  • Page 1 USER MANUAL PCN-1001 Passenger & People Counter Rev 4.0 – 23 December 2011 – PCN-1001_UserMan_En_4.0...

  • Page 2: Trademarks

    • Added paragraph Cleaning on page 7 • Updated paragraph The “Wide-Gate” tab on page 63 September 2010 • Updated paragraph Notes about the Digital I/O interface on page 61 • Minor changes April 2011 23 December 2011 • General contents review © 2011 Eurotech...

  • Page 3: Table Of Contents

    ......................21 INSTALLATION PROCEDURE Step 1: Find the best mounting location ........................23 The PCN-1001 field of view and the Detection area ....................24 The PCN’s field of view ............................24 The Detection area ............................... 25 Number of PCN-1001 devices required ........................27 Example ................................
  • Page 4 Table of contents PCN-1001 User manual How to connect three or more PCN-1001 devices in Wide-gate configuration ........... 30 Note about PCN-1001 devices connected in Wide-gate configuration ..............31 Step 2: Install a PCN-1001 ............................33 Step 2.1: Connect the rear side interfaces and adjust the angle of the front panel ..........33 1: Loosen the front panel to simplify the cabling procedure: ................
  • Page 5 Scenarios ................................88 The DATA field ..............................89 Example 1: setting the LED intensity to 100 ......................90 Example 2: requesting the kernel version installed in the PCN-1001 ..............90 Commands availability ............................91 CRC16 Algorithm ............................... 95 APPENDIX ..................................97 Note for mounting the front panel with angles from 20°...
  • Page 6 Example of direct connection using the CBL-1001-02 ..................106 Rear interfaces ................................107 Power Supply Specifications ........................... 108 Mechanical Characteristics ............................108 PCN-1001 Logon ............................... 109 Troubleshooting ................................ 111 Standards Compliance ............................. 113 Cut-out template ................................ 115 Notes ..................................117...

  • Page 7: Important User Information

    Eurotech reserves the right to revise this document or to make changes to its content at any time without any obligation to notify any person of such revisions or changes.

  • Page 8: Safety Notices And Warnings

    Eurotech assumes no liability for the customer’s failure to comply with these requirements. The safety precautions listed below represent warnings of certain dangers of which Eurotech is aware. You, as the user of the device, should follow these warnings and all other safety precautions necessary for the safe operation of the device in your operating environment.

  • Page 9: Installation

    3. Gently wipe the lenses with a lint-free cloth. WARNING! The PCN-1001 should not be used for extended periods of time with the service plate removed. Doing so can cause dust and other particulates to enter the system thus causing degradation to the optics.

  • Page 10: Life Support Policy

    2006/95/EC Low Voltage Directive (LVD). Eurotech shall not be liable for use of our products with equipment (i.e., power supplies, personal computers, etc.) that are not CE marked and that do not meet the PCN-1001 technical requirements indicated in this manual.

  • Page 11: Technical Assistance

    When transporting any module or system, for any reason, it should be packed using anti-static material and placed in a sturdy box with enough packing material to adequately cushion it. Warning: Any product returned to Eurotech that is damaged due to inappropriate packaging will not be covered by the warranty! Device labelling...

  • Page 12: Conventions And Definitions Used Within This Manual

    Hexadecimal numbering: Hexadecimal numbers are indicated like this: 0x01. Control Unit, Host PC The terms “Control Unit” and “Host PC” are used to describe a computer connected to the PCN-1001 for maintenance and configuration activities. PCN-1001, Device, Counter, Master, Slave In this manual the terms: •...

  • Page 13: Part 1 - Introduction

    Part 1 – Introduction PCN-1001 User manual 1 – I NTRODUCTION PCN-1001_UserMan_En_4.0...
  • Page 14 (This page has been intentionally left blank)

  • Page 15: Contents Of The Box

    2x hexagonal socket screws (M3 x 6) and 2x split washers. These allow you to mount the Extender PCN-1001 Passenger Counter PCN-1001 Extender with screws and washers 2. DTK-1001-00. This is the PCN-1001 development kit and contains: • 1x PCN-1001-00 (as described above) •...

  • Page 16: Pcn-1001 General Description

    PCN-1001 User manual PCN-1001 general description The PCN-1001 is a compact and autonomous device based on non-contact stereoscopic vision technology. It has been designed to count passengers entering and exiting the doorways of buses and trains, but can also be used to count people as they enter or leave buildings or any other area with restricted access.
  • Page 17 PCN-1001 User manual The PCN-1001 has to be installed so that the front panel is placed horizontal to the floor. To achieve this, the angle between the front panel and the enclosure can be adjusted from 0° to 20° (up to 45° using an extender: the extender also increases the protection of the rear side).

  • Page 18: Front Interfaces. The Service Panel

    Boot finished and PCN-1001 ready to operate Notes about the Mini USB port This is a standard Mini-USB type “B” 1.1 client port and is used to connect the PCN-1001 to a Host PC for maintenance and configuration. For further information refer to the paragraph ‘Step 3.2: Connect the PCN-1001 with the Host...

  • Page 19: Rear Interfaces

    PCN-1001 general description PCN-1001 User manual Rear interfaces The PCN-1001 has the following interface connectors on the rear panel: CONNECTOR CHARACTERISTICS: CONNECTOR CHARACTERISTICS: Type: 12-pin male circular connector Type: 12-pin female circular connector P/N: Lumberg 031512 P/N: Lumberg 031512 COUNTERPART CHARACTERISTICS:...

  • Page 20: Power Supply Specifications

    41.5 to 70.0 mm, depending on optical panel angle PCN-1001 dimensions Required cut-out dimensions for mounting Dimensions are in millimetres WARNING! PROVIDE SUFFICIENT ANCHORAGE WHEN MOUNTING THE PCN-1001. THIS MUST BE DONE TO ENSURE THAT THE PCN-1001 DOES NOT BECOME DETACHED DURING TRANSIT CAUSING A SAFETY HAZARD. PCN-1001_UserMan_En_4.0...

  • Page 21: Part 2 - Pcn-1001 Installation Procedure

    Part 2 – PCN-1001 installation procedure PCN-1001 User manual 2 – PCN-1001 INSTALLATION PROCEDURE PCN-1001_UserMan_En_4.0...
  • Page 22 (This page has been intentionally left blank)

  • Page 23: Step 1: Find The Best Mounting Location

    The PCN-1001 must be placed in a way that any person crossing the gate, also passes under the PCN-1001. It is recommended to install the PCN-1001 with a maximum distance of 50 cm from the gate. If not, the area in front of the gate may not be entirely seen by the cameras (the detection area will be too far from the gate) •...

  • Page 24: The Pcn-1001 Field Of View And The Detection Area

    The PCN-1001 field of view and the Detection area The PCN’s field of view The two PCN-1001 stereoscopic cameras have a specific field of view: • The viewing angle relative to the long side of the front panel is about 70 degrees •...

  • Page 25: The Detection Area

    EXAMPLE: If H = 225 cm and the “25-30 cm” range is selected the PCN-1001 will count - with the maximum precision - people having heights from around 100 cm to around 200 cm. People outside this range (very tall or very short) probably will not be detected correctly and will not be counted.
  • Page 26 The following picture gives you an example of frontal and lateral views of the installation. When installing the PCN-1001, make sure that all the people crossing the gate are also crossing the Detection area. If the detection area is shifted to the right or left, some people may not be seen and therefore counting errors may occur.

  • Page 27: Number Of Pcn-1001 Devices Required

    The number of PCN-1001 devices required depends on the width of the gate. For gate widths up to 120 cm you need only one PCN-1001. For gates wider than 120 cm you need to install a supplementary PCN-1001 for each additional 60 cm, and connect the devices in Wide-gate configuration.

  • Page 28: How To Connect One Pcn-1001

    Find the best mounting location PCN-1001 User manual How to connect one PCN-1001 Essential requirements: • The counter must be aligned with respect to the gate • A = B. The Counter must be placed in the middle of the gate Procedure: •...

  • Page 29: How To Connect Two Pcn-1001 Devices In Wide-Gate Configuration

    Find the best mounting location PCN-1001 User manual How to connect two PCN-1001 devices in Wide-gate configuration Essential requirements: • Both counters must be aligned with the other, and both with respect to the gate • The distance between the centres of each counter must be 60.0 cm •...

  • Page 30: How To Connect Three Or More Pcn-1001 Devices In Wide-Gate Configuration

    Find the best mounting location PCN-1001 User manual How to connect three or more PCN-1001 devices in Wide-gate configuration Essential requirements: • The counters must be aligned with each other and with respect to the gate • The distance between the centres of each counter must be 60.0 cm •...

  • Page 31: Note About Pcn-1001 Devices Connected In Wide-Gate Configuration

    PCN-1001 User manual Note about PCN-1001 devices connected in Wide-gate configuration The figure below shows different PCN-1001 devices in Wide-gate configuration, all managed by the same Control Unit (for example the Host PC). The Control Unit sees each Wide-gate configuration as a single entity: Entity #1, Entity #2, …, Entity #N.
  • Page 32 (This page has been intentionally left blank)

  • Page 33: Step 2: Install A Pcn-1001

    • P/N: Lumberg 032212 NOTE: Pins L (Power supply +) and M (Power supply -) are used to supply power to a slave PCN-1001 in Wide-gate. Optionally, for demonstration applications, you can use the Multifunction cable contained in the CBL-1001- 00 Cable Kit (refer to “CBL-1001-00 cable...

  • Page 34: 3: Adjust The Angle Of The Front Panel And Secure The Front Panel

    45°”on page 99. Note about installing 2 or more PCN-1001 in Wide-gate configuration The procedure to install two or more PCN-1001 in Wide-gate is similar to that described in the Step 2.1 above. Before proceeding, refer to “Number of PCN-1001 devices required”...

  • Page 35: Step 2.2: Fix The Pcn-1001 To The Ceiling

    Step 2.2: Fix the PCN-1001 to the ceiling The frame of the PCN-1001 has four mounting holes which allow fixing the PCN-1001 using four M5 screws. You will have to provide all necessary fixing hardware. This will depend on the location, material, and any applicable regulation.

  • Page 36: Step 3: Configure The Network Between Pcn-1001 And Host Pc

    USB type “A” connector on the Host PC 4. Use a Male Mini USB -B to Male USB type “A” cable to connect the Mini USB port of the PCN-1001 to the USB port of the Host PC.

  • Page 37: Step 3.3: Configure The Network On The Host Pc

    Step 3: Configure the network between PCN-1001 and Host PC PCN-1001 User manual Step 3.3: Configure the network on the Host PC 1. Open the “Network Connections”. A dialog-box similar to the one shown below will appear 2. Double-click on the appropriate “Local Area Connection”, in the example above we have named the connection “PCN-1001”...

  • Page 38: Step 3.4: Configure The Tcp/Ip Properties

    10, the last three fields should be numbers ranging from 0 to 254. The Host PC address must be different from the PCN-1001 address. In this case, you cannot insert [10.100.10.100] as the connection between the two systems would not function.

  • Page 39: Step 3.5: Configure The Host Pc Firewall

    PCN-1001 User manual Step 3.5: Configure the Host PC firewall WARNING! If the host PC has a firewall running, the following ports MUST be open. If not, even if the PCN-1001 is properly connected no image will appear within the WinClient. PROTOCOL...

  • Page 40: Step 4: Use Winclient To Network Pcn-1001 & Host Pc

    51 for further details. After the PCN-1001 has been turned on and properly connected the WinClient has to detect it. In this way the PCN-1001 and the Host PC will form a network. Follow these steps to detect the PCN-1001.

  • Page 41: Step 4.1: Set The Main Parameters In The "Controls" Tab

    PCN-1001 User manual Step 4.1: Set the main parameters in the “Controls” tab The “Controls” tab allows you to change the main settings of the PCN-1001 in order to obtain a good resolution on windows 1, 2 & 3. Any modifications to the settings will be automatically saved to the internal flash memory of the PCN-1001 and takes immediately effect (a reset is not needed).

  • Page 42: 4: Set The "In/Out Direction

    Place it away from door-opening mechanisms • It should be placed in the middle of the detection area, which if the PCN-1001 has been installed correctly above the door, should correspond to a central position of the “Door threshold” slide bar If a door is intended to be used in a single direction, for example “in only”...

  • Page 43: 7: Use The "Scene Background" Button To Acquire And Store The Background

    Step 4: Use WinClient to network PCN-1001 & Host PC PCN-1001 User manual 7: Use the “Scene background” button to acquire and store the background Together with “Door threshold”, “Scene background” is the most important parameter that has to be properly set to obtain a reliable counting process.
  • Page 44 Step 4: Use WinClient to network PCN-1001 & Host PC PCN-1001 User manual • Exclude as much as possible the area outside the transportation vehicle • Verify that all the entrance area is detected properly. Make a person move under the PCN-1001s and verify the correct detection •...

  • Page 45: Step 5: Use Winclient To Test The Tracking Of People

    Step 5: Use WinClient to test the tracking of people PCN-1001 User manual Step 5: Use WinClient to test the tracking of people The “tracking” process consists of a 3D image displayed in window 3 that is the differences between the images from the left and right cameras.

  • Page 46: Example Of Counting

    Step 5: Use WinClient to test the tracking of people PCN-1001 User manual Example of counting Outside Inside Remember: During the tracking process, the two counters are incremented only if a Door threshold person enters the detection area, crosses the door...

  • Page 47: How The Threshold Works When Using Digital Inputs

    The commutation time of digital inputs is extremely important because any propagation delay in the signal may affect severely the precision of the counting. The digital inputs should enable the PCN-1001 as soon as the door starts opening and should disable it after the door is closed completely.
  • Page 48 (This page has been intentionally left blank)

  • Page 49: Part 3 - The Pcn-1001 Software

    Part 3 – The PCN-1001 software PCN-1001 User manual 3 – T PCN-1001 SOFTWARE PCN-1001_UserMan_En_4.0...
  • Page 50 (This page has been intentionally left blank)

  • Page 51: Install/Update The Software

    Install/update the software PCN-1001 User manual Install/update the software The software to use with the PCN-1001 is contained on the CD-ROM that comes with the development kit of the PCN-1001 (the DTK-1001-00). For the latest software releases, please refer to www.eurotech.com/en/download/PCN-1001.

  • Page 52: Install/Update The Software On The Host Pc

    PCN-1001 User manual Install/update the software on the Host PC Before starting, save and unzip both the “pcn-1001-Imgserver” and the “pcn-1001-demo-win32” packages on your Host PC into a specific folder (i.e. name it “Eurotech PCN-1001”). Install / Update WinClient and RS485_GUI on the PCN-1001...
  • Page 53 Install/update the software PCN-1001 User manual 3. The InstallShield Wizard will guide you through the following installing/updating procedures: • NEW INSTALLATION: If you are installing the “WinClient” and "RS485_GUI" on the Host PC for the first time, you will obtain the following messages: ...

  • Page 54: Updating Imgserver On The Pcn-1001

    The PCN-1001 comes with Imgserver already installed and ready to work. When available, new versions of the Imgserver can be installed in the following way: 1. The PCN-1001 has to be turned on and connected to the Host PC via USB. Refer to “Install a PCN-1001”...
  • Page 55 PCN-1001 User manual 5. A dialog box will appear. Open the folder with the latest Imgserver file. Select the Imgserver file. Click “Open” 6. The Imgserver will be updated on the PCN-1001. When done the following confirmation message will appear: Click “OK”...
  • Page 56 9. IMPORTANT! Disconnect power to the PCN-1001 (turn it off) 10. Reapply power to the PCN-1001 (turn it on). Allow sufficient time for the system to start. A message like the following will appear when the PCN-1001 has successfully rebooted and reconnected: 11.

  • Page 57: Know Winclient

    PCN-1001 User manual Know WinClient After you have properly connected and configured both the Host PC and the PCN-1001 as described above, if you click the WinClient shortcut on the Desktop you will obtain the WinClient graphical interface: 1 & 2...

  • Page 58: The Drop-Down List

    (“■”) buttons allow you to respectively start and stop the counting process. PCN Configuration Files management (PCF) This feature is useful when you have several PCN-1001 devices that have to be installed and all will have the same operating conditions (i.e. same door on different buses of the same type).

  • Page 59: The Status Bar

    3. A dialog box like the following will appear: 4. Select the proper file name (i.e. Config1) and click “Open” NOTE: The “Scene Background” must be retaken for each new PCN-1001, even if the background is theoretically the same The status bar...

  • Page 60: The Tabs

    PCN-1001 User manual Notes about images acquisition and FPS During normal operations (default mode), the PCN-1001 acquires the images at a constant rate of approximately 60 Frames Per Second (FPS). During configuration, the acquired images are transmitted to the Host PC for visualization. Depending on the Host PCs characteristics and the USB connection, the FPS rate may differ.

  • Page 61: The "Controls" Tab

    Regional Options within the Windows Control panel and set the time separator to “.” And the date separator to “/”; after doing so reconnect to the PCN-1001 and verify that the time and date are correctly displayed.

  • Page 62: The "In/Out Direction" Panel

    Know WinClient PCN-1001 User manual For installations within buildings: In these kinds of installation, it is assumed that the environment has a constant illumination. The right light intensity has to be found experimentally. For on-board installations: Slide the bar completely to the right, and put the light intensity to the maximum.

  • Page 63: The "Data Records" Panel

    Place it away from door-opening mechanisms • It should be placed in the middle of the detection area, which if the PCN-1001 has been installed correctly above the door, should correspond to a central position of the “Door threshold” slide bar If a door is intended to be used in a single direction, for example “in only”...
  • Page 64 Boot 26/09/2011 09:10:00 000002 000002 In this example: At 08:51:10 the PCN-1001 was powered on, the current counter values were: 0 In, and 0 Out At 08:51:20 the door was opened At 08:56:37 1 person entered At 08:57:08 1 person entered...

  • Page 65: The "Scene Background" Button

    In this case the system will continue to cancel and rewrite each successive block of 30,000 lines It is possible to use the Mini USB 1.1 client connector located on the front side of the PCN-1001 in order to transfer data (i.e. to a Host PC).

  • Page 66: The "Reset Counters" Button

    NOTE: If the PCN-1001 is correctly connected via USB to the Host PC and the drivers is correctly installed but you still cannot see the images in windows 1 and 2, try to set the Host PC colour depth to 16 bit (or less) by going to the Start Menu >...

  • Page 67: The "I/O Settings" Tab

    The RS485 port is the main communications interface used when the PCN-1001 is installed on-board a transportation vehicle. Each modification to these settings will be automatically saved in the internal flash memory of the PCN-1001 and takes immediate effect (a reset is not needed).

  • Page 68: The "Optocoupled I/O Test" Panel

    GPO2: By default is associated to outgoing people The optocoupled output electronics behave as low-side switches normally closed. When the PCN-1001 detects a person, one of the two outputs (depending on the direction of the person) turns its status to open for a period of “GPO-Open-Time” milliseconds.

  • Page 69: Notes About The Digital I/O Interface

    Notes about the Digital I/O interface The PCN-1001 can be interfaced and triggered by means of two general-purpose inputs and two general-purpose outputs. For example, the general-purpose digital I/O interface can be used to detect a doors status (open or closed).

  • Page 70: Note: How To Simulate A Digital Input

    For development purposes a digital input can be simulated using Cn5 of the CBL-1001-00 cable kit (see page 100) and an ON/OFF switch. The “RS485 Setup” panel ‘Configure the RS485 port of the PCN-1001’ paragraph on page 82 for further information. PCN-1001_UserMan_En_4.0...

  • Page 71: The "Wide-Gate" Tab

    1. Connect properly all the PCN-1001 devices as described in the paragraph Number of PCN-1001 devices required on page 27 2. Connect your Host PC via the USB port (located under the service plate) to the Master PCN-1001 (the one directly connected to the Control Unit) a.
  • Page 72 Remember to set the configuration parameters (direction, door threshold, light intensity, etc.). The configuration parameters have to be set only after the Wide-Gate mode has been enabled and you are connected to the Master PCN-1001. This will redirect the configuration parameters to the slave counters.

  • Page 73: The "Advanced (1/2)" Tab

    Know WinClient PCN-1001 User manual The “Advanced (1/2)” tab “No Tracking Zone” panel NOTE: The no tracking zone feature is NOT available in Wide-Gate mode The “No Tracking Zone” feature allows you to define rectangular zones in the detection area where tracking will not be performed.
  • Page 74 Know WinClient PCN-1001 User manual The picture below shows how the no tracking zones will affect the cameras’ field of view and the Detection area. A person crossing the Detection area in a non-masked zone will be counted. A person crossing the Detection area in a masked zone will not be counted.

  • Page 75: Single Way Tracking" Panel

    “PCN-1001 System diagnostic” panel Note: With the WinClient software revision 2.2 the “PCN-1001 System diagnostic” works only if the PCN-1001 is set in single configuration. This is a diagnostic algorithm that detects and signals any problem that may occur to the optical section of the PCN-1001 (i.e.: blind cameras, cameras malfunction, luminosity too low, etc.).

  • Page 76: Use Move Detection" Panel

    Know WinClient PCN-1001 User manual The following commands can be used to manage the system diagnostic: DESCRIPTION COMMAND Diagnostic enabled (default configuration) diagnostic_en 1 (unsigned char) Diagnostic disabled diagnostic_en 0 Returns the diagnostic status displaying two values (unsigned char) pcn1001_status The first value will indicate the diagnose status: •...

  • Page 77: Time Background" Panel

    The “Time Background” feature has been specifically developed for building installations. If the PCN-1001 is installed on-board a transportation vehicle it is strongly recommended to disable the Time background by setting to “0” the value of the “Time bkg” parameter.

  • Page 78: The "Advanced (2/2)" Tab

    Know WinClient PCN-1001 User manual The “Advanced (2/2)” tab “Stairs Upgrade” panel Flag the “Stairs Upgrade Enable” feature if stairs are present inside the detection area. This will improve the accuracy of counting. Note: It is suggested to keep this feature enabled.

  • Page 79: Test An Rs485 Connection And Use The Rs485_Gui

    Test an RS485 connection and use the RS485_GUI Introduction Thanks to its RS485 ports, the PCN-1001 allows you to take advantage of all the benefits of an RS485 network, including the possibility of connecting multiple devices – up to 32 at the same time – and perform communications over long distances even in electrically noisy environments.

  • Page 80: Notes About The Rs485 Serial Bus For Development Purposes

    • The same “Multifunction cable” (found in the CBL-1001-00 Cable Kit) you are using to supply power to the PCN-1001, also allows you to connect the PCN-1001 to the RS485 port of the Host PC by using Cn4. • Personal Computers generally do not have a RS485 port. You can use the “703704001SL Adapter” (an element of the CBL-1001-00 Cable Kit) to connect Cn4 of the Multifunction Cable with the USB port of the Host PC.

  • Page 81: Example Of Rs485 Network

    • You need a Host PC that acts as Master device, manages the RS485 network, and has ID number = 1 • Each one of the PCN-1001 devices must have same values for Baud Rate, Data Bits, Parity and Stop Bits, but different ID number, starting form 2.

  • Page 82: Configure The Rs485 Port Of The Pcn-1001

    PCN-1001 User manual Configure the RS485 port of the PCN-1001 Use WinClient to configure the RS485 ports of the PCN-1001. Select the “I/O Settings” tab and refer to the “RS485 Setup” panel as shown below: Insert there the parameters of the PCN-1001 serial port and then click “Set” to save them.

  • Page 83: Start The Rs485_Gui. Configure The Rs485 Port Of The Host Pc

    Test an RS485 connection and use the RS485_GUI PCN-1001 User manual Start the RS485_GUI. Configure the RS485 port of the Host PC Double click on the RS485_GUI link on the Host PC desktop. The following interface will appear: It allows you to test all the commands available to the RS485 port.

  • Page 84: Recipient" And "Polling" Panels

    To do this, Insert the appropriate address in the Recipient box and then click the Start button. If the appropriate PCN-1001 is found, the address is correct and the port is configured correctly, the software will display a message like: “Got reply from [Slave #2]”.

  • Page 85: System Info" Panel

    This allows you to insert the PCN-1001 IP address. The default IP address is 10.100.10.100; the first octet if fixed to avoid network configuration mismatch. In Wide-Gate configuration all the PCN-1001 of same group will obtain the same IP address “Date and Time settings” panel This allows you to set the Time and Date on your PCN-1001.

  • Page 86: Optocoupled Inputs Functions" Panel

    Test an RS485 connection and use the RS485_GUI PCN-1001 User manual The file transfer progressing is displayed in the log view as shown as follows: No other operation is allowed during file transfer. When transfer finishes a proper message will be shown in the log view and the user will be allowed to perform other operations.

  • Page 87: The Communication Protocol

    Test an RS485 connection and use the RS485_GUI PCN-1001 User manual The communication protocol SNP (Small Network Protocol) is the communication protocol used in the RS485 connection. The packet format contains the addresses of both the sender and recipient and the number of packets to be sent along with the current packet number.

  • Page 88: Polling

    Test an RS485 connection and use the RS485_GUI PCN-1001 User manual Polling The master can poll a slave who answers with a message to the master. A poll is defined as a packet with: TotalPacketNumber PacketNumber DataLength Scenarios The following charts are intended to give an idea of how the sequences are sent/received by the master and...

  • Page 89: The Data Field

    Test an RS485 connection and use the RS485_GUI PCN-1001 User manual Broadcast Message Send Message Received by all Part 3 Systems [‘S’, ‘J’, 3, 3, x] Each message between Master and Slave is made in the following format: Source Destination...

  • Page 90: Example 1: Setting The Led Intensity To 100

    Postamble 0xFF The slave will reply to this command with: STRING TERMINATOR COMMAND “sled” Example 2: requesting the kernel version installed in the PCN-1001 Example of request STRING TERMINATOR COMMAND “ker_version” This command does not need any parameter. The Slave will answer with:...

  • Page 91: Commands Availability

    Enables or disables the diagnostic enable_pc Enables or disables the counting process fw_version Reads the version number of PCN-1001 FPGA firmware gcounters Returns the values of the Incoming and Outgoing counters gdatetime Reads the date and the time input0 / input1...
  • Page 92 Command Description Gets date and time in the PCN-1001 Parameters Parameters Description Returns String containing the date and the time in PCN-1001 input0 / input1 Command input0 / input1 Command Description Enable the functions for the two Optoisolated inputs.
  • Page 93 Resets the values of the incoming and outgoing counters Parameters Parameters Description Returns sdatetime Command sdatetime Command Description Sets date and time in the PCN-1001 Parameters String Parameters Description String containing the date and time. Example: 21 May 2006 at 15:39 = “052115392006” Returns PCN-1001_UserMan_En_4.0...
  • Page 94 Parameters Description 0 ~ 255 0: Off 255: Maximum intensity Returns sys_version Command sys_version Command Description Returns the PCN-1001 operating system version. Parameters Parameters Description Returns String containing the OS version number (e.g.: “1.6”) version Command version Command Description Returns the PCN-1001 counting software version.

  • Page 95: Crc16 Algorithm

    Test an RS485 connection and use the RS485_GUI PCN-1001 User manual CRC16 Algorithm Table based algorithm in C for calculation of CRC16. #include <string.h> #define MAX_DATA_LEN 4096 #define MAX_PACKET_LEN 5+1+1+1+1+1+2+MAX_DATA_LEN+2+1 #define MAX_CRC_DIGITS 256 #define BYTE_WIDTH #define CRC_WIDTH #define CRC_MASK 0xFF...
  • Page 96 Test an RS485 connection and use the RS485_GUI PCN-1001 User manual main (int argc, char *argv[]) char buf[MAX_PACKET_LEN]; char data[6] = {0x73, 0x6c, 0x65, 0x64, 0x00, 0x64}; unsigned char src = 0x01; unsigned char dest = 0x02; char tpn = 0x01;...

  • Page 97: Appendix

    APPENDIX PCN-1001 User manual APPENDIX PCN-1001_UserMan_En_4.0...
  • Page 98 (This page has been intentionally left blank)

  • Page 99: Note For Mounting The Front Panel With Angles From 20° Up To 45

    It is also recommended to install any cabling before mounting the extender, this will give easier access to M1 and M2. Use the two M3 x 6 hexagonal head screws (and the two split washers) provided to fix it to the PCN-1001. A hexagonal 2 mm (3/32”) key/driver is required.

  • Page 100: Pcn-1001 Cable Kits

    CBL-1001-02 Link Cable for multiple PCN-1001 configurations CBL-1001-00 cable kit The CBL-1001-00 Cable Kit allows you to quickly power supply and interface the PCN-1001 to the external world. The cable kit has the following components: • 1x 7030000330L Multifunction Cable •...

  • Page 101: Male Usb Mini-B To Male Usb Type "A" Cable

    White / Green Digital OUT 1 V+ White / Blue Power supply + (*) Power supply - (*) Black (*) For secondary PCN-1001 Male USB Mini-B to Male USB Type “A” Cable Cable length: 180 cm +/- 10% Connector Details TYPE NAME...

  • Page 102: 703704001Sl Adapter (Male Usb Type "A" To Male Db9 For Rs485 Cable)

    PCN-1001 Cable kits PCN-1001 User manual 703704001SL Adapter (Male USB Type “A” to Male DB9 for RS485 Cable) Cable length: 180 cm +/- 10% Connector Details TYPE NAME To Multifunction Cable, Cn4 Male DB9 (for RS485) To Host Computer Male USB Type “A”...

  • Page 103: Cbl-1001-01 Cable Kit

    PCN-1001 Cable kits PCN-1001 User manual CBL-1001-01 cable kit The CBL-1001-01 allows you to directly connect two PCN-1001 devices together in Wide-Gate configuration (for gates wide between (120 and 180 cm). The cable kit has the following components: • 1x 7010000108L Cable for direct connection...

  • Page 104: Example Of Direct Connection Using The Cbl-1001-01

    PCN-1001 Cable kits PCN-1001 User manual Example of direct connection using the CBL-1001-01 Vehicle data bus (Communication interface and power supply) Central Unit Direct connection PCN-1001 PCN-1001 25 cm from the sensors Secondary Primary connector connector 60 cm Detection area...

  • Page 105: Cbl-1001-02 Cable Kit

    The CBL-1001-02 Cable Kit allows you to install three or more PCN-1001 devices in Wide-Gate configuration to monitor gates wider than 180 cm. Remember that in this configuration it is necessary to supply additional power to the third PCN-1001, and the same connection has to be done for each PCN-1001 thereafter.

  • Page 106: Example Of Direct Connection Using The Cbl-1001-02

    PCN-1001 Cable kits PCN-1001 User manual Connector Pinouts SIGNAL Cn2 Pin # SIGNAL Cn3 Pin # SIGNAL SIGNAL Cn1 PIN # Digital IN1 + Digital OUT 2 V + Digital IN1 - Digital OUT 2 Digital OUT 1 V+ Digital IN 2+...

  • Page 107: Rear Interfaces

    RS485_1 GND IN/OUT RS485_1 + IN/OUT RS485_1 - IN/OUT Power supply + (For the secondary PCN-1001) Power supply – (For the secondary PCN-1001) M2 pinout SIGNAL DIRECTION Power supply + (To the secondary PCN-1001) Power supply – (To the secondary PCN-1001)

  • Page 108: Power Supply Specifications

    Required cut-out dimensions PCN-1001 dimensions for mounting Dimensions are in millimetres WARNING! WHEN MOUNTING THE PCN-1001, USERS SHOULD PROVIDE SUFFICIENT ANCHORAGE, THIS SHOULD BE DONE TO ENSURE THAT THE PCN-1001 DOES NOT BECOME DETACHED DURING TRANSIT AND CAUSE A SAFETY HAZARD. PCN-1001_UserMan_En_4.0...

  • Page 109: Pcn-1001 Logon

    PCN-1001 Logon PCN-1001 User manual PCN-1001 Logon The PCN-1001 runs using an embedded Linux Operating System. Use the ssh protocol (IP: 10.100.10.100) if for any reason it is necessary to log-on the Operating System . Example: root@10.100.10.100 These are the default passwords:...
  • Page 110 (This page has been intentionally left blank)

  • Page 111: Troubleshooting

    WARNING! Before going further with this troubleshooting make sure you have ALWAYS installed the SAME REVISION of “pcn-1001-Imgserver” and “pcn-1001-demo-win32” (the software package that contains “WinClient” and “RS485_GUI”). Incompatibilities will happen and cause problems if older and newer versions of either the “pcn- 1001-demo-win32”...
  • Page 112 REMEDY PROBLEM Too many false negatives There is a counting enable delay The digital inputs should enable the PCN-1001 as soon as the door starts opening. Too many false positives The digital inputs should disable the PCN-1001 There is a counting disable delay after the door is closed completely.

  • Page 113: Standards Compliance

    Standards Compliance PCN-1001 User manual Standards Compliance STANDARD FOLLOWED RESTRICTION TYPE ROUTINE TEST Visual inspection EN 50155 Section 10.2.1 Performance test EN 50155 Section 10.2.2 Low limit: 9V High limit: 32V Interruption: Class 1 (no interruptions) Cooling test EN 50155 Section 10.2.3 Class T1: -20°C (§...
  • Page 114 (This page has been intentionally left blank)

  • Page 115: Cut-Out Template

    Cut-out template To simplify the PCN-1001 installation you can print this page in A4 format (e.g.: on card or plasticard) without any scaling and use it as a cut-out template. Before using this page, verify that the dimensions in the printed sheet correspond to the real ones.
  • Page 116 (This page has been intentionally left blank)

  • Page 117: Notes

    Notes PCN-1001 User manual Notes PCN-1001_UserMan_En_4.0...
  • Page 118 Toll free: +1 888.941.2224 Tel: +81 86.245.2861 Via Fratelli Solari, 3/a Fax: +39 0433.485.499 Tel: +1 301.490.4007 Fax: +81 86.245.2860 33020 Amaro (UD) – Italy E-mail: sales.it@eurotech.com Fax: +1 301.490.4582 E-mail: sales@advanet.co.jp Tel: +39 0433.485.411 E-mail: support.it@eurotech.com E-mail: sales.us@eurotech.com E-mail: tsupport@advanet.co.jp Fax: +39 0433.485.499...

Table of Contents
