Summary of Contents for YOKOGAWA WU10
- Page 1 Instruction Model WU10 and WE10 Manual VP cable and extension cable IM 12B06W02-02E-E 10th edition...
-
Page 2: Table Of Contents
1.3. Waranty & Service General Specifications 2.1 Specifications WU10-V- 2.2 Specifications WE10- Installation 3.1 Connections of VP single coax cable WU10-V-S 3.2 Connections of VP dual coax cable WU10-V-D and WE10 Model and Suffix codes Appendix 1. IM Protection of environment IM 12B06W02-02E-E... -
Page 3: Preface
Damage caused by wear and tear, This instruction manual provides information inadequate maintenance, corrosion, or for the installation and use of the WU10 and by the effects of chemical processes is WE10 cable. This universal sensor cable excluded from this warranty coverage. -
Page 4: General Specifications
2. General Specifications 2.1 Specifications WU10-V- WU10-V-S-..-.. WU10-V-D-..-.. Description: Multicore shielded cable with Multicore shielded cable one low noise coax and three with two low noise coaxes insulated wires and drain wire and four insulated wires Mechanical specifications Outer diameter 6,5 mm ±... -
Page 5: Specifications We10
2.2 Specifications WE10- WE10-H-D-...-.. Description: Multicore shielded cable with two low noise coaxes and four insulated wires, halogeen free. Mechanical specifications Outer diameter 8,3 mm ± 0,2 mm Bending radius: ≥ 5x outer diameter • Fixed installation ≥ 12x outer diameter •... -
Page 6: Installation
Drain wire yellow Liquid Earth (LE) Parameter SC For SC the WU10-V-S cannot be used, for this parameter the WU10-V-D or WE10 is necessary Parameter ISC For ISC the WU10-V-S cannot be used, for this parameter the WU10-V-D or WE10 is... -
Page 7: Connections Of Vp Dual Coax Cable Wu10-V-D And We10
3.2 Connections of VP dual coax cable WU10-V-D and WE10 Blue (F) Red (E) Black green White (D) Brown (B) brown yellow Transparent (C) Transparent (A) brown blue white Green (H) Yellow (G) white Connector Cable Figure 3 Dual coax cable layout... - Page 8 Parameter pH differential+ORP pH differential is where the combined sensor has two dissimilar glass membranes WU10-V-D, WE10 Color EXA/FLXA terminal no. Description Coax1 core transparent pH input Coax1 shield brown pH guard Coax2 core transparent Ref input Coax2 shield white...
- Page 9 Parameter SC WU10-V-D Color EXA/FLXA terminal no. Description Coax1 core transparent Ui (inner electrode) Coax1 shield brown Ii (inner electrode) Coax2 core transparent Uo (outer electrode) Coax2 shield white Io (outer electrode) Wire Pt1000-T1 Wire blue Pt1000-T2 Wire yellow Not connected...
-
Page 10: Model And Suffix Codes
4. Model and Suffix codes Model Suffix Code Description WU10 Sensor cable Connector type Variopin Cable type Single Coax Dual Coax Cable length 2 meters 5 meters 10 meters 15 meters 20 meters Model Suffix Code Description WE10 Generic cable... -
Page 11: Appendix 1. Im Protection Of Environment
Appendix 1. IM Protection of environment Instruction Manual SC24V, SC25V, SC25F, SM60, SR20, FC20, BA10, BA11, IB100, SA11, WE10, WF10, WU10, WU11, WU40 SC41, SC42, SC4A, SX41, SX42 ISC40 Protection of Environment (Use in China) 中華人民共和国国内でのみ有効です。 这个标志是基于SJ/T11364，在中国（不包括台湾，香港，澳门）贩售的电子电器 产品所适用的环境保护期限，6种有害物质的含有量都低于GB/T26572所规定的限 量要求以下。 Production date 关于生产日期... - Page 12 Yokogawa has an YOKOGAWA ELECTRIC ASIA Pte. LTD. YOKOGAWA ELECTRIC CORPORATION World Headquarters 5 Bedok South Road extensive sales and Singapore 469270 9-32, Nakacho 2-chome, Musashino-shi distribution network. Singapore Tokyo 180-8750 www.yokogawa.com/sg Please refer to the Japan www.yokogawa.com A5 form European website (www.yokogawa.com/eu)
