USER INSTRUCTIONS
SELF RETRACTING LIFELINES WITH
LEADING EDGE CAPABILITY
Complies with the ANSI Z359.14 standard and
OSHA 29 CFR 1910 and 1926 regulations.
This manual applies to SRL model numbers R410020LE, R410030LE and R410065LE.
WARNING!
Compliant fall protection equipment must only be used as it was designed. Users MUST read
and follow all user instructions provided with the product. Before using a fall arrest system,
users must be trained in the safe use of the system, as required by OSHA 29 CFR 1910.30 and
1926.503, or local safety regulations. Misuse or failure to heed these warnings and
instructions may result in injury or even death.
WORK SAFE! WORK SMART!
IF YOU HAVE ANY QUESTIONS ABOUT THE PROPER USE OF THE EQUIPMENT, SEE YOUR
SUPERVISOR, USER INSTRUCTIONS, OR CONTACT WERNER CO. FOR MORE INFORMATION.
Werner Co. Fall Protection
93 Werner Rd.
Greenville, PA 16125
724-588-2000
888-523-3371 toll free
888-456-8458 fax
