model to a 5.8GHz receiver (Rx) on the ground. Three bands with a total of 22 frequencies in the 5.8GHz spectrum can be user
selected. For optimum use, operate the system away from other 5.8GHz transmitters, in areas having as few obstructions
possible between the Tx and Rx. For best signal, use a clean and stable DC power source (battery, voltage regulator, etc.).
Allow for maximum space from other electronic components such as ESCs and cables, R/C receivers, high power servos,
telemetry radios, etc.
ANTENNA INSTALLATION
Carefully thread the included antenna onto the RP-SMA receptacle on the Tx, being careful not to cross-thread. Turn the mounting
screw until snug – do NOT overtighten. Do NOT apply power to the transmitter if the antenna is disconnected as it could cause
the Tx to overheat!
CONNECT TO CAMERA AND INPUT POWER
The included Y-wire harness connects the Tx to a camera and battery
(both available separately). Attach the adapter's white connector to the Tx.
Connection polarities are as follows:
CAMERA CONNECTION: Attach the white/yellow/black wire
to the camera's A/V signal output. Make sure the polarities
on the camera's input matches those of the adapter. Use
the included gray/yellow/black cable extension with USB
Mini-B plug if necessary.
SELECT THE CHANNEL/FREQUENCY
Refer to the charts below to determine the frequency to transmit the video signal. The frequency number is shown at the
bottom of each switch diagram:
BAND A
ON
ON
ON
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
CH1 5.865G
CH2 5.845G
CH3 5.825G
ON
ON
ON
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
CH5 5.785G
CH6 5.765G
CH7 5.745G
BAND SELECTION: Switches 4 and 5 are used to set either band A, B, or F. Place both switches UP for band A, switch 4 down
and switch 5 up for band B, and both switches DOWN for band F.
CHANNEL SELECTION: Switches 1, 2, and 3 are used to set the frequency. Set each respective switch to the location which
matches that shown in the chart for band A, B, or F, depending on your desired frequency.
Tactic's FPV-T1 first person video
transmitter (Tx) is intended for sending
video signals from a camera (available
separately) mounted inside an R/C hobby
Yellow = Video
White = Audio
Black = Ground
BAND B
ON
ON
ON
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
CH4 5.805G
CH1 5.733G
CH2 5.752G
ON
ON
ON
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
CH8 5.745G
CH5 5.809G
CH6 5.828G
Red
Black
Red = 7.4-22.2V
Yellow
White
Black = Ground
Black
BATTERY CONNECTION: Attach the red/black wire to the
battery. Use the included cable extension with red connector
if necessary. IMPORTANT: Make sure polarities match! Do
NOT exceed the acceptable input voltage range of 7.4 – 22.2
volts, which can be achieved with a 2S-6S lithium-polymer
(LiPo) battery.
ON
ON
1 2 3 4 5
1 2 3 4 5
CH3 5.771G
CH4 5.790G
ON
ON
1 2 3 4 5
1 2 3 4 5
CH7 5.847G
CH8 5.866G
5.8GHZ 25mW TRANSMITTER
To Battery
To Camera
BAND F
ON
ON
ON
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
CH1 5.740G
CH2 5.760G
CH3 5.780G
ON
ON
ON
1 2 3 4 5
1 2 3 4 5
1 2 3 4 5
CH5 5.820G
CH6 5.840G
CH7 5.860G
TM
ON
1 2 3 4 5
CH4 5.800G
ON
1 2 3 4 5
CH8 5.860G
