Onyx VENUS-191 User Manual

22”/19” lcd with led backlight intel n2800 dual core processor mobile cart computer
Hide thumbs
Table of Contents

Advertisement

Quick Links

M o b i l e C a r t C o m p u t e r
V E N U S 1 9 1 / 2 2 1
VENUS-221/191
22"/19" LCD with LED Backlight
®
Intel
N2800 Dual Core Processor
Mobile Cart Computer
User Guide
VENUS-221/VENUS-191 Manual 1st Ed
May, 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VENUS-191 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onyx VENUS-191

Summary of Contents for Onyx VENUS-191

  • Page 1 M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 VENUS-221/191 22”/19” LCD with LED Backlight ® Intel N2800 Dual Core Processor Mobile Cart Computer User Guide VENUS-221/VENUS-191 Manual 1st Ed May, 2014...
  • Page 2 ONYX Healthcare Inc., assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein ONYX Healthcare Inc. reserves the right to make changes in the product design without notice to its users...
  • Page 3 If any of these items are missing or damaged, you should contact your distributor or sales representative immediately. Headquarters Onyx Healthcare Inc. 2F, No.135, Lane 235, Pao-Chiao Rd., Hsin-Tien City, Taipei 231, Taiwan, R.O.C. TEL: +886-2-8919-2188 FAX: +886-2-8919-1699 E-mail: sales@onyx-healthcare.com http://www.onyx-healthcare.com Worldwide Offices: Onyx Healthcare, USA Inc. 324 W. Blueridge Ave.,...
  • Page 4 Fax: +31-(0)499-462010 Email: eusales@onyx-healthcare.com e-FAE@onyx-healthcare.com (RMA) Onyx Healthcare Technology GmbH An der Trift65d 63303 Dreieich , Germany TEL: +49-(0)61033-7479-00 Fax: +49-(0)61033-7479-49 Email: eusales@onyx-healthcare.com e-FAE@onyx-healthcare.com (RMA) Onyx Healthcare (SU ZHOU) INC. Room 12, 2F, Building B, No.5 Xing Han Street, Suzhou Industrial...
  • Page 5 M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 Park, Jiang Su Province, China Tel: +86-512-67625700 Fax: +86-512-67617337 Email: cnsales@onyx-healthcare.com...
  • Page 6 M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 Safety & Warranty 1. Read these safety instructions carefully. 2. Keep this user's manual for later reference. 3.
  • Page 7 M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 12. If the equipment is not used for a long time, disconnect it from the power source to avoid damage by transient over-voltage.
  • Page 8 M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 with the standard IEC 60601-1-1, Safety requirements for medical electrical systems. Equipment not complying with UL 60601-1 shall be kept outside the patient environment, as defined in the standard.
  • Page 9 M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 Classification 1. Degree of production against electric shock: not classified 2.
  • Page 10 M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 This device complies with Part 18 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference...
  • Page 11 M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 UL Module Description VENUS-191 / 221 modules are developed to suitable for the Classification Mark requirement...
  • Page 12 M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 Safety Symbol Description The following safety symbols are the further explanations for your reference.

  • Page 13: Table Of Contents

    1.3 Specification ..............16 1.4 Dimension ................ 20 Chapter 2 Hardware Installation 2.1 Safety Precautions .............. 2.2 Quick Tour of the VENUS-191 ..........2.3 Turn On and Boot up into Windows……………………….. 2.4 Turn off………………………………………………………….. Chapter 3 Driver Installation 3.1 Driver installation……………………………………………….

  • Page 14: Chapter 1 General Information

    M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 Chapter General Information...

  • Page 15: Introduction

    Germs have no corners to hide in while cleaning because of smooth and seamless surface design. VENUS-191/221 owns side mount two USB 3.0 ports, and a smart card reader to support high speed data transfer and ID check by smart card reader.

  • Page 16: Feature

    M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 1.2 Feature ® Intel N2800 1.86GHz Dual Core Processor  19”...

  • Page 17: Specification

    M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 1.3 Specification Hardware Specifications VENUS-221: 21.5” 1366x768 LCD Display VENUS-191: 19” 1280x1024 LCD ® Intel N2800 1.86GHz 2.5” SATA Solid State Drive Disk Drive...
  • Page 18 M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 Touch Screen Specification Type 5-wire Resistive Interface USB interface Light Transmission >...
  • Page 19 EN 60601-1 Note: All ONYX LCD products are manufactured with High precision technology. However, there are a small number of defective pixels in all LCD panels that are not able to change color. This is a normal occurrence for all LCD displays from all manufacturers and should not be noticeable or objectionable under normal operation.

  • Page 20: Dimension

    M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 1.4 Dimension VENUS-191 Chapter 2 Hardware Installation...
  • Page 21 M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 VENUS-221 Chapter 2 Hardware Installation...

  • Page 22: Chapter 2 Hardware Installation

    M o b i l e C a r t C o m p u t e r V E N U S 1 9 1 / 2 2 1 Chapter Hardware Installation Chapter 2 Hardware Installation...

  • Page 23: Safety Precautions

    M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 2.1 Safety Precautions Always completely disconnect the power cord from your board whenever you are working on it.

  • Page 24: Quick Tour Of The Venus-191

    V E N U S - 1 9 1 / 2 2 1 2.2 Quick Tour of the VENUS-191 / 221 Before you start to set up the VENUS-191 / 221 take a moment to become familiar with the locations and purposes of the controls, drives, connections and ports, which are illustrated in the figures below.
  • Page 25 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 Picture 2-2-2: Front View of the VENUS-221 Chapter3 Award BIOS Setup 3...
  • Page 26 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 5 Smart Program Keys ICON VENUS-191/ VENUS-221 One touch for reading light on/off One touch for screen on/off One touch for LCD brightness down...
  • Page 27 Display Port, the Ethernet ports, USB ports, the microphone jack, and so on.) The Cart Mobile Computer integrates WLAN function by using Mini Card. VENUS-191 / 221 Picture 2-2-3: back view of the VENUS-191 /221 Chapter3 Award BIOS Setup 3...
  • Page 28 When you turn the Mobile Cart Computer around and look at its right/left side, two USB 3.0 ports, the smart card reader and Lithium Battery are as shown in Picture 2-2-4. Picture 2-2-4: Side view of the VENUS-191/221 Chapter3 Award BIOS Setup 3...

  • Page 29: Turn On And Boot Up Into Windows

    M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 2.3 Turn On and Boot up into Windows OS This section is for Windows operating system only.

  • Page 30: Chapter3 Driver Installation 3

    M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 Chapter Driver Installation Chapter3 Driver Installation 3...
  • Page 31 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 3.1 Driver installation There are several installation ways depending on the driver package under different Operating Systems.
  • Page 32 All rights are reserved. No part of this document may be photocopied, reproduced or translated to another language without prior written consent of ONYX Healthcare Company. Other important information ONYX-Healthcare Company reserves the right to change or amend this user guide at any time without notice. Appendix A Miscellanea A-2...
  • Page 33 Installing the sBMS control software Run the Setup exe. Application in the installer folder on your Setup CD or driver also can be found on our website http://www.onyx-healthcare.com/ServicesSupport.php Click “Next” at the Welcome to the Onyx-Healthcare SBMS setup wizard. Appendix A Miscellanea A-3...
  • Page 34 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 Choose the destination folder where the application will be installed. Select start menu folder and click the “Next”...
  • Page 35 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 Appendix A Miscellanea A-5...
  • Page 36 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 Select additional tasks if you would like to create an icon on the screen.
  • Page 37 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 Click “Install” for running installation process. Appendix A Miscellanea A-7...
  • Page 38 V E N U S - 1 9 1 / 2 2 1 You have now successfully installed the software. Click the “Finich” button to exit the installation. You can run Onyx-Healthcare sBMS control software now. Appendix A Miscellanea A-8...
  • Page 39 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 Explanation of symbols Symbol Function Feature -Battery bar displaying 3 colors of green, yellow and purple.
  • Page 40 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 ONYX contact information Service information Appendix A Miscellanea A-10...
  • Page 41 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 SBMS control panel Power status: AC mode means switch the powered from power adaptor, DC mode means switch the powered from lithium batteries.
  • Page 42 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 Remind Alarm Two primary levels protection of remaining alarm SBMS provide you flexibility of setting alarm, you can set reminder in two ways to replace the batteries as below table.
  • Page 43 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 Tool List This page can show you how to set up and use multiple language input options on your computer.
  • Page 44 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 Information: Design capacity: Basically the amount of charge. Relative status of charge: The direct way to measure the status of charge (SOC) of a lithium-ion battery gives the relative value of its charge.

  • Page 45: Appendix A Miscellanea

    M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 Appendix Miscellanea Appendix A Miscellanea A-15...

  • Page 46: General Cleaning Tips

    M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 A.1 General Cleaning Tips You may need the following precautions before you begin to clean the computer.

  • Page 47: Cleaning Tools

    M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1 A.2 Cleaning tools Although many companies have created products to help improve the process of cleaning your computer and peripherals users can also use household items to clean their computers and peripherals.
  • Page 48 M o b i l e C a r t C o m p u t e r V E N U S - 1 9 1 / 2 2 1  Cotton swabs - Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas in your keyboard, mouse, and other locations.

  • Page 49: Scrap Computer Recycling

    For the computers that are no longer useful or work well, please contact with worldwide distributors for recycling. The worldwide distributors show on the following website: http://www.onyx-healthcare.com.tw/Contact.php Note: Follow the national requirement to dispose unit Appendix A Miscellanea A...
