Page 3: Product Description
Product Description DC-LINK-RE1 is a optimized type-selection based on DC-LINK-LR1 receiver antenna. There are 5 ports high gain panel antenna instead of previous Spcs flag antennas, which can improve the communication distance from 300m to 600m under the same test standard, and also can largely decrease the inte... -
Page 4: Performance Parameters
Performance Parameters Electrical Performance lndicators Model DC-LINK-LR1 plate Frequency Range 5.0-5.9GHz Gain 14±0.5dBi (F/B Ratio) >25dB Isolation >26dB Horizontal Beam Width 40±5 ° Vertical Beam Width 40±5 ° V.S.W.R .;;;2.0 Polarization 5 ports: 3 ports vertical,2 ports±45 ° Maximum Power 100W lmpedance 50ohm... - Page 9 Trouble shooting and using notice (1) lf no video connection within 3m to 10m, then check the video input and output, as it is not caused by the antenna; (2) lf poorer video quality from 100m to 600m, please check whether the suites are set up as requested, if meet the requirements, then check if coaxial cable is damaged or port has dirty or stains, when working normally, there should be 4 to 5 RSSI LEDs lit on the receiver side;...
- Page 10 DwarfConnection OG Münzfeld 51, A-4810 Gmunden, Austria office@dwarfconnection.com www.dwarfconnection.com Errors and omissions excepted...
