Specifications - Samsung SyncMaster 2253BW, 2253LW User Manual

Specifications

(2253BW)
General
General
Model Name
LCD Panel
Size
Display area
Pixel Pitch
Synchronization
Horizontal
Vertical
Display Color
16.7M
Resolution
Optimum resolution
Maximum resolution
Input Signal, Terminated
RGB Analog, DVI(Digital Visual Interface) Compliant Digital RGB
0.7 Vp-p ± 5 %
Separate H/V sync, Composite, SOG
TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock
146 MHz (Analog, Digital)
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz
Signal Cable
15pin - to - 15pin D-sub cable, Detachable
DVI-D to DVI-D connector, Detachable
Dimensions (W x H x D) / Weight
513.7 x 352.2 x 61.2 mm / 20.2 x 13.9 x 2.5 inch (Without Stand)
513.7 x 400.3 x 219 mm / 20.2 x 15.8 x 8.6 inch (With Stand) / 5.4 kg / 11.96 Ibs
SyncMaster 2253BW
22 inch (55cm)
473.76 mm (H) x 296.1 mm (V)
0.282 mm (H) x 0.282 mm (V)
30 ~ 81 kHz
56 ~ 75 Hz
1680 x 1050 @ 60 Hz
1680 x 1050 @ 60 Hz
53
