Cover & Index
1
2
Safety Information / Warning / Warranty / Marking
Explanation / Dimension
3
4
Product Specifications
5
Standart DMX Wiring Diagram
Congratulations on choosing a HERA product!
We thank you for your custom.
Please note that this product, as all the others in the rich HERA range, has been designed and made with total quality to ensure excellent performance and best meet your
expectations and requirements. Carefully read this instruction manual in its entirety and keep it safe for future reference. It is essential to know the information and comply
with the instructions given in this manual to ensure the fitting is installed, used and serviced correctly and safely. HERA disclaims all liability for damage to the fitting or to
other property or persons deriving from installation, use and maintenance that have not been carried out in conformity with this instruction manual, which must always
accompany the fitting. HERA reserves the right to modify the characteristics stated in this instruction manual at any time and without prior notice.
PD 60 DYNAMIC WHITE SERIES
User's Manual & Installation Guide
6
7
9
11
12
www.heraled.com
www.heraled.com
RDM Monitoring Wiring Diagram
Connection Diagram
Installation Instruction
Ordering Information
Accessories / Recommended Products
Back Cover
V.1.0
Advertisement
Table of Contents
Related Manuals for HERA PD 60 DYNAMIC WHITE SERIES
Summary of Contents for HERA PD 60 DYNAMIC WHITE SERIES
- Page 1 We thank you for your custom. Please note that this product, as all the others in the rich HERA range, has been designed and made with total quality to ensure excellent performance and best meet your expectations and requirements. Carefully read this instruction manual in its entirety and keep it safe for future reference. It is essential to know the information and comply with the instructions given in this manual to ensure the fitting is installed, used and serviced correctly and safely.
- Page 2 Waste Electrical Shock Manual. Illumination and Electronic Equipment Warranty Hera warrants the products for a period of five (5) years from date of purchase, provided that the purchased items are used under the conditions stated in this user manual. Marking www.heraled.com...
- Page 3 PD 60 DYNAMIC WHITE SERIES Explanation P D60 DW Series is used in industrial application where high brightness, broad color scale, customization and very long pixel pitch distances are needed with excellent color consistency. Splendid effects can be animated with large fixtures without limitation of geometry, shape and range.
-
Page 4: Product Specifications
PD 60 DYNAMIC WHITE SERIES Product Specifications Model Direct View Diffused View Light Source: 48pcs High intensity 3528 LEDs Lumen Maintenance: 60.000+ hours L70 @ 25° C (full output) Color Range: White CCT 2700-6500K Color Resolution: 2 x 14-bit (Gamma correction) PWM Frequency: 1,600Hz flicker free dimming to 0.1%... -
Page 5: Standart Dmx Wiring Diagram
PD 60 DYNAMIC WHITE SERIES Standart DMX Wiring Diagram Indoor Zone Ethernet AC Input RISK OF ELECTRIC SHOCK 3-Pin VDE RJ45 90~264VAC 50/60Hz RJ45 DMX 1 DMX 2 DMX 3 DMX 4 DMX 5 DMX 6 DMX 7 DMX 8... -
Page 6: Rdm Monitoring Wiring Diagram
PD 60 DYNAMIC WHITE SERIES RDM Monitoring Wiring Diagram Indoor Zone RDM Monitoring DMX Data Sending The MADRIX Software is the ultimate Voltage Monitoring,Temperature Monitoring, control tool for LED lighting. Luminex Status Monitoring,Power Cycle Monitoring, Use pixel mapping at its best in 2D or 3D Lumen-Maintenance Life Monitoring Luminex Lighting Control Equipment ©... -
Page 7: Connection Diagram
PD 60 DYNAMIC WHITE SERIES Connection Diagram Push arrow direction Push Lock Turn to left and pull for removing. Turn Pull For instance diagram Max.cable length 50 meter for pixel pitch PD60 PIN DETAILS Input Output (+) 48VDC (+) 48VDC... - Page 8 PD 60 DYNAMIC WHITE SERIES Connection Diagram Connection Diagram Push arrow direction Push Lock Turn to left and pull for removing. Turn Pull For instance diagram Max.cable length 50 meter for pixel pitch PD60 PIN DETAILS Input Output (+) 48VDC...
- Page 9 PD 60 DYNAMIC WHITE SERIES Installation Instruction Screwing diagram as shown at figure 1 Connector connection diagram as shown at figure 2 Finished Installation as shown at figure 3 www.heraled.com...
- Page 10 PD 60 DYNAMIC WHITE SERIES Installation Instruction Screwing diagram as shown at figure 1 Connector connection diagram as shown at figure 2 Finished Installation as shown at figure 3 www.heraled.com...
-
Page 11: Ordering Information
PD 60 DYNAMIC WHITE SERIES Ordering Information Color Selection Ordering Information Color Selection P01003105 PD60-RGBW 4Ch. DMX Direct View Pixel Dot P01005105 PD60-RGBW 4Ch. DMX Dome Pixel Dot P01009105 PD60S-RGBW 4Ch. DMX Dome Pixel Dot P01004105 PD60S-RGBW 4Ch. DMX Direct View Pixel Dot *Standart product codes that we provided is above. - Page 12 www.heraled.com...
