Bouncer
User's Manual
Model______________
JNC3600
WARNING
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
Maximum user weight 60 lbs.
AGES
3 to 7
IMPORTANT
CAUTION: Adult Assembly
Required
Trampoline is susceptible to winds.
WARNING:
Be sure tosecure your trampoline.
Wind Damage is not covered in the
CHOCKING HAZARD--
Small parts
warranty of your trampoline
Not for children under 3 years
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Skywalker JNC3600
Summary of Contents for Skywalker JNC3600
- Page 1 Bouncer User’s Manual Model______________ JNC3600 WARNING Read all precautions and instructions in this manual before using this equipment. Save this manual for future reference. Maximum user weight 60 lbs. AGES 3 to 7 IMPORTANT CAUTION: Adult Assembly Required Trampoline is susceptible to winds.
-
Page 2: Table Of Contents
JNC3600 Model_____________ A serial decal is found on one of the bouncer tubes. CONTENTS Important Precautions...........3 Warning Label Placement........4 Before You Begin..........4 Trampoline Safety Information......5 Methods of Accident Prevention......6 Use and Instructional Material......7 Part Identification Chart........8 Exploded Drawing and Parts List......9-10 Ordering Replacement Parts.........10... -
Page 3: Important Precautions
USE INSTRUCTIONS WARNING: To reduce the risk of serious injury, read and follow all of the warnings, precautions, and instructions in this manual before you use the trampoline. Warnings and instructions for care, maintenance, and use of this trampoline are included to promote safe, enjoyable use of this equipment. -
Page 4: Warning Label Placement
Tie the trampoline frame down to the ground using ropes and stakes (not included). method to protect your trampoline and the surrounding environment during high winds is to store indoors. BEFORE YOU BEGIN Thank you for choosing your Skywalker Trampolines brand Trampoline. Skywalker Trampoline brand Trampolines are designed and crafted to provide many years of fun and fitness. -
Page 5: Trampoline Safety Information
TRAMPOLINE SAFETY INFORMATION In trampoline use, as in all active recreational sports, participants can be injured. However, there are steps that can be taken to reduce the risk of injury. In this section, primary accident patterns are identified and the responsibilities of supervisors and jumpers in accident prevention are described. -
Page 6: Methods Of Accident Prevention
METHODS OF ACCIDENT PREVENTION The Supervisor's Role in Preventing Accidents It is the responsibility of the supervisors of trampoline users to provide knowledgeable and mature supervision. They need to know and enforce all of the rules and warnings printed in this manual to minimize the likelihood of accidents and injuries. -
Page 7: Use And Instructional Material
Climb onto and off of the trampoline. Do not jump onto or off of it. Do not use the trampoline as a springboard to jump to other objects or places. For additional information regarding equipment, contact Skywalker Holding, LLC. For additional regading skill training, contact a trainer certification organization. -
Page 8: Part Identification Chart
Part Identification Chart(not to actual scale)----Model No. JNC3600 Use below drawings to identify all the parts. two holes Left Foam (1 pc) Left Handle (1 pc) Right Handle (1 pc) Right Foam (1 pc) Legs welding(1 pc) Leg (3 pcs) -
Page 9: Exploded Drawing And Parts List
Exploded Drawing----Model No. JNC3600 12 11 12 11... -
Page 10: Ordering Replacement Parts
JNC3600 Key No. Qty. Description Left Handle Right Handle Left Foam Right Foam Legs welding Spacer Mat with Pad Elastic with ball M6x30mm Bolt M6 Nut M6 Washer M6x60mm Bolt M3x10mm Screw M6x33mm Bolt Sound game Battery cover Screw Driver Wrench User’s Manual... -
Page 11: Assembly
ASSEMBLY 1. Insert the Left Handle(1) into Left Foam(3) as shown A. Then insert the Right Handle(2) into Right Foam(4) two holes as shown B. Notice: If the foam is pre-installed on the handle, go to step 2. 2. Insert the Right Handle(2) with foam into Left Handle(1) with foam as shown, secure with a M6x32mm Bolt(10), M6 washer(12) and a M6 Nut(11). - Page 12 5. Locate the last leg(6) and two Spacers(7) as shown, secure with M6x60mm Bolts(13), M6 Nuts(11) and M6 Washers(12). Note: Tighten all the nuts. 6. Insert the assembled handle into the Leg welding(5) wire as shown, secure with M6x33mm Bolts(15), M6 Nuts(11) and M6 Washers(12).
- Page 13 Attach the Mat with pad(8) to the frame by Elastic with ball(9). Attach two Elastics with ball(9) to each corner of frame as shown to hold the mat in place. (only one corner is shown) Attach the remaining 24 Elastics with ball in an even pattern (not one directly after the other) until all Elastics with balls have been placed around the frame.
-
Page 14: Assembly
a. Connect the sound game from the handle to the sound box. b. Assemble the Sound Game(16) to the handle with M3x10mm Screws(14) as shown. c. Connect the other end of the sound wire from the leg to the wire on the jumping mat. Note: Do not turn the Sound game. -
Page 15: Care And Maintenance
WARNING TRAMPOLINE CARE AND MAINTENANCE Care To avoid damage to the trampoline, do not allow pets or animals inside the enclosure. The trampoline is intended to be used by one person at a time who weighs no more than 60 pounds. The user should be either barefoot, wearing socks, or wearing gymnastic shoes. -
Page 16: Limited Warranty
Skywalker Holdings, LLC option, the product at one of this authorized service centers. All products for which a warranty claim is made must be received by Skywalker Holdings, LLC at one of its authorized locations. Preauthorization may be obtained by calling Skywalker Holding, LLC Customer Care Hot Line at 1-866-603-Jump(5867).
