MLT Inverters Powerstar 3-Phase Quick Setup Manual

Product Support
When contacting Product Support via telephone or email please provide the follow-
ing information for the fastest possible service:
Error message shown on display
Type of Inverter
Serial number
Software and Firmware version numbers
Battery type
Battery bank capacity
Battery bank voltage
The above details (apart from the Error Message should be available from your Sys-
tem Configuration sheet in the manual). Note that the software and firmware ver-
sion numbers plus the serial number are available from the System Information
screen which is accessed from the SCREENS menu.
Contact Details
Telephone: +27 87 943 2299 or +27 21 683 3310
Email: support@mltdrives.com
© MLT Drives. Date of Publication 20140801. Some icons by Freepic. CC 3.0 license.
Powerstar 3-Phase
Quick Setup Guide

Installation

Connecting cables:
1. By default, the Utility/Grid is connected to Source A, and the Generator to
Source B.
2. 2. Minimum AC cables per phase diameters: 18kVA Powerstar: 6mm² (Source)
and 16mm² (Load). 24kVA Powerstar: 10mm² (Source) and 16mm² (Load)
Swapping the DC polarity will damage the inverter.
Connecting the Utility to the AC output port will damage the inverter
