SWTC060
WARNING
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
Maximum user weight 100Ibs.
AGES
3 to 7
IMPORTANT
Trampoline and Enclosures are
susceptible to winds. Be sure to
secure your trampoline and enclosure.
Wind Damage is not covered in the
warranty of your trampoline

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWTC060 and is the answer not in the manual?

Questions and answers

Related Manuals for Skywalker SWTC060

Summary of Contents for Skywalker SWTC060

  • Page 1 SWTC060 WARNING Read all precautions and instructions in this manual before using this equipment. Save this manual for future reference. Maximum user weight 100Ibs. AGES 3 to 7 IMPORTANT Trampoline and Enclosures are susceptible to winds. Be sure to secure your trampoline and enclosure.

  • Page 2: Table Of Contents

    SWTC060 Model____________________ A serial decal is found on one of the bouncer legs or frame. CONTENTS Important Precautions............3 Warning Label Placement............4 Before You Begin..............4 Trampoline Safety Information..........5 Enclosure Safety Information..........6 Methods of Accident Prevention..........7 Warning...................8 Use and Instructional Material..........9 Assembly.................10-14 Care and Maintenance.............15...

  • Page 3: Important Precautions

    USE INSTRUCTIONS WARNING: To reduce the risk of serious injury, read and follow all of the warnings, precautions, and instructions in this manual before you use the trampoline enclosure. Warnings and instructions for care, maintenance, and use of this trampoline and enclosure are included to promote safe, enjoyable use of this equipment. It is the responsibility of the owner and supervisors of the Do not attach anything to the enclosure barrier that is not a trampoline and enclosure to make sure all users obey the safety...

  • Page 4: Warning Label Placement

    BEFORE YOU BEGIN Thank you for choosing your Skywalker Trampolines brand Trampoline. Skywalker Trampoline quadrate Trampolines are designed and crafted to provide many years of fun and fitness. This trampoline comes equipped with warnings and instructions for the assembly, care, maintenance, and use of the trampoline.

  • Page 5: Trampoline Safety Information

    TRAMPOLINE SAFETY INFORMATION In trampoline use, as in all active recreational sports, participants can be injured. However, there are steps that can be taken to reduce the risk of injury. In this section, primary accident patterns are identified and the responsibilities of supervisors and jumpers in accident prevention are described.

  • Page 6: Enclosure Safety Information

    ENCLOSURE SAFETY INFORMATION NEED FOR TRAMPOLINE ENCLOSURE SAFETY A trampoline enclosure is a recreational product. The information on this page and on pages 7-9 identify important safety precautions. The precautions are not all-inclusive, because an enclosure can be used in ways that this manual cannot cover completely. To prevent pinches and cuts during enclosure use, a frame pad must be installed on the trampoline (See the trampoline manufacturer’s instructions).

  • Page 7: Methods Of Accident Prevention

    METHODS OF ACCIDENT PREVENTION The Supervisor's Role in Preventing Accidents It is the responsibility of the supervisors of trampoline users to provide knowledgeable and mature supervision. They need to know and enforce all of the rules and warnings printed in this manual to minimize the likelihood of accidents and injuries.

  • Page 8: Warning

    • Wear clothing that does not have drawstrings, hooks, loops or anything else that could get caught while using the trampoline/enclosure and result in entanglement or strangulation, or both. • Do not attach anything to the netting that is not a Skywalker Trampolines approved accessory or part of the of the trampoline enclosure.

  • Page 9: Use And Instructional Material

    Un-zip and un-clip opening and place one knee on the frame pad and climb head first through the door and crawl to the center of the mat. A responsible adult supervisor must zip the enclosure closed. For additional information regarding equipment, contact Skywalker Holding, LLC. For additional information regarding skill training, contact a trainer certification organization.

  • Page 10: Assembly

    ASSEMBLY Insert the Straight Tube A(1) into the Straight B(2) secure with screw(3) as shown 1、 Repeat this step to attach the three remaining Straight Tube A and Straight Tube B together( not shown) Units A 2、 Install each Frame unswedged(4) and each Frame Swedge(5) onto each Units A using M8 x 100mm Bolt(8) with two M8 Washers(7) and two spacers(6) and one M8 Cap locknut(12).
  • Page 11 Align opening of enclosure 3、 as shown here, centered in between the Pole of the enclosure Pole of enclosure opening of enclosure The Mat with net Attach the Mat with net(12) to the frame by Elastic with ball(14). First attach two Elastics with ball(14) to each corner of frame as show below.(only one corner as shown) Repeat this process to assemble the remaining 40 Elastics with ball to the trampoline frame as shown Frame look underneath...
  • Page 12 Lay the Pad(15) on the frame. adjust the position of the pad so that the slits are directly above the legs 4、 as show below. Look underneath the trampoline. Locate the straps attached to the underside of the frame pad, Position each outer strap so that one strap is on each side of the frame as shown.
  • Page 13 Insert the Straight Tube A(1) into the Short Foam(16), then insert the 5、 Straight Tube B(2) into the Long Foam(17) as shown( not shown the net) Repeat this process to assemble the rest of the Foams(16 and 17) to the tubes(1 and 2) by same manner 6、...

  • Page 14: Assembly

    7、 Surround the legs with lower net(20) as shown, make sure locate the attached strap adjacent to the legs. Firstly attached the lower net(20) to the frame (5) or (4) with strap as ahown A. Then slide the Straight Tube(1) into the attached strap as shown B.

  • Page 15: Care And Maintenance

    WARNING TRAMPOLINE AND ENCLOSURE CARE AND MAINTENANCE Care To avoid damage to the trampoline and enclosure, do not allow pets or animals inside the enclosure. The trampoline is intended to be used by one person at a time who weighs no more than 100 pounds. The user should be either barefoot, wearing socks, or wearing gymnastic shoes.

  • Page 16: Exploded Drawing And Parts List

    EXPLODED DRAWING AND PART LIST 7 12 7 12 strap...
  • Page 17 PART LIST Key No. Description Straight Tube A Straight Tube B Screw Frame unswedged Frame Swedged Spacer M8 Washer M8X100mm Bolt M6 Cap Nut M6 Washer M6x40mm Bolt M8 Cap Locknut Mat with net Elastic with ball Short Foam Long Foam Pole Cap M5X38mm Bolt Lower Net...

  • Page 18: Electronic Console Operation

    ELECTRONIC CONSOLE OPERATION 1. Place 3AA batteries inside the battery compartment with the polarity as shown. 2. Close and lock the battery door. 3. The console can be turned on or off with the power switch on the side of the console. NOTE: If the unit is not producing a sound first check the on/off switch.
  • Page 19 Connect the wire harness of the electronic box to the other wire under the trampoline , see the below insert drawing as shown in drawing A. electronic box drawing A Tie the strap on the small bag of the the electronic box to the Frame as shown in drawing B look underneath strap...

  • Page 20: Fun And Learning Games To Play With Animal Sounds

    Bounce-n-Learn™ Animal Game About Bounce-n-Learn™ Bounce-n-Learn™ Bounce-n-Learn provides physical activity for both good health and skill Bounce-n-Learn provides physical activity for both good health and skill building. It was created for young bouncers to help them develop their gross building. It was created for young bouncers to help them develop their gross motor and mental skills while playing an activity-focused identification game motor and mental skills while playing an activity-focused identification game with...

  • Page 21: Limited Warranty

    Skywalker Holdings, LLC authorized service center, or to products used for commercial or rental purpose. No other Warranty beyond that specifically set forth above is authorized by Skywalker Holdings, LLC.
