- Page 1 Cartridge Machine USER MANUAL 2018...
-
Page 2: Table Of Contents
INDEX Machine Overview The Grip The Body The Give Knob Adjust the Give Replacing the Give Knob The MotorBolt System Changing the Stroke Wheel Detaching the MotorBolt RCA Connection Connecting your Machine Adjusting Needle Depth Additional Information 15 -16... -
Page 3: Machine Overview
Ergonomic grip design providing artists full control for tattooing of parameters to unleash their creative vision. Compatible with most power supplies on the market, the Spektra Xion S is a one tool solution for all your tattooing needs. -
Page 4: The Grip
Spektra Xion S Grip Autoclavable Ergonomic Grip design Compatible with most “membrane” needle cartridges on the market THE GRIP he Spektra Xion S offers an 32mm to 25mm. Other grip This polished and anodized ergonomic Grip design options may be available. -
Page 5: The Body
USER MANUAL THE BODY Spektra Xion S Body Ratcheted Disk System O-Ring Hex Drive Pin Xion S Body Give Knob System Stabilizing Friction O-Rings THE BODY he Body is the core of the machine where the reciprocating and give systems are housed. -
Page 6: The Give Knob
USER MANUAL THE GIVE KNOB Spektra Xion S Give Knob Give Knob GIVE KNOB his dial, located at the tip of the body, adjusts your needle strike from hard to soft. Note that this mechanism only spins about one turn (270° or... -
Page 7: Adjust The Give
USER MANUAL ADJUST THE GIVE Turning the Give Knob in the arrow’s direction decreases the Give Turning the Give Knob in the arrow’s direction increases the Give or locks it completely. Always back one click from maximum settings ADJUST THE GIVE emove the Grip by harder strike. -
Page 8: Replacing The Give Knob
USER MANUAL REPLACING THE GIVE KNOB Use a plastic prying tool, pry gently and pull out Give Knob At this stage you can also sanitize the Hex Drive Pin by wiping it with cold sterilization. Avoid fluids entering the housing HOW TO o remove the Give Knob place it in position ensuring... -
Page 9: The Motorbolt System
USER MANUAL THE MOTORBOLT SYSTEM Spektra Xion S MotorBolt system Motor Shaft Stroke Wheel MotorBolt System MOTORBOLT SYSTEM his detachable module houses the motor, cam and RCA connection. Once removed, artists can replace stroke MotorBolt housing displacement by interchanging provided Stroke Wheels. -
Page 10: Changing The Stroke Wheel
USER MANUAL CHANGING THE STROKE WHEEL Pull out to remove the Stroke Wheel Insert the thinner 0.05” Allen Key in set screw that secures Stroke Wheel with Motor Shaft and loosen. Do not remove screw CHANGING THE STROKE WHEEL emove the MotorBolt by the screw that secures Stroke Ensure that the Stroke Wheel pushing in while turning it... -
Page 11: Detaching The Motorbolt
USER MANUAL DETACHING THE MOTORBOLT Twist the MotorBolt as shown and remove Get a firm grip and turn the body as shown with the Grip. DETACHING THE MOTORBOLT Do not apply force o detach your MotorBolt, element. all the way in, topping off with ensure you have a firm until you feel your Stroke Wheel the O-Ring around it and the... -
Page 12: Rca Connection
USER MANUAL RCA CONNECTION RCA Connector CONNECTION his connecting terminal is compatible with most RCA cables on the market. For consistent connection and machine longevity, premium Gold-Plated Premium Darklab Straight RCA Cord RCA cables are preferred. -
Page 13: Connecting Your Machine
USER MANUAL CONNECTING YOUR MACHINE Plug the RCA cord into the Best connection Improper connection Xion S RCA connector HOW TO Insert the RCA into the back unit uses 1/8” or 3.5mm jack (similar to headphone of the MotorBolt. Connect CONNECT to a Power Supply. -
Page 14: Adjusting Needle Depth
USER MANUAL ADJUSTING NEEDLE DEPTH Increases needle depth Decreases needle depth ADJUSTING NEEDLE DEPTH o adjust needle depth, hold the machine body and MotorBolt while turning the grip. A counter clockwise turn decreases depth, while a clockwise turn increases depth (also known as needle hang). -
Page 15: Additional Information
USER MANUAL ADDITIONAL INFORMATION VOLTAGE PARAMETERS While voltage is a parameter that will vary from artist to artist, it is safe to say that this machine will operate at a minimum voltage of around 4 Volts with a maximum voltage of 9.5 Volts. Depending on the type of needle configuration or brand you use, feel free to adjust the voltage to obtain the desired performance. - Page 16 YouTube channel at YouTube. com/microbeauintl. HANDY TIPS The following tips will help you get the most out of your Spektra Xion S and avoid potential issues: • Always place the machine on a safe area. Dropping the machine can cause damage to the magnets, bearings and brushes of the motor.
