Operator's Manual
2N1 Brad Nailer and Stapler
IMPORTANT:
This manual provides complete instructions for safely operating and maintaining your nailer.
Read and save these instructions. Refer to this manual each time before using your nailer.
keep this manual for future reference
E107991 Rev. 0 04/2014
Model No
BNCS2P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vx BNCS2P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Powermate Vx BNCS2P

Summary of Contents for Powermate Vx BNCS2P

  • Page 1 Model No BNCS2P Operator's Manual 2N1 Brad Nailer and Stapler IMPORTANT: This manual provides complete instructions for safely operating and maintaining your nailer. Read and save these instructions. Refer to this manual each time before using your nailer. keep this manual for future reference E107991 Rev.

  • Page 2: Table Of Contents

    CONTENTS IMPORTANT INFORMATION EXPLANATION OF THE NAILING ACTION GENERAL SAFETY RULES WORK AREA PERSONAL SAFETY TOOL USE AND CARE SERVICE AIR SOURCE DESCRIPTION AND SPECIFICATION SPECIFICATION FEATURES ASSEMBLY/INSTALLATION OPERATION LUBRICATION ADJUSTING AIR PRESSURE CONNECTING AIR SUPPLY TOOL TESTING NAIL LOADING REMOVING THE NAILS METHODS OF OPERATION COLD WEATHER OPERATION...
  • Page 3 IMPORTANT INFORMATION requirements of American National Standards Institute, ANSI Z87.1 and provide protection against flying particles both from the front and side. The employer must enforce the use of safety glasses by WARNING the tool operator and others in work area. TO AVOID SERIOUS PERSONAL INJURY, ALL USERS AND • ALWAYS WEAR EAR AND HEAD PROTECTION.

  • Page 4: Air Source

    • USE ONLY FASTENERS THAT ARE RECOMMENDED 6). Leaving work area; FOR YOUR MODELS. Do not use the wrong fasteners or 7). Moving it to another location; load the fasteners incorrectly. 8). Handing it to another person. • CHECK FOR MISALIGNMENT OR BINDING OF Never attempt to clear a jam or repair the tool unless you MOVING PARTS, BREAKAGE OF PARTS, AND ANY have disconnected air hose from the tool and removed all...

  • Page 5: Specification P3

    FUNCTIONAL DESCRIPTION AND SPECIFICATIONS WARNING Disconnect the tool from the air source before making any adjustments, changing accessories or storing the tool. Such precautionary safety measures reduce the risk or unintentional tool operation. FIG. 1 Adjustable Exhaust Deflector Hand Grip Air Plug Top Cap Body...

  • Page 6: Features P4

    OPERATION FEATURES • Quick-release latch for jams. LUBRICATION • New designed light die cast alum alloy body. • Depth of penetration adjustable. WARNING • Exhaust direction adjustable and remain nails visible. • No-Mar tip protects work surface. USE ONLY THE AIR TOOL LUBRICANTS SUPPLIED WITH THE TOOL. Do not use other lubricants as they may damage ASSEMBLY/INSTALLATION the tool. Follow the instructions below to prepare your tool for If the tool is not used with an in-line lubrication system on operation.

  • Page 7: Tool Testing

    • ALL SCREWS MUST BE TIGHTENED. If any screws WARNING are loose, tighten them. Never connect the tool to an air source that is capable • T HE SAFETY AND TRIGGER MUST MOVE of producing air pressure exceeding 200PSI. Excessive SMOOTHLY.

  • Page 8: Nail Loading

    c. Remove the finger from the trigger. FIG. 8 Tool operation will end (the driver blade will return to the top). 6. If no abnormal operation is observed, you may load nails in the tool. Drive nails into the workpiece that is the same type to be used in the actual application.

  • Page 9: Cold Weather Operation

    SEQUENTIAL FIRE 1. Disconnect tool from air supply. 1. Position the nail outlet on the workpiece with finger off 2. Remove nails from the tool. the trigger. 3. Adjust tool driving depth: 2. Depress the safety firmly until it is completely depressed. • T o reduce the nail depth , turn the adjustment knob 3.

  • Page 10: No-Mar Tip

    5. Close the jam release and latch. FIG. 13 6. Reconnect the tool to the air resource. 7. Reload the tool with fasteners. FIG. 15 Latch (A) Nail Indicator USING THE NO-MAR TIP Jam Release (B) WARNING When attaching or detaching the No-Mar Tip, be sure to CLEANING remove your finger from the trigger and disconnect the air hose from the nailer.
  • Page 11 Copyright © 2014 Sanborn Mfg. Division of MAT Industries, LLC...
