Web configuration password. The following table lists the fields available in this tab. FIELD/OPTION EXPLANATION...
  • Page 111 PART 2: SOFTWARE CONFIGURATION Otherwise, a negative confirmation will indicate that the change password operation was not successful. The following screen capture illustrates this case. 110150-1001F...

  • Page 112: Chapter 12 Backing Up Configurations

    The Web configuration page is the main way to implement configuration changes on the ZyWAN. However, it may be useful to be able to copy configuration files from the ZyWAN, either to install on a multiple devices or to save for archive purposes. This section describes the process of retrieving configuration files from the ZyWAN and loading them onto a different ZyWAN.

  • Page 113: Part 3: Configuration Examples

    PART 3: CONFIGURATION EXAMPLES PART 3: CONFIGURATION EXAMPLES 110150-1001F...

  • Page 114: Introduction

    The actual implementation may vary with customer requirements. The configurations described in this section are only a subset of the functionality of the ZyWAN. Many other configurations are possible that are not represented by the examples included in this section.

  • Page 115: Configuration Example 1: Network Router

    UDP ports 67 and 53 (DHCP and DNS) are allowed in the ZyWAN firewall, and NAT is configured for eth0 and wlan0. The next sections provide detailed descriptions including Web configuration pages for each setting. Cellular Setup The cellular page will depend on the model of ZyWAN and the network provider. 110150-1001F...

  • Page 116: Ethernet Setup

    Do not configure the Default Gateway and DNS Server addresses because these addresses will override the cellular network. If configured, the Default Gateway address will be the ZyWAN’s default route, and the ZyWAN will obtain its public DNS servers from that network.

  • Page 117: Wifi Setup

    Do not configure the Default Gateway or DNS Server addresses because these addresses will override the cellular network. If configured, the Default Gateway address will be the ZyWAN’s default route, and the ZyWAN will obtain its public DNS servers from that network.

  • Page 118: Networking Setup

    Networking Setup Port 67 (UDP) is required for the ZyWAN to act as a Default Gateway to other devices, and port 53 (UDP) is required for it to act as a DNS server. The NAT entries allow devices on each network to route through the ZyWAN to reach the cellular network (ppp0 interface).

  • Page 119: Checking Out Example 1

    The following screen captures show diagnostic information on checking the operation of this Network Router configuration. A computer is connected to the Ethernet 0 port on the ZyWAN and is set to automatically obtain an IP address and DNS. The screen captures show the output of “...

  • Page 120: Configuration Example 2: Wifi Client

    The WiFi Client configuration example illustrates the following features of the ZyWAN: • Ability of the ZyWAN to connect to a WiFi network using an access point or wireless router The following table lists the network settings used in this example, which is only a partial configuration to illustrate the WiFi network.

  • Page 121: Configuration Example 3: Terminal Server

    PART 3: CONFIGURATION EXAMPLES Configuration Example 3: Terminal Server The Terminal Server configuration example illustrates the following features of the ZyWAN: • Terminal Server for IP to serial conversion, allowing host applications to communicate with a local serial device The following table lists the network settings used in this example, which is only a partial configuration to illustrate the Terminal Server network.

  • Page 122: Terminal Server Setup

    This example also shows the use of COM2 (RS-232) at a baud rate of 19,200, which must be set correctly for the application. If RS-485 is needed (on an appropriate model of ZyWAN), use COM3 with ”Flow Control” set to RTS/CTS and “Echo cancel RS485” set to Yes. See...

  • Page 123: Configuration Example 4: Gps Interface

    GPS data requires the cellular account to have a static, public IP address. GPS Setup The GPS Terminal Server allows incoming TCP connections to be made to the ZyWAN to obtain raw NMEA data from the GPS module. The desired NMEA messages may be enabled. This NMEA data may also be sent to a local COM port.

  • Page 124: Networking Setup

    The portions of the Networking configuration page shown are used to enable inbound connections to the Terminal Server port 5000 (TCP). The NTP setting allows the ZyWAN to obtain the correct system time, so GPS reports sent with UDP will contain the correct timestamp.

  • Page 125: Appendix

    Appendix Appendix A.1. Mechanical Specifications Mechanical Characteristics The electrical circuitry of the ZyWAN is contained in a sturdy aluminium enclosure consisting of a base and lid. The following table lists the ZyWAN mechanical characteristics. Length 141 mm (9.4 in.) Width 238.5 mm (5.6 in.)
