Summary of Contents for Kenco KLCE-DPDT
- Page 3 (Slotted universal adapter), (Post mounted adapter) AND – FS OPTIONS Attach the controller to the mounting adapter using the Kenco supplied bolts (and washers if applicable). The recommended 20 ft-lbs torque for the bolts is Mount the controller so that the centerline of the sight window corresponds to the running oil level in the crankcase. Connect the hose from the ¾”...
- Page 4 JGC/JGD 6 cylinder with standard shaft rotation and a dual chain drive) AND –FS OPTIONS Remove the sight glass located on the crankcase and replace it with the oil controller assembly using the sight glass mounting bolts and Kenco supplied gasket. –1 –2 OIL LEVEL CONTROLLERS WITH (Clark MA &...
- Page 5 For -17, -18, -37, -38, -39, & -40, install the O-ring into the groove of the Kenco door and replace the clamp bar on the back side of the door using the bolts, washers, and O-rings supplied by Kenco.
- Page 6 III. INSTALLATION INSTRUCTIONS FOR FIRE SAFE VALVES: MODEL 50-KFS AND 75-KFS (PATENT NO. 3,877,476) NOTE: All lines between thermal valves, supply tanks and the controller must be made of steel. DO NOT use rubber hose. The lines should be 3/4” I.D. ...
