  • Page 1 Grid Emulator (GE+ AC&DC) Installation and operation manual...

  • Page 2: Table Of Contents

    INDEX INTRODUCTION ........................5 1.1. Symbols used ......................... 5 1.2. Safety notes ........................5 1.3. Quality and regulations ....................5 PRESENTATION ........................7 2.1. Introduction ........................7 2.2. Power supply features....................9 2.3. Operation and connection modes ................10 2.4. Configuration and control of the power supply ............
  • Page 3 4.4.4.1. AC mode (X6 to X10) ..................34 4.4.4.2. DC unipolar mode.................... 34 4.4.4.3. DC bipolar mode ....................34 4.4.5. Emergency Power Off terminals (X12) (EPO) ............34 4.4.6. Output signal of local Emergency Stop pushbutton state (EPO OUTPUT) ..36 4.4.7.
  • Page 4 5.5.3. Emergency stop ....................62 5.5.4. Accidental shut down ..................62 5.5.5. Alarms........................63 5.5.6. Alarms reset ......................64 LOCAL TOUCHSCREEN CONTROL PANEL ................66 6.1. Upper bar ........................66 6.2. Keyboard ........................67 6.3. LCD tabs distribution ....................68 6.3.1.

  • Page 5: Introduction

    GE+ ACDC Installation and operation manual v11 1. INTRODUCTION Dear customer, on behalf of CINERGIA team, thank you for the confidence placed in our company and for the purchase of this product. Please, read carefully this manual before using the equipment to get familiarized with it and to obtain the maximum performance from it.
  • Page 6 GE+ ACDC Installation and operation manual v11 • EN-IEC 60950-1. IT equipment. Safety. Part 1: General requirements. • EN-IEC 62040-2. Uninterruptible power supply (UPS). Part 2: Prescriptions for Electromagnetic compatibility (EMC). • EN-IEC 62040-3. Uninterruptible power supply (UPS). Part 3: Methods of operation specification and test requirements.

  • Page 7: Presentation

    GE+ ACDC Installation and operation manual v11 2. PRESENTATION 2.1. Introduction As a grid emulator, the GE is a programmable power supply specially designed to emulate grid disturbances. Its programmable parameters will allow the generation of different type of grids and its common faults and disturbances.
  • Page 8 GE+ ACDC Installation and operation manual v11 REFERENCE RATED POWER (25ºC) RATED CURRENT (25ºC) WEIGHT DIMENSIONS Independent mode Parallel mode DxWxH (mm) Arms/ch Adc/ch Arms GE7.5 6.75 ±10A ±10A ±30A GE10 ±15A ±15A ±45A GE15 13.5 ±20A ±20A ±60A GE20 ±25A ±25A ±75A...

  • Page 9: Power Supply Features

    GE+ ACDC Installation and operation manual v11 2.2. Power supply features MAGNITUDE VALUE Power 7.5kVA-200kVA Input side (GRID side) AC Voltage Rated 3x400Vrms+Neutral+Earth Voltage range +15% / -20% Rated AC Current Depends on model (see table) 10-290Arms per phase Frequency 48-62Hz THDi (at rated power)

  • Page 10: Operation And Connection Modes

    GE+ ACDC Installation and operation manual v11 Communication Port: Ethernet (Optional: RS485, RS232, CAN) Communication Protocol: Modbus/TCP Humidity 10-90% (Absolute maximum, without condensation) Temperature 5-35ºC (Absolute maximum) Cooling Forced air Protections Over Current, Over Voltage, Shortcircuit, Overtemperature Standards CE Marking Safety EN-62040-1-2, EN-60950-1 EMC: EN-62040-2...

  • Page 11: Configuration And Control Of The Power Supply

    Remote interface: an Ethernet communication interface with protocol MODBUS/TCP can be used to configure, monitor and operate the grid emulator. By using HMI software application provided by CINERGIA, downloading of excel files is also possible. 2.5. Functional diagram The diagram below is the conceptual functions blocks diagram of the power supply:...
  • Page 12 GE+ ACDC Installation and operation manual v11 Each phase is controlled independently. Output LC filter: the filter in question reduces voltage distortion (caused by switching) at the output of the grid emulator. Output protections: a disconnector is provided to isolate the output from the EUT. Screw terminals are also integrated to connect the EUT.

  • Page 13: Principle Of Operation

    (Please note that earth protection cable is only connected to the cabinet chassis). State-of-the-art digital control is used in all CINERGIA products. In the GE case, the control system algorithms are computed in a dual core DSP-based hardware, designed by CINERGIA, allowing a multitask execution of the regulation systems for the Active Rectifier and the Inverter output.
  • Page 14 GE+ ACDC Installation and operation manual v11 Setpoint Σ PR ω0 PWM x3 generator PR ω1 PR ω2 PR ω3 Feedback Therefore, the main characteristics of the Resonant Control applied are the ones listed below: Control loop rate of 15 kHz. Harmonics controlled up to 760Hz* 15 control loops executed per phase.
  • Page 15 GE+ ACDC Installation and operation manual v11 Where: A: EUT current (EUT is connected to the phase W of GE) B: GE output voltage U C: GE output voltage U D: GE output voltage U E: Instant at which the EUT is started. F: Fundamental harmonic of U (shown in the FFT) G: 15...
  • Page 16 GE+ ACDC Installation and operation manual v11 Both in voltage mode and current mode, the equipment is regulated for the limits imposed by the interface: Max Current, Min Current, Max Voltage and Min Voltage. In case that those limits are not configured, the equipment is protected by the natural limits (110% of the nominal current).

  • Page 17: Installation And Wiring Recommendations

    We advise you to follow these instructions carefully and to contact us in case of any question or comment. If the commissioning of the unit has been agreed with CINERGIA or one of our distributors, please follow the recommendations in this document and once the installation is finished contact us to agree an appointment.

  • Page 18: Isolation Transformer

    CINERGIA standard units are not galvanically isolated from the grid. Therefore, the output terminals (including the negative rail and the neutral) are referenced electrically to the grid neutral. CINERGIA offers an Isolation Transformer as an optional for those test setups that require galvanic isolation. The necessity of an Isolation Transformer depends on the Equipment Under Test and the electrical installation of the laboratory (TT, TN or IT system).
  • Page 19 GE+ ACDC Installation and operation manual v11 19 / 121...

  • Page 21: Case External Isolation Transformer With Or Without Inrush Current Limitation Box

    3 phase + neutral + PE. The size of PE cable will depend on local regulations and electrical system (TN, TT, IT, etc…) The above recommended protections are useful in case that CINERGIA provides the transformer. In case that a third party supplies the transformer, please follow the recommendations from the transformer manufacturer.
  • Page 22 3 phase + neutral + PE. The size of PE cable will depend on local regulations and electrical system (TN, TT, IT, etc…) The above recommended protections are useful in case that CINERGIA provides the transformer. In case that a third party supplies the transformer, please follow the recommendations from the transformer manufacturer.

  • Page 23: Configuration Values Of Protection And Wires

    GE+ ACDC Installation and operation manual v11 3.5. Configuration values of protection and wires Nomenclature Description Characteristics CNG7.5 CNG10 CNG15 CNG20 CNG 30 CNG40 CNG50 CNG 60 Mains RCCB Rated residual current (for each 300mA to 500mA type 100A equipment) B1 and B2 Input/Output 4P –...
  • Page 24 GE+ ACDC Installation and operation manual v11 Nomenclature Description Characteristics CNG80 CNG100 CNG120 CNG160 CNG 200 Mains RCCB Rated residual current (for each equipment) 300mA to 500mA type B 125A 160A 200A 250A 315A B1 and B2 Input/Output MCB type C 4P –...

  • Page 25: Configuration Values Of Suitable Terminal Metric

    GE+ ACDC Installation and operation manual v11 3.6. Configuration values of suitable terminal metric Cables from electrical installation must have the suitable terminal metric value to connect on: Nomenclature Characteristics CNG7.5 CNG10 CNG15 CNG20 CNG 30 CNG40 CNG50 CNG 60 CNG80 CNG100 CNG120...

  • Page 26: Installation

    GE+ ACDC Installation and operation manual v11 4. INSTALLATION 4.1. Important safety instructions As a device with class l protection against electric shocks, it is essential to install a protective earth wire (connect earth ). Connect the protection earth wire to the terminal (X5) before connecting the grid to the grid emulator input.
  • Page 27 GE+ ACDC Installation and operation manual v11 Local front panel: Front view (with the door open): Detailed view of the front protections and switches: 27 / 121...
  • Page 28 GE+ ACDC Installation and operation manual v11 Detailed view of the signal connectors: General view (with the front door closed): 28 / 121...
  • Page 29 GE+ ACDC Installation and operation manual v11 Protection elements (Q*):  (Q1) Input thermal-magnetic circuit breaker or disconnector according to power of the equipment.  (Q2) Output disconnector.  (Q4) AC/DC switch.  (Q5) Parallel connection switch.  (Q8) Bipolar/unipolar switch. Connection elements (X*): ...

  • Page 30: Equipment Reception

    On receiving the device, make sure that the power supply has not suffered any damage during the transportation. Otherwise, make all pertinent claims to the supplier or to CINERGIA. The packing of the device consists of a wooden palette, a cardboard or wooden packaging (depending on the case), expanded polystyrene corner pieces, a polyethylene sleeve and bands;...
  • Page 31 GE+ ACDC Installation and operation manual v11 facilitate the operations of maintenance of the equipment or the interventions of the technical service in case of breakdown. Front view: Recommendable minimum distance, 1 m. Top view: Recommendable minimum distance, 1 m. Recommendable minimum distance, 1 m.

  • Page 32: Connection

    GE+ ACDC Installation and operation manual v11 The equipment may be installed in any place if the safety and ventilation requirements are fulfilled. The power supply includes 2 levelling elements located near the front castors, which serve to immobilize the unit once it is in place. To adjust the level, open the front door of the cabinet and proceed as follows: By hand, loosen the levelling elements by turning them anticlockwise until they touch ...

  • Page 33: External Isolation Transformer

    (R’, S’, T’, N’) to the input terminals (X1), (X2), (X3) and (X4) of Cinergia equipment. The connections in the transformer are the followings: The following image is a simple schematic connection of the transformer between the grid and...

  • Page 34: Output Connection, Terminals (X6 To X10 And X20 To X22)

    It is possible to use both independent power supplies as Positive or Negative power supplies. 4.4.5. Emergency Power Off terminals (X12) (EPO) CINERGIA units are equipped with a local Emergency Stop pushbutton at the front panel. When this local pushbutton is pressed, the unit will be completely switched off by disconnecting the main contactors at the input and at the output.
  • Page 35 GE+ ACDC Installation and operation manual v11 WARNING: the internal circuitry will be damaged if an external power supply is connected to X12 (J15) EPO terminals. Do not connect an external power supply or active signal. Only Normally Closed dry contact is allowed. The following picture shows the 2 different connection points in X12, which are X12_A and X12_B.

  • Page 36: Output Signal Of Local Emergency Stop Pushbutton State (Epo Output)

    GE+ ACDC Installation and operation manual v11 Connection to serialize the Emergency Power Off sequence (option c) 4.4.6. Output signal of local Emergency Stop pushbutton state (EPO OUTPUT) WARNING: the internal circuitry will be damaged if any external power supply is connected to X12 (J15) EPO terminals.

  • Page 37: Communications

    GE+ ACDC Installation and operation manual v11 4.4.7. Communications There are several connectors dedicated to communications, which are listed below: (Optional) Connector for RS485/RS232 communications (X11): DB9 connector to be used when Modbus RS485 option is chosen. It is not possible to have both type of communication protocols running at the same time.

  • Page 38: Analogue Inputs And Outputs (Aio)

    GE+ ACDC Installation and operation manual v11 DIGITAL INPUT (Operation of the equipment): PIN 7: INPUT RESET. Makes a RESET to the equipment. PIN 8: INPUT RUN/READY. Changes from RUN to READY and vice versa. PIN 10: INPUT ENABLE/DISABLE. Changes from ENABLE to DISABLE and vice versa. PIN 13: INPUT TRIGGER (GE).
  • Page 39 GE+ ACDC Installation and operation manual v11 The analogue inputs accept a voltage range from -10Vdc to +10Vdc (referenced to GND_ADC). The analogue output voltage range values are from -10Vdc to +10Vdc (referenced to GND_ADC). The output analogue values are used to read the internal value of the equipment. Each output analogue is configurable by the user.
  • Page 40 GE+ ACDC Installation and operation manual v11 Reactive Alarm_OverLoad_150_POS Alarm_OverLoad_150_POS Output Frequency not used Limit_max_freq_out Output Table 1 Range and configuration of the output analogue The equipment has 6 analogues inputs to send SETPOINT values to the equipment in ANALOG machine setpoints control.
  • Page 41 GE+ ACDC Installation and operation manual v11 -10V MODE ANALOG VARIABLE MINIMUM MEDIUM MAXIMUM Voltage U RMS setpoint not used max voltage AC Voltage Phase angle U -359º 359º Voltage Voltage V RMS setpoint not used max voltage AC Independent Bipolar source Voltage Phase angle V...
  • Page 42 GE+ ACDC Installation and operation manual v11 Resistance W not used 10000 Inductance W not used 10000 Voltage RMS setpoint not used max voltage AC Voltage Parallel Bipolar source Phase angle -359º 359º Current Current RMS setpoint min current AC max current AC Parallel Bipolar...
  • Page 43 Table 2 Range value of each input analogue depends on the control of the equipment (AC/DC, independent/parallel, V/I/P/R, Bipolar/Unipolar) The table above is valid for all the equipment of CINERGIA (AC and DC current, voltage, power and impedance control) 43 / 121...

  • Page 44: Operation

    GE+ ACDC Installation and operation manual v11 5. OPERATION 5.1. Safety Before operating the equipment, check that the Protective Earth is properly connected. Check out the electrical installation in both sides (input and output) of the cabinet. All wires shall be connected and secured before proceeding to the power supply start-up.

  • Page 45: Initialization

    GE+ ACDC Installation and operation manual v11 From any Initialization Error EMCY Reset? sequence? Standby Enable? Precharge Ready Run? Enable? Run? Enable? 5.2.1. Initialization During the initialization, the power supply control system checks the presence of all internal components and the embedded PC loads the operating system. No voltage is present at the DC bus and the IGBTs PWMs are completely stopped.

  • Page 46: Precharge

    GE+ ACDC Installation and operation manual v11 The transition from the Standby state is the Enable signal or, in case of errors, a Fault signal. The Enable signal will bring the State Machine to Precharge and eventually to the Ready state. If an error is detected the power supply will go into Alarm state.

  • Page 47: Operation Modes

    In AC mode, the GE can configure a value of Resistance of the grid (0 to 1ohm). The following figure illustrates how the CINERGIA converter works in all four quadrants. It explains where the equipment behaves as a source and where as a load:...

  • Page 48: Constant Voltage (Cv)

    GE+ ACDC Installation and operation manual v11 Before operating the equipment, check that all LIMITS from the equipment are correct. Please take care that CNG equipment are bidirectional, this means that the equipment can consume or inject current. The equipment can operate as a source or as a load.

  • Page 49: Constant Current (Cc)

    GE+ ACDC Installation and operation manual v11 Parameters and limits (DC mode) In CV mode, the GE AC&DC wrks as a DC power supply: Parameter Allowed range of values Unipolar voltage [0 , +750] Bipolar voltage [-350 , +350] 5.3.2. Constant current (CC) In CC mode, the user may modify the values of the following parameters as long as they are within the specified range (only available in DC mode): Parameter...
  • Page 50 GE+ ACDC Installation and operation manual v11 VII. Parameters and limits In FG mode, the user can modify the value of the following fault general parameters as long as it is within the specified range: Parameter Allowed range of values Fault duration Minimum: 100ms Fault delay (β) –...
  • Page 51 GE+ ACDC Installation and operation manual v11 Additionally, in the FG mode, each kind of fault has its own parameters to be modified by the user. These parameters are listed below: Parameters of Voltage Dip, Over/Under Voltage Allowed range of values Voltage of fundamental harmonics of phases U, V, W 0-200% 0% means 0V...
  • Page 52 GE+ ACDC Installation and operation manual v11 Parameters of Frequency variation Allowed range of values Fundamental frequency of phases U,V,W Minimum frequency – Maximum frequency FadeIn Ramp [Hz/s] 0.01-1000 FadeOut Ramp [Hz/s] 0.01-1000 Parameters of Flicker Allowed range of values Voltage of fundamental harmonics of phases ±...
  • Page 53 GE+ ACDC Installation and operation manual v11 Frequency Variation. Freq Var, Fault Duration, Fault Start Angle, Freq, FadeIn Ramp, FadeOut Ramp Example: Freq Var,200,0,60,10,0.01 Flicker. Flicker, Fault Duration, Fault Start Angle, Voltage %, Freq, FadeIn Ramp, FadeOut Ramp Example: Flicker,10000,0,50,20,100,0.1 There are also another two more type of rows to be introduced in the file: Grid Configuration.

  • Page 54: Independent Branch Control

    It is very important to be very aware of what is being connected in the output of the Cinergia equipment. It will be able to work in different modes for each channel (voltage or current source). It is in the user responsibility to use this mode properly.

  • Page 55: Power Amplifier

    GE+ ACDC Installation and operation manual v11 5.3.7. Power amplifier Power amplifier is optional and it has an additional cost. The GE converter can work as a voltage amplifier from the analogue inputs. It means that the waveform in the analogue input will appear in the output of the converter. For instance, if the analogue input is a square waveform, the output of the GE will be a square voltage waveform.

  • Page 56: Ac (Q4 In Ac Position)

    GE+ ACDC Installation and operation manual v11 Please remember to disconnect the equipment before modifying the connection mode. The following diagram illustrates the different operation connection modes: 5.4.1. AC (Q4 in AC position) Three-phase mode 56 / 121...

  • Page 57: Dc (Q4 In Dc Position)

    GE+ ACDC Installation and operation manual v11 Parallel mode Please note that working with a single-phase grid requires a short circuit between the output terminals in the Cinergia converter. X6, X7 and X8 must be short circuited. 5.4.2. DC (Q4 in DC position) Bipolar mode...
  • Page 58 GE+ ACDC Installation and operation manual v11 III. Unipolar parallel mode In case of working in parallel mode the user must use 3 cables in the positive outputs (X6, X7 and X8) or use a bridge which put together all 3 phases. The negative outputs (X20, X21 and X22) must also be bridged in case of using only one cable.

  • Page 59: Working With The Equipment

    GE+ ACDC Installation and operation manual v11 5.5. Working with the equipment Before powering the cabinet check step by step the following items:  The power supply output (Q2) must be disconnected:  The grid side of the converter is protected by a thermal-magnetic circuit breaker. ...

  • Page 60: Start-Up

    GE+ ACDC Installation and operation manual v11 5.5.1. Start-up Before powering the cabinet wait at least 15 seconds to be sure that the PC embedded inside the equipment starts correctly. Before operating the equipment, check that all LIMITS from the equipment are correct.

  • Page 61: Stop

    GE+ ACDC Installation and operation manual v11 Please keep in mind that not all EUTs are compatible with all operation modes. If the power supply is operated as a voltage source, please do not connect any other voltage sources at the output. When the equipment is turned off, the user must wait at least 15 seconds before turn it on again.

  • Page 62: Ready

    GE+ ACDC Installation and operation manual v11 NEVER connect or disconnect the cables while the power supply is in this state. 5.5.2.3. Ready This type of stop is recommended if the power supply will be stopped for a short time. The DC link is kept charged and the power supply is ready to run.

  • Page 63: Alarms

    Check that room temperature does not exceed 50ºC. ABR/INV Alarmed One of the two control boards Reset alarms has an alarm. SD Error Control Board Reset the equipment. Contact damaged. Cinergia for technical support if this alarm persists. 63 / 121...

  • Page 64: Alarms Reset

    GE+ ACDC Installation and operation manual v11 Heart Beat Communications cable Contact Cinergia in order to isolate broken or there is a control the problem. board without response. Mains lost There has been an interruption Check the mains and the grid in the mains.
  • Page 65 2. Send a Not enable and Not run signals (note: this step is done automatically when the user is interfacing the power supply by the LCD or by the software provided by Cinergia). 3. Proceed as a standard start-up process by deactivating the emergency stop (pull out the button).

  • Page 66: Local Touchscreen Control Panel

    To create a friendly navigation of the LCD, Cinergia has designed a tab distribution ubicated in the right of the screen. There is also an upper bar, which has the purpose to inform and modify the control operation and mode as well as the status of the equipment.

  • Page 67: Keyboard

    GE+ ACDC Installation and operation manual v11 By means of the bar in the upper side of the touchscreen, the user is constantly aware and can modify the following variables by pressing the touchscreen: Control of the equipment. The local touchscreen will go to the settings options where the user can decide which is the control of the equipment (Modbus, LCD or Digital) Working connection mode.

  • Page 68: Lcd Tabs Distribution

    GE+ ACDC Installation and operation manual v11 The use of the keyboard is very simple: introduce the number normally. It can be written in positive, negative and with decimals depending on which is the introducing parameter. For example, if the user is changing the IP address, the number cannot be negative or with decimals, but if the introduced number is a current setpoint, the number can be positive, negative and with decimals.

  • Page 69: Supervision

    GE+ ACDC Installation and operation manual v11 6.3.1. Supervision Information tab. It shows the main variables of the inverter: voltage, current and power. You can choose between bars or table visualization. 1. Bar visualization. Change screens using left and right arrows to see voltage and current or power.

  • Page 70: Scada

    (the addition of all phases). 4. Frequency in the output (EUT) side. If the Cinergia equipment is an AC voltage source, the output frequency will be chosen within the specified allowed range (10 to 400Hz) whereas if the equipment is an AC current source, the frequency will be read from the AC voltage source connected in the EUT side.

  • Page 71: Alarms

    GE+ ACDC Installation and operation manual v11 5. Power diagram. This indicator displays the total output power of the converter. It will move to the right or to the left depending on the behavior of the equipment (load or source). By touching any part of the Scada screen it will appear information about the power and temperature.

  • Page 72: Plots

    GE+ ACDC Installation and operation manual v11 1. If any alarm occurs, the red symbol of emergency will appear on the right-top of the LCD touchscreen. 2. To reset the alarms and continue working with the equipment, press the Reset button. The alarm state will disappear as long as the alarm situation has been solved and the screen of alarms will be cleaned.

  • Page 73: Settings

    GE+ ACDC Installation and operation manual v11 1. Select the items you want to be in the plot. The available parameters are output voltage, current and power for each phase. The selected items are illuminated in green. To deselect them, press the left square again and they will be not illuminated anymore. 2.
  • Page 74 It means, for example, that phase U can be in voltage mode and V and W in current mode, which can be very useful because the same Cinergia equipment can work as a voltage and current source at the same time.
  • Page 75 PID can be activated with this button to get a balance in the current flowing in both voltage source channels. HW Check For now, this is an internal option of Cinergia and is in development process to be available for the user as soon as possible. Config.
  • Page 76 Setpoints Control. As it is explained before, the first one (1) allows the user to control the equipment status. This control can be done through these different possibilities: a. Modbus. Send the control signals via the interface delivered by Cinergia. b. LCD. Control the equipment state using the LCD touchscreen. Using this option, a blue lock will appear on the top left of the touchscreen.
  • Page 77 While there is a selected control, the other two controls are not available. The Machine Setpoints Control (2) is separated in two options: a. Modbus. The setpoints are sent using the interface delivered by Cinergia. b. Analog. The setpoints are sent using the DB15 connector gathered in X15.
  • Page 78 About It shows the basic information of the converter. It contains the address and the webpage of Cinergia as well as the device information. The user can consult it by touching the arrows on the right of the screen. 78 / 121...
  • Page 79 This is the menu where the user can visualize all the connections parameters. To know more about these parameters, please read the document Connecting Cinergia units to PC. To change the values of the following parameter, touch the number and the LCD will go to the keyboard explained in the chapter 3.2.
  • Page 80 GE+ ACDC Installation and operation manual v11 3. Slave ID. If the connection of the Cinergia equipment is not in serial (RS485 or RS232), this parameter is not important because the Modbus is based in a point-to-point communication. When the equipment is using a serial communication, set this parameter according to the other equipment in the same net.
  • Page 81 GE+ ACDC Installation and operation manual v11 Once the four red crosses are touched, the touchscreen will go back to the previous menu (Settings/config). VII. Limits The user can define the limits of the equipment in this menu. The converter has its own factory limits, but it is possible to introduce new ones.
  • Page 82 GE+ ACDC Installation and operation manual v11 The LCD touchscreen will freeze or unfreeze (illuminate) the available parts where the user can introduce the parameters depending on the equipment (AC or DC, voltage source or current source and parallel or independent connection) Each limit window is practically the same, the main difference are the values to introduce.
  • Page 83 GE+ ACDC Installation and operation manual v11 mode, so the available limits to introduce are the current ones while the voltage values are frozen and the user cannot touch them. To change the values, touch the number and the keyboard explained in the chapter 3.2. Keyboard will appear.
  • Page 84 GE+ ACDC Installation and operation manual v11 The LCD touchscreen will freeze or unfreeze (illuminate) the available parts where the user can introduce the parameters depending on the equipment (AC or DC and voltage source or current source) Each ramp window is practically the same, the main difference are the values to introduce. For example, in AC there are differences between each channel whereas in DC, each ramp is for all three channels at the same time.

  • Page 85: Operational Panel

    GE+ ACDC Installation and operation manual v11 6.3.6. Operational Panel It is possible to view the voltages and the currents in the output of the converter at any time by pressing the left-down button. 1. By touching this button, the LCD will show a supervision window without being important the actual tab.
  • Page 86 GE+ ACDC Installation and operation manual v11 b. The setpoints will appear with bars and can be modified by touching this bar until it reaches the desired value or can also be modified touching the number above the bar. It will go to the keyboard explained in the chapter 3.2. Keyboard. c.

  • Page 87: Digital Control

    GE+ ACDC Installation and operation manual v11 7. DIGITAL CONTROL The Cinergia converter can be controlled using Digital Inputs and Outputs. INPUT/OUTPUT NAME FUNCTION Turns on when the equipment is in READY and blinks when the Output OUTPUT LED READY...

  • Page 88: Remote Communications

    GE+ ACDC Installation and operation manual v11 8. REMOTE COMMUNICATIONS CINERGIA’s power supplies can be operated and supervised remotely through an Ethernet communications bus. An internal embedded PC, with CINERGIA’s proprietary software, allows the exchange of information between the internal CAN bus and the external Modbus TCP/IP (Ethernet).

  • Page 89: Human Machine Interface

    Connect a standard RJ45 Ethernet cable to terminal X13. The unit can be connected directly either to a computer or to a router (wired or wireless). If the CINERGIA unit is connected through a router, several computers could be connected to the unit at the same time.

  • Page 90: Show Operational Button

    Reset. Reset button turns the equipment into Standby state. Before going to Run state, please be sure that all the connections between the EUT and the Cinergia equipment are ready. C: Information about of Active Rectifier and Inverter status: Initialization. The converter control system checks the presence of all internal components and the embedded PC loads the operating system.
  • Page 91 In Current, Power or Impedance mode, the equipment controls current and it requires a voltage source connected in the output of the Cinergia equipment. The voltage source must be the first to be turned on. Once the Cinergia converter reads the voltage in the inverter, the Run state can be applied.

  • Page 92: Distribution Of The Interface

    GE+ ACDC Installation and operation manual v11 9.2. Distribution of the interface To create a friendly navigation of the interface, Cinergia has designed a Tab Dialog distribution, in which each tab has one of the following purposes: Further information of each kind of tab can be found in the following sections.

  • Page 93: Operation

    GE+ ACDC Installation and operation manual v11 9.2.1. Operation A: Connection mode. Informs about the connection: AC Independent/Parallel Bipolar (note that AC unipolar is not allowed) DC Independent/Parallel Unipolar DC Independent Bipolar (note that parallel bipolar is not allowed) The connection mode can only be modified by changing the switches in the front panel.
  • Page 94 GE+ ACDC Installation and operation manual v11 Follow the steps 1, 2 and 3 of the above picture to reach the LCD touchscreen submenu that enables the configuration of the Machine Control and Setpoints Control. Once the user is in the third step, A part is for the Machine Control (Enable, Disable, Run, Ready and Reset) and B part is for the setpoints (the equipment will send the setpoints only in Run state).
  • Page 95 Modbus TCP. Uses Modbus protocol and the port 502. Connect a RJ45 ethernet cable to the terminal X15. TCP Socket. Uses an internal Cinergia protocol and the port 8989. Connect a RJ45 ethernet cable to the terminal X15. Modbus Serial Port. Uses RS485 or RS232 protocol. Connect a DB9 cable to the terminal X11.

  • Page 96: Alarm

    GE+ ACDC Installation and operation manual v11 9.2.2. Alarm In this tab, the alarms of each converter (active rectifier and inverter) are shown. When there is an alarm, the light turns into red. A: Active Rectifier alarms. B: Inverter alarms. C: Alarms history.

  • Page 97: Supervision

    GE+ ACDC Installation and operation manual v11 2. When the equipment has any alarm, it is reflected in the status. 3. Press Reset to reach the standby state (no alarms). 9.2.3. Supervision The supervision is an informative tab is where the user is able can see all the values of the converter.
  • Page 98 AC Operation This subtab allows the user to send all the AC parameters to control the Cinergia converter in AC mode: voltage setpoints, harmonics, phase angles, frequency, grid resistance and ramps. A: Part of the subtab to introduce all the parameters to be sent to the converter.
  • Page 99 GE+ ACDC Installation and operation manual v11 whereas the other columns are a percentage of the first column. From the 3 until the 11 harmonic, the percentage can go from 0% to 100% (0 to ±1) whereas 13 and 15 can reach 50% (0 to ±0.5).
  • Page 100 GE+ ACDC Installation and operation manual v11 AC Faults Before introducing any fault to the emulated grid, some grid must be created and there are two ways to do so: from the “AC Operation” tab (chapter 1.5.1) or the “AC Faults” tab (explained in this chapter).
  • Page 101 GE+ ACDC Installation and operation manual v11 C: Frequency Variation configurations. This fault makes the frequency grid to reach the introduced frequency according to the introduced ramps. The minimum and maximum frequency are the limits of the converter. If the duration of the fault (introduced in window G) is not long enough, the frequency will not reach the introduced one.
  • Page 102 GE+ ACDC Installation and operation manual v11 ramps for all three elements of each phase. The buttons Add Step and Config Step are explained at the point H of this chapter. G: General configurations of the fault. Set the duration of any fault and the starting angle referenced at the U channel.
  • Page 103 GE+ ACDC Installation and operation manual v11 A: This table shows all the values that refer to the configuration of the harmonics and it is distributed in the following way: The user can write the desired values on this table of the interface to create a harmonic file to be sent or saved as it is explained in the point E of this chapter.
  • Page 104 GE+ ACDC Installation and operation manual v11 C: This graph is behaving as the one before (B), but it draws the waveform showing how the harmonics will look like when the user uses an oscilloscope in the output (EUT side). D: Theoretical values are very useful to know which is the maximum output voltage, as well as the peak, the crest factor and the total harmonic distortion (THD).
  • Page 105 GE+ ACDC Installation and operation manual v11 105 / 121...
  • Page 106 GE+ ACDC Installation and operation manual v11 9.2.5. DC DC Unipolar This subtab allows the user to send all the DC parameters to control the Cinergia converter in unipolar connection: current, power, impedance, voltage setpoints, virtual resistances and limits. Please read the Operation Modes document to know more about how to connect the equipment in unipolar.
  • Page 107 GE+ ACDC Installation and operation manual v11 All setpoints windows have the actual value right beside them. In this way, the user can know it without being necessary the supervision tab. 5. Set the resistance value to create a voltage drop. It is configurable for each channel and for independent and parallel mode.
  • Page 108 DC Bipolar This subtab allows the user to send all the DC parameters to control the Cinergia converter in bipolar connection: current, power, impedance, voltage setpoints, virtual resistances and limits. Please read the Operation Modes document to know more about how to connect the equipment in bipolar.
  • Page 109 GE+ ACDC Installation and operation manual v11 3. Set the impedance setpoints to be sent and its ramp. The allowed maximum and minimum values are 1000 and 0.8 Ω. The ramps go from 0 to 1000 Ω /ms. The user must calculate the appropriate value or resistance to get the desired current.
  • Page 110 GE+ ACDC Installation and operation manual v11 Once the limits are ready, press Send Limits. The button Refresh Limits will show in the windows the limits that the equipment has in that moment. When the converter is switched off and on again, these limits will be erased and substituted for the factory ones.
  • Page 111 GE+ ACDC Installation and operation manual v11 1. Voltage setpoints configuration where the user can introduce values for the global configuration (parallel), channel U, V and W and the ramp. 2. Current setpoints configuration where the user can introduce values for the global configuration (parallel), channel U, V and W and the ramp.
  • Page 112 GE+ ACDC Installation and operation manual v11 o Save test. There is the possibility to save the created sequence. By pressing this button, the user will save the existent sequence in the B window in a CSV file in the desired location and name. o Delete row.

  • Page 113: Limits

    GE+ ACDC Installation and operation manual v11 9.2.6. Limits The user can define the limits of the equipment in this tab. The converter has its own factory limits, but it is possible to introduce new ones. The condition for these new limits is that they must be lower (in case of maximum limits) or higher (in case of minimum limits) than the factory ones, otherwise the equipment will introduce the factory limits.
  • Page 114 GE+ ACDC Installation and operation manual v11 2. Current limits. The user can set the maximum and minimum limits for each phase. These current limits are used in current mode (positive and negative) and in power mode (positive but not negative). 3.
  • Page 115 GE+ ACDC Installation and operation manual v11 DC Limits The interface will freeze or unfreeze (illuminate) the available parts where the user can introduce the parameters depending on the connection mode (parallel or independent). A: Voltage and current limits section. 5.
  • Page 116 GE+ ACDC Installation and operation manual v11 Each part (A, B and C) has two different buttons explained in the following lines. It is important that, for example, voltage limits must be sent, the buttons to use are the ones in the A part.

  • Page 117: Alarms Configuration

    GE+ ACDC Installation and operation manual v11 When the converter is switched off and on again, these limits will be erased and substituted for the factory ones. It is possible to save limits in the equipment in the EEPROM memory, but a password is required 9.2.7.
  • Page 118 GE+ ACDC Installation and operation manual v11 o Default Values. The user can define default values that will remember the equipment as long as it is switched on and lower than the Factory Values. o Factory Values. The equipment has its own factory values depending on the rated power.

  • Page 119: About

    9.2.8. About This tab shows the characteristics of the equipment. A: Extras of the converter. By entering the password delivered by Cinergia, it is possible to unblock the available extras. It has an additional cost. B: Basic description parameters of the equipment.

  • Page 120: Warranty And Maintenance

    (1) year from the Ex Works delivery date. If a purchased CINERGIA product becomes defective because of a faulty component or manufacturing, at any time during its standard warranty period, CINERGIA shall provide one of the following solutions: •...

  • Page 121: Claim Procedure

    If defect of malfunction is detected, please proceed as follows: • Immediately notify in writing CINERGIA by submitting a brief report describing the type of fault detected and all the data contained in the product data plate, attaching a copy of the purchase invoice/receipt.
