Setting the jumper pin

Setting the jumper pin
Before installing the Samsung hard disk drive, the jumpers must be set to match the configuration of your computer system.
Refer to the following diagram for instructions on setting the jumper pins.
General Configuration 32GB Clip Configuration
Master Slave Cable Select Master Slave Cable Select
*General configuration setting as "Slave" is "Remove the jumper" *32GB Clip Configuration "Slave" is set as above
