- Page 1 Simplicity® LED Light Post Mount User Manual...
-
Page 2: Table Of Contents
Cleaning & Disinfecting .................... 9 Section V User Service Information Troubleshooting .......................10 Service Instruction ....................10 Disposal of Equipment .....................11 Section VI Parts List/Diagrams Light Head Assembly ....................12 Transformer......................12 Limited Warranty ....................13 Wiring Schematic ....................14 EMC Information ....................15-16 www.DentalEZ.com www.DentalEZ.com 866-DTE-INFO (opt 3) -
Page 3: Section I Introduction
Leave this manual in the doctor's off ice. Operation: Temperature range of + 10º C to + 40º C The Simplicity® LED Light is intended to be used Relative humidity range of 30% to 75% by trained professional dental care personnel to... -
Page 4: Explanation Of Symbols And Signs
41 Blackwell Drive, Braintree Business Park, = Refer to Manual (follow instructions) Braintree Essex, CM7 2PU, UK Phone: +44 (0)1787 877 877 ext. 200 = Serial Number = Manufacture Date = Manufacturer = European Certifi cation www.DentalEZ.com www.DentalEZ.com 866-DTE-INFO (opt 3) -
Page 5: Dimensions
Section I Introduction Light User Manual Dimensions Post Mount 23-1/2" 23-1/2" 5" 8" 3-1/2" 1.701" www.DentalEZ.com www.DentalEZ.com 866-DTE-INFO (opt 3) -
Page 6: Packaging
Section I Introduction Packaging Features The Simplicity® LED Light components are packaged and shipped according to the pack- Light Arm ing list below. Please verify the carton contents Assembly against the packing list. Post Mount • Light Head & Arm Assembly •... -
Page 7: Section Ii Installation
Light Post NOTICE Isolating the light from the supply mains is accomplished by unplugging the light from its power supply. NOTICE Installation by an authorized DentalEZ dealer service technician is recommended. www.DentalEZ.com www.DentalEZ.com 866-DTE-INFO (opt 3) - Page 8 2. Remove the four #10 screws that secure the utility service center (USC) cover and take off the cover. (When mounting to a Simplicity Unit, remove the magnetic cover.) 3. Plug the umbilical harness into the adapter harness.
-
Page 9: Section Iii Operation
Levels will adjust from low, to medium, NOTICE then high and back. To take full advantage of the Simplicity® LED Light's intensity and color correction, position the light between 50.8 cm (20") and 114.3 cm (45") away from the oral cavity. -
Page 10: Section Iv Care
Do not use abrasive material or steel wool when cleaning. NOTICE Under normal use, there is no routine mainte- nance required. NOTICE Use of BactSpray cleaner is highly recommend- ed, or any other cleaning product that has the active component Benzalkonium chloride. www.DentalEZ.com www.DentalEZ.com 866-DTE-INFO (opt 3) -
Page 11: Section V User Service Information
• Model Name ___________________________ • Model Number _________________________ The chart below should be used when trouble- shooting Simplicity® LED Light problems. If these • Serial Number__________________________ suggested troubleshooting procedures do not • Installation Date ________________________ resolve the problem, see the Service Instruction •... -
Page 12: Disposal Of Equipment
Section V User Service Information Disposal of Equipment Disposal and Decommissioning of DentalEZ product Note: All local regulatory requirements for dis- posal and decommissioning of equipment apply. Electrical Salvage: Remove all circuit board and electrical cabling for recycle as electrical salvage. -
Page 13: Section Vi Parts List/Diagrams
Section VI Parts list/Diagrams Light User Manual www.dentalezparts.com Light Head Assembly Part/Kit Name Part/Kit No. 1 Light Head 3802-581 Transformer Part/Kit Name Part/Kit No. 2 Transformer 3801-804 www.DentalEZ.com www.DentalEZ.com 866-DTE-INFO (opt 3) -
Page 14: Limited Warranty
Simplicity LED Light DentalEZ and its employees are proud of the products we provide to the dental community. We stand behind these products with a warranty against defects in material and workmanship as provided below. In the event that you experience diff iculty with the application or operation of any of our products, please contact our Technical Service Department at our expense at 1-866-DTE-INFO (1-866-383-4636). -
Page 15: Wiring Schematic
Light User Manual Wiring Schematic www.DentalEZ.com www.DentalEZ.com 866-DTE-INFO (opt 3) -
Page 16: Emc Information
GUIDANCE AND MANUFACTURER’S DECLARATION – ELECTROMAGNETIC EMISSIONS The Simplicity LED Light is intended for use in the electromagnetic environment specifi ed below. The customer or the user of the Simplicity LED Light should assure that it is used in such an environment. -
Page 17: Emc Information
GUIDANCE AND MANUFACTURER’S DECLARATION – ELECTROMAGNETIC IMMUNITY The Simplicity LED Light is intended for use in the electromagnetic environment specifi ed below. The customer or the user of the Simplicity LED Light should assure that it is used in such an environment. - Page 18 2500 Highway 31 South Bay Minette, Alabama 36507 866-DTE-INFO (opt 3) www.dentalez.com © DentalEZ® Alabama, Inc. Printed in USA PN: 2717-270B June, 2018...
