- Page 1 PHYSITEMP INSTRUMENTS INC 154 Huron Avenue Clifton NJ 07013 USA Tel: 973-779-5577 Fax: 973-779-5954 OPERATING MANUAL TCAT-2AC CONTROLLER EB FRONTIS EBTCAT-2 0204...
- Page 4 Appendix 1: ADJUSTING CONTROL PARAMETERS...
-
Page 5: Maintenance, Warranty And Service
12 months from date of shipment. Repair or replacement will be made at no charge at the discretion of Physitemp if the defect is not the result of misuse or abuse. Physitemp accepts no consequential liability for delay in delivery, alleged faulty performance of the product or any other cause. - Page 6 SPECIFICATIONS TCAT-2AC Operating Range: -200°C to +400°C Digital Readout Resolution: 0.1°C AC Input Voltage: 100 - 130VAC or 200 - 240VAC, 50 or 60Hz user selectable Fused input module, (6.3Amp, 5 x 20mm fuse) Output: Via 2 controlled auxiliary AC sockets Size: 7 3/8”wide x 10”...
- Page 7 The two front feet can be flipped down to adjust the viewing angle. Rotate feet down and towards the front until they lock in position. To return to original position, pull down slightly, then rotate back. Serial Number: PHYSITEMP INSTRUMENTS INC 9003 154 Huron Avenue Clifton, NJ 07013 USA...
-
Page 8: Rear Panel Connections
Connect a suitable load (500 Watts maximum) to either of the auxiliary AC outlets on the rear panel of the TCAT-2AC using the auxiliary AC adaptor cable if necessary. Insert a type T thermocouple feedback sensor into the blue socket. Ensure that the sensor tip is securely attached to the load at an appropriate location. -
Page 9: General Description
The TCAT-2DF combines features of both the instruments described above. A type T thermocouple probe is used as the temperature feedback sensor and any of Physitemp’s extensive line of probes can be used for this application. - Page 10 OPERATING MANUAL TCAT-2AC CONTROLLER CONTENTS SECTION PAGE GENERAL DESCRIPTION UNPACKING AND CHECKING CONTENTS SETTING UP THE TCAT-2AC OPERATING INSTRUCTIONS SPECIFICATIONS MAINTENANCE, WARRANTY AND SERVICE Appendix 1 Adjusting Control Parameters EB TCAT-2AC 04/23/04...
