INSTALLATION DETAILS MAGIC.SENS MSS 400

Fixing notes

The sounder base is designed for surface mounting and is provided for rear and surface cable
entry. The sounder insert has to be removed before fixing the mounting base. To release the
sounder insert, fixing clamps have to be pushed in direction of the arrows (Fig.2). for rear
cable entry, conduit box mounting, feed the cable through the openings. For surface cable
feed, please break out the prepared cable entries. Install the mounting base with two screws
on a flat dry surface. Therefore, only the prepared fixing bores may be used (see Fig. 2)!

Technical Data

Dimensions :
see Figure 1 and Figure 2
IP-Rating (as per EN 60529):
Operating temperature:
Storage temperature:
Housing material:
Terminals:
In and Out 0,28 - 2,5mm
Figure 1: Dimensions
128
Figure 3: Mounting order

Tone table

Operating voltage:
Current consumpt. from LSN (standby): 575 - 1025mA
IP30
Current consumption from LSN (alarm):
-10_C . . . +55_C
-25_C . . . +85_C
Bosch order number:
ABS plastics
CPD number:
2
Cable entries for
under plaster cable feed
Detector
Sounder insert
Fixing springs
Mounting base
Detector with sounder
base (complete fitted)
Page 1
(depending on selected tone)
Figure 2: Installation details
Use only these borings for
fixing the mounting base!
Sounder insert
fixing clamps
Prepared cable
entries
Figure 4: Detector locking spring
9 - 15V DC / 15 - 28V DC
20mA
4.998.098.974
0786 - CPD - 20186
70
60
50
Prepared cable
entries
to
release
sounder
insert
BDL - 4998121822
A4.en/ 23.08.2007
ST-FIR/ PRM1/ deh
