This manual pertains to the Echometer Wireless Base WB100.
identification numbers are provided in Table 1, with label image and location images in Table 2.
Model
Wireless Base Model WB100
FCC/IC Label Design/Location
Table 2: Label shown will be placed on the bottom of the product enclosure
Echometer Company
5001 Ditto Lane
Wichita Falls, TX 76302
Wireless Base User Guide
Table 1
FCCID
Q5Q-WB100
FCC/IC Label Location
Associated FCC and IC
IC ID
10048A-WB100
11 Sep 2012
Advertisement
Table of Contents
Related Manuals for Echometer Wireless Base WB100
Summary of Contents for Echometer Wireless Base WB100
- Page 1 Wireless Base User Guide This manual pertains to the Echometer Wireless Base WB100. Associated FCC and IC identification numbers are provided in Table 1, with label image and location images in Table 2. Model FCCID IC ID Wireless Base Model WB100...
- Page 2 Wireless Base User Guide The Wireless Base WB100 is a component of the Echometer Well Analyzer and designed to be used with Echometer Wireless Sensors, (WRFG, WPRT, WPP, WPT, WHT, WHT50K, and WGDA), providing a wireless option for obtaining data, (such as dynamometer, power and pressure/temperature).
- Page 3 Pulse W1030 o Linx Tech ANT-2.4-CW-RAH-RPS: 2.4GHz o Substitutes may be used, as long as they meet the 2.4GHz, 50Ω, <2dBi gain, RPSMA Male requirements. Echometer Company 5001 Ditto Lane Wichita Falls, TX 76302 11 Sep 2012...
- Page 4 2. A backup battery (+5-15VDC ) may be connected to the WB100 using the power connector shown: 3. Connect the supplied USB cable between the Echometer Computer and the WB100 USB port. 4. Proceed with setup using the Echometer TAM Software User Manual.
