Ordering Information: Disposable BiPolar EHL Probes


9-195-371......1.9fr. (0.63mm) Biliary Probe (375cm)(Sterile) 1/Box

9-195-25 ......1.9fr. (0.63mm) Biliary Probe (250cm)(Sterile) 1/Box

9-196-12 ..... 1.9fr. (0.63mm) Ureteral Probe (120cm)(Sterile) 3/Box

9-900-54 ..... 9.0fr. (3.0mm) Urinary Bladder Probe (54cm)(Sterile) 3/Box

9-001-00 ..... Pneumatic Foot Switch

9-002-00 ..... Extender Cable

9-003-00 ..... U.S. Power Cord
82-00040-1 Rev. B

Frequency of Shots

This adjusts how fast the selected number of shots are
delivered. For stones that are free to move or bounce
away, select fewer shots at a higher frequency.
of 30 shots per second is the highest (fast) frequency
setting. A rate of
frequency setting.

Number of Shots

Again, if the stone can move or bounce away, select
fewer shots. A maximum of 60 shots delivered over 2
seconds is the maximum number of shots that can be
fired with 1 foot-pedal depression.
Suggested setting: 3-5 shots per foot-pedal
depression.
Keeping the probe tip 1-2mm
from the stone surface is ideal.
• Press the
Standby
unintentional probe firings. This feature is
useful if the scope and EHL probe are brought
outside of the body.
• Press
Total Shots
have been discharged.
™/® trademarks and registered trademarks of or used under license by NORTHGATE Technologies Inc.
Northgate Technologies Inc. • 1591 Scottsdale Court • Elgin Illinois 60123
Toll Free 800 348-0424 • 847 608-8900 • www.northgate-tech.com
1 shot per second is the slowest
Suggested setting: 30/sec.
The OUTPUT light will flash every time a shot has been triggered.

Note:

• Using higher power settings and a higher number of shots
may reduce probe life.
• The most effective stone fragmentation occurs with the end
of the EHL probe 1-2mm from the stones surface.
button to avoid
to see how many shots
A rate
