- Page 1 User’s Guide This page intentionally left blank. Instructions for Installation and Operation Handheld Transmitters Models KTXW303C6-n (where n=1 to 6) Remote Control Receiver w/Relays Model RCR303C6R Long Range Wireless Applications...
- Page 2 (amplified) Dipole Antenna (see Antenna Options table) for the receiver’s standard whip antenna will significantly extend reception range. For The receiver can quickly “learn” up to four Applied Wireless transmitters maximum range performance, the receiver’s antenna (whip or dipole) with different address codes. Alternatively, for applications requiring...
- Page 3 Relay Response Mode Configuration Relay Response Mode Configuration – (continued) Each of the six relays of the RCRC6R remote control receiver may be configured Latched Mode for one of three possible “Response Modes.” A Response Mode defines how a A relay energizes when its associated button on the transmitter is relay functions when that relay’s associated button is pressed on the handheld pressed, and remains energized after the button is released.
- Page 4 Relay Response Mode Configuration – Latched Mode (continued) Learn Mode Instructions The receiver will learn up to 4 transmitter IDs. To learn a transmitter: 1) Power up the receiver, Global Latch Group Any relay 2) Remove the receiver antenna DIP Switch S2-3 ON configured for 3) Press the “Learn”...
- Page 5 Ordering Information Receiver Electrical Characteristics 1 to 6-Button Parameter Unit Frequency (MHz) Receiver Model No. Transmitter Operating Voltage Range (AC or DC) Volts Operating Current, Unactivated 303.825 RCR303C6R KTXW303C6-n Operating Current, All 6 Relays Activated Relay Contact Ratings @ 28VDC Receiver Sensitivity -112 Antenna Options...
- Page 6 Application Circuit – DC Motor Forward/Reverse Circuit This is an example of using the RCRC-6R The following pertains to Model KTXW303C6‐n, where n=number of channels Receiver for wireless forward and reverse FCC ID: QY4KTXW303 remote control of a DC motor. “This device complies with Part 15 of the FCC Rules. Operation is subject to the The wiring diagram shows the motor following two conditions: (1) this device may not cause harmful interference, and (2) ...
- Page 7 IMITED ARRANTY (USA), cont. Products manufactured by APPLIED WIRELESS, This warranty is extended to the original HOW TO OBTAIN WARRANTY SERVICE INC. (AW) and sold to purchasers in the USA are purchaser of the product(s) only, and is not...
- Page 8 ANTENNA REMOVED. Re-Boot Needed Remove power from receiver for at least 5 seconds. with pride in the United States of America Copyright 2007 by Applied Wireless, Inc. All rights reserved. Specifications subject to change without notice. PPLIED IRELESS 1250 Avenida Acaso, Camarillo, CA 93012 Phone: 805-383-9600 Fax: 805-383-9001 Email: info@appliedwireless.com...
