Perfection in cooking and more...
hood
VISION VeNt 2
techNIcal dOcumeNtatION
read thIS maNual befOre uSe

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VISION vent 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Retigo VISION vent 2

  • Page 1 Perfection in cooking and more... hood VISION VeNt 2 techNIcal dOcumeNtatION read thIS maNual befOre uSe...
  • Page 3: Table Of Contents

    Technical documentation I  Vision Vent 2 Hood I  Contents CoNTENTS baSiC iNformaTioN ..........................5 prEamblE .............................................5 1. abouT ThiS maNual ........................................5 2. uSiNg aNd opEraTiNg ThE hood ..................................6 3. uNiNTENdEd uSE ..........................................6 4. imporTaNT iNformaTioN ......................................6 5. uSiNg ThE opEraTiNg maNual ....................................6 6.
  • Page 5: Basic Information

    Technical documentation I  Vision Vent 2 Hood I  Basic information baSiC iNformaTioN iN case of doubt, don't hesitate to contact our highly trained specialists: preamble prOfeSSIONal SaleSpeOple: +420 603 571 360 +420 604 568 562 rETigo s.r.o. thanks you for choosing a  retigo product! your new appliance brings together years of experience with the best professional chefs and state-of-the-art science and technology.
  • Page 6: Using And Operating The Hood

    5.1 SymbOlS uSed 4.
  • Page 7: Limitation Of Liability

    Technical documentation I  Vision Vent 2 Hood I  Basic information ČSN EN 61000-6-2 ed.3:06 • ČSN EN 61000-6-4 ed.2:07+a1:11 • act No 22/1997, government regulation NV 17/2003 and • 616/2006. directives of the European Council: 2006/95/EC and 2004/ • 108/EC.
  • Page 8: Safety Instructions

    Technical documentation I  Vision Vent 2 Hood I  Safety instructions SafETy iNSTruCTioNS 1. geNeral Safety INfOrmatION This documentation contains the information required for suitable use of the product described. knowledge and application of the safety instructions and warnings in this documentation are a ...
  • Page 9: Technical Information

    Technical documentation I  Vision Vent 2 Hood I  Technical information TEChNiCal iNformaTioN 1. maIN techNIcal characterIStIcS 0610 hood weight: 60 kg dimensions (height, width, depth): 1126 x 939 x 409 mm Noise level – min/max: 63 db/ 68 db /hour...
  • Page 10 Technical documentation I  Vision Vent 2 Hood I  Technical information 2011 hood weight: 60 kg dimensions (height, width, depth): 1133 x 953 x 410 mm Noise level – min/max: 63 db/ 68 db maximum air flow: 1000 m /hour maximum power consumption:...
  • Page 11 Technical documentation I  Vision Vent 2 Hood I  Technical information 623 hood weight: 40 kg dimensions (height, width, depth): 633 x 689 x 259 mm Noise level – min/max: 46 db/ 50 db maximum air flow: 760 m /hour maximum power consumption:...
  • Page 12: Nameplates Of 0610, 2011 And 623 Hoods

    Technical documentation I  Vision Vent 2 Hood I  Technical information 2. NameplateS Of 0610, 2011 aNd 623 hOOdS The nameplate is located on the left side of the hood, at the bottom. The nameplate states the manufacturer of the appliance, technical information and marks indicating that the product fulfils the applicable standards.
  • Page 13: Transport And Installation

    Technical documentation I  Vision Vent 2 Hood I  Transport and installation TraNSporT aNd 3. INStallINg the applIaNce iNSTallaTioN operate the appliance only in perfect condition. do not remove any safety equipment such as covers etc. do not modify the appliance in any way.
  • Page 14 Technical documentation I  Vision Vent 2 Hood I  Transport and installation fit the 0610 hood onto the appliance, taking care to correctly • connect the hood input (the tube at the back of the hood) onto the appliance’s flue - see fig. 2. due to the weight of the hood, a sufficient number of persons will be needed for this operation.
  • Page 15: Electrical Connections For An 0610 Or 2011 Hood

    Technical documentation I  Vision Vent 2 Hood I  Transport and installation 4. electrIcal cONNectIONS fOr aN 0610 Or 2011 hOOd The hood may be connected only to a normalized voltage network, whose parameters match the data listed on the hood’s nameplate. The hood must be protected by a fuse of up to 16a.
  • Page 16 Technical documentation I  Vision Vent 2 Hood I  Transport and installation pOwerINg frOm a fIxed electrIcal cONNectION attach the free end of the cable to the fixed electrical supply, which must contain a multi-pole breaker device (switch) with a minimum distance of 3mm between the contacts.
  • Page 17 Technical documentation I  Vision Vent 2 Hood I  Transport and installation figure 12: positioning the plastic spacers Screw the diN rail with fuse and terminals from the hood set (1) onto the back of the electrical board in the prepared openings using m4x10 bolts and the cushioning pads and nuts (part of the set) (see fig.
  • Page 18: Electrical Connections For A 623 Hood

    Technical documentation I  Vision Vent 2 Hood I  Transport and installation 5. electrIcal cONNectIONS fOr a 623 hOOd The hood may be connected only to a normalized voltage network, whose parameters match the data listed on the hood’s nameplate. The hood must be protected by a fuse of up to 16a.
  • Page 19 Technical documentation I  Vision Vent 2 Hood I  Transport and installation figure 18: loosening the control panel attach the fuse holders and terminal from the hood set to the diN rail (1) at the front of the electrical board (see fig. 19) figure 17: fitting the uTp cable into the rJ-45 port 5.
  • Page 20: Fitting A 0610 Hood Onto A Configuration Of Two Appliances

    Technical documentation I  Vision Vent 2 Hood I  Transport and installation 6. fIttINg a 0610 hOOd ONtO a cONfIguratION Of twO applIaNceS mOdIfIcatION Of the hOOd remove the hood from its transport packaging and set it on its side on one of the polystyrene packages. The standard hood is produced and delivered for use on one appliance.
  • Page 21: Hood Settings And Controls

    Technical documentation I  Vision Vent 2 Hood I  Transport and installation 7. hOOd SettINgS aNd cONtrOlS mOdel blue on the main screen, press the button “SETTiNgS” 4. “Enter your service piN“ 2. Select “SErViCE” 3. Select “CoNfiguraTioN” 5. Select “hood”...
  • Page 22 Technical documentation I  Vision Vent 2 Hood I  Transport and installation cONtrOllINg the hOOd IN the dIagNOStIcS (fOr teStINg purpOSeS) on the main screen, press the button “SETTiNgS” 2. Select “SErViCE” 3. Select “diagNoSTiCS” 4. Select “hood” 5. The hood’s motor can now be set to a lower or higher speed.
  • Page 23: Fault Report In Connection With The Hood

    Technical documentation I  Vision Vent 2 Hood I  Transport and installation mOdel OraNge cONtrOllINg the hOOd IN the dIagNOStIcS (fOr teStINg purpOSeS) hold down the buttons and  hold down buttons 2. Enter the service piN. using the buttons enter 2. use buttons to enter your service the number which is flashing up on the screen.
  • Page 24: Maintenance And Cleaning

    Technical documentation I  Vision Vent 2 Hood I  Maintenance and cleaning maiNTENaNCE aNd rETigo recommends using a servicing firm for cleaning and regular inspections of the appliance. ClEaNiNg only regular inspection and cleaning can prevent wear and tear and possible damage to the appliance.
  • Page 26 Perfection in cooking and more... RETIGO s.r.o. láň 2310 756 61 rožnov pod radhoštěm Email: info@retigo.cz Tel.: +420 571 665 511 www.retigo.cz TSd_15_h_EN_r01...
