IBASE Technology MPT-7000V User Manual

Multi-purpose in-vehicle system
Hide thumbs Also See for MPT-7000V:
Table of Contents

Advertisement

Quick Links

Download this manual
MPT-7000V
Multi-Purpose In-Vehicle System
User's Manual
Version 1.1
(Sep. 2018)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPT-7000V and is the answer not in the manual?

Questions and answers

Related Manuals for IBASE Technology MPT-7000V

Summary of Contents for IBASE Technology MPT-7000V

  • Page 1 MPT-7000V Multi-Purpose In-Vehicle System User’s Manual Version 1.1 (Sep. 2018)
  • Page 2 No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc. (hereinafter referred to as “IBASE”).

  • Page 3: Compliance

    0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by weight (100 ppm). • Lead (Pb) • Mercury (Hg) • Cadmium (Cd) • Hexavalent chromium (Cr6+) • Polybrominated biphenyls (PBB) • Polybrominated diphenyl ether (PBDE) MPT-7000V User Manual...

  • Page 4: Important Safety Information

    You are not suggested to disassemble, repair or make any modification to the device. Disassembly, modification, or any attempt at repair could generate hazards and cause damage to the device, even bodily injury or property damage, and will void any warranty. MPT-7000V User Manual...

  • Page 5: Caution

    Software in use (such as OS and application software, including the version numbers) 3. If repair service is required, you can download the RMA form at http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and contact your distributor or sales representative. MPT-7000V User Manual...

  • Page 6: Table Of Contents

    Jumper & Connector Locations on Motherboard ........25 Jumpers Quick Reference ..............27 2.4.1 COM1 & COM2 Voltage Selection (JP1, JP2) ...... 27 2.4.2 ME Register Clearance (J12) ..........28 2.4.3 CMOS Data Clearance (J14) ..........28 MPT-7000V User Manual...
  • Page 7 Management Engine Driver Installation ........51 USB 3.0 Driver Installation ..............53 Chapter 4 BIOS Setup ................55 Introduction ................... 56 BIOS Setup ................... 56 Main Settings ..................57 Advanced Settings ................58 4.4.1 ACPI Settings ................. 59 MPT-7000V User Manual...
  • Page 8 Save & Exit Settings................75 Appendix ...................... 76 I/O Port Address Map ................77 Interrupt Request Lines (IRQ) ............... 77 Watchdog Timer Configuration .............. 78 Software Development Kit for WDT.DLL ..........82 Motherboard MCU ISP Specifications ........... 88 viii MPT-7000V User Manual...

  • Page 9: Chapter 1 General Information

    Chapter 1 General Information The information provided in this chapter includes: • Features • Packing List • Specifications • Overview • Dimensions...

  • Page 10: Introduction

    1.1 Introduction The MPT-7000V is a vehicle-mounted product IBASE embedded computing Core™ i7/i3 ® system. It is a robust, rugged and fanless design with an Intel ® processor and an Intel I210 Ethernet controller. This product provides high- speed data transmission and reliable connection when subject to shock or vibration.

  • Page 11: Packing List

    General Information 1.3 Packing List Your MPT-7000V package should include the items listed below. If any of the items below is missing, contact the distributor or the dealer from whom you purchased the product. Item Q’ty IBASE P/N MPT-7000V Mounting Bracket...

  • Page 12: Specifications

    3.6 kg (7.94 lb) Certificate CE, FCC Class B, E-Mark I/O Ports 2 x GbE LAN • 2 x USB 3.0 • 2 x USB 2.0 2 x 2.5” drive bay SATA 2 x SATA III ports MPT-7000V User Manual...
  • Page 13 For SSD: 2.26 grms, 5 ~ 500 Hz (Z-axis) Protection • For HDD: 1.04 grms, 5 ~ 500 Hz (Z-axis) • Operating: 20G, 11 msec (Z-axis) Shock • Protection Non-operating: 40G, 11 msec (Z-axis) All specifications are subject to change without prior notice. MPT-7000V User Manual...

  • Page 14: Overview

    1.6 Overview Front View No. Name Name LED Indicators USB 3.0 Receptacles Reset Button CFast / SIM Card Slot Door Secondary Microphone Input Antenna Holes Secondary Line-out SSD Drive Bays MPT-7000V User Manual...
  • Page 15 DC Input Connector LAN Ports with LED Indicators UPS Battery / DC 12V Output DVI-D Port COM3 / CAN (Optional) USB 2.0 Ports VGA Port First Microphone Input COM1 & COM2 Ports First Line-out Expansion Card Slot Oblique View MPT-7000V User Manual...

  • Page 16: Device Dimensions

    1.7 Device Dimensions Unit: mm 1.8 Fuse Dimensions ® ® Littlefuse TAC ATO Style Blade 15A, 58V DC MPT-7000V User Manual...

  • Page 17: Chapter 2 Hardware Configuration

    Chapter 2 Hardware Configuration The information provided in this chapter includes: • Essential installations • Information and locations of connectors...

  • Page 18: Essential Installations

    If you need to replace or install the modules, perform the following steps: Loosen the following 4 screws to pull out the SSD trays. Turn your MPT-7000V upside down. Remove the following 4 screws to open the front I/O cover.
  • Page 19 To remove the module, press the clips outwards with both hands. After installation, tighten the 8 screws mentioned in Step 2 to secure the device. MPT-7000V User Manual...

  • Page 20: Storage Installation

    Release 2 screws to pull out an SSD tray (4 screws for 2 trays). Put your 2.5” SSD onto the tray(s), and secure the SSD with the supplied 4 screws for each tray. Tray 4 screws Put and secure the tray(s) back to the device. MPT-7000V User Manual...
  • Page 21 Installation for M.2 SATA Card Release the following 4 screws to pull out the SSD trays. Turn your device upside down. Remove 4 screws to remove the front I/O cover. Remove the following 8 screws to open the whole bottom cover. MPT-7000V User Manual...
  • Page 22 Put the supplied thermal pad (the thin one) onto the M.2 card and secure the heatsink back with 4 round head screws. After installation, secure the bottom cover and front I/O cover and put back the SSD trays. MPT-7000V User Manual...

  • Page 23: Cfast & Micro-Sim Card Installation

    CFast & micro-SIM card door. Then refer to 2.1.4 Mini-PCIe & M.2 Network Cards Installation for further installation. To remove the micro-SIM card, push the card again. → MPT-7000V User Manual...

  • Page 24: Mini-Pcie & M.2 Network Cards Installation

    For M.2 card installation, you need to remove the whole bottom cover by referring to the section Installation for M.2 SATA Card in 2.1.2 Storage Installation. If the device is half open already, open the other half by removing 4 screws below. MPT-7000V User Manual...

  • Page 25: Wifi / 3G / 4G Antenna Installation

    1. Thread and fasten the hex nut and the 2. Apply adhesive around here. washer. Then install the antenna. Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC). MPT-7000V User Manual...

  • Page 26: Pcie (X16) Expansion Card Installation

    Remove the following 6 screws to half open the bottom cover after you remove the front I/O cover. Remove 2 screws on the rear I/O cover to take out the PCIe expansion bracket. Then remove a screw to separate the PCIe expansion bracket and its shield. MPT-7000V User Manual...
  • Page 27 Install the bracket with the card back to the device and tighten 2 screws on the rear I/O cover to fix the bracket. After installation, tighten 7 screws mentioned in Step 1 to secure the half bottom cover. MPT-7000V User Manual...

  • Page 28: Mounting Brackets Installation

    When mounting, ensure that you have enough room for power and signal cable routing. And have good ventilation for power adapter. The method of mounting must be able to support weight of the MPT-7000V plus the suspend weight of all the cables to be attached to the system. Use the following...
  • Page 29 Turn your MPT-7000V upside down, attach the mounting brackets to MPT-7000V, and secure with the supplied 4 screws as below. Prepare at least 4 screws (M3, 6 mm) to mount MPT-7000V on wall . 4 screws You can install MPT-7000V on plastic (LCD monitor), wood, drywall surface over studs, or a solid concrete or metal plane directly.

  • Page 30: Pinout For Com Ports, Power Input & Gpio Connectors

    COM2 / COM3 RS-232 Ports Assignment Assignment DCD, Data carrier detect DSR, Data set ready RXD, Receive data RTS, Request to send TXD, Transmit data CTS, Clear to send DTR, Data terminal ready RI, Ring indicator Ground MPT-7000V User Manual...
  • Page 31 DO NOT connect a DC source to be used as the UPS voltage input. This could damage the system. This connector has a charging feature. Assigment Assigment Ground Ground 12V Out • GPIO Connector (terminal block) Assignment Assignment Ground DIO4 DIO1 DIO5 DIO2 DIO6 DIO3 Ground MPT-7000V User Manual...

  • Page 32: Setting The Jumpers

    1 2 3 When two pins of a jumper are encased in a jumper cap, this jumper is closed, i.e. turned On. When a jumper cap is removed from two jumper pins, this jumper is open, i.e. turned Off. MPT-7000V User Manual...

  • Page 33: Jumper & Connector Locations On Motherboard

    Hardware Configuration 2.3 Jumper & Connector Locations on Motherboard Motherboard: MBT-7001V COM1 COM4 COM2 COM3 72 71 PCIE1 72 71 PCIE2 J16 J18 Battery CN10 CN13 CN14 CN11 CN12 CN15 CN16 MBT-7001V - top MPT-7000V User Manual...
  • Page 34 Intel ® Gen. Core™ i7-6600U MBT-7001V - bottom MPT-7000V User Manual...

  • Page 35: Jumpers Quick Reference

    Connector Name Page COM1 & COM2 Voltage Selection JP1, JP2 ME Register Clearance CMOS Data Clearance Flash Descriptor Security Override Selection 2.4.1 COM1 & COM2 Voltage Selection (JP1, JP2) (for COM1) (for COM2) Function Pin closed Illustration (default) MPT-7000V User Manual...

  • Page 36: Me Register Clearance (J12)

    2.4.2 ME Register Clearance (J12) Function Pin closed Illustration Normal (default) Clear ME Register 2.4.3 CMOS Data Clearance (J14) Function Pin closed Illustration Normal (default) Clear CMOS MPT-7000V User Manual...

  • Page 37: Flash Descriptor Security Override Selection (J15)

    Hardware Configuration 2.4.4 Flash Descriptor Security Override Selection (J15) Function Pin closed Illustration No override Open (default) Override Close MPT-7000V User Manual...

  • Page 38: Connectors Quick Reference

    Future Connector for CAN Module Connection M.2 B3042 USB2.0 Interface J17 (interrelated with CN14) Half-Size Mini-PCIe USB2.0 Connector Full-Size Mini-PCIe USB2.0 / PCIe J20 (interrelated with CN13) (x1) Connector Reset Button Digital IO Pull High to +5V Switch MPT-7000V User Manual...

  • Page 39: Pcie (X4) Slot (Pcie1)

    LED4 (for MB Power, green) LED5 (for LAN, green) LED6 (for LAN, green) Power Board +12V Connector (Reserved) Power Connector (Reserved) Motherboard Power Button Connector Factory Use Only J7, J13 2.5.1 PCIe (x4) Slot (PCIE1) 2.5.2 Power Module Interface (PCIE2) MPT-7000V User Manual...

  • Page 40: Com Port (Com1, Com2, Com3, Com4)

    2.5.3 COM Port (COM1, COM2, COM3, COM4) COM1 COM4 COM3 COM2 Assignment Assignment Ground 2.5.4 Digital I/O Connector (CN1) Assignment Assignment Ground DIO4 DIO1 DIO5 DIO2 DIO6 DIO3 Ground MPT-7000V User Manual...

  • Page 41: Dvi-D Port (Cn2)

    Hardware Configuration 2.5.5 DVI-D Port (CN2) 2.5.6 Audio Jack (CN6, CN15, CN16) 2.5.7 SATA III Connector (CN7, CN8) MPT-7000V User Manual...

  • Page 42: Cfast Connector (Cn10)

    2.5.8 CFast Connector (CN10) 2.5.9 USB 3.0 Ports (CN11, CN12) 2.5.10 SIM Card Slot (CN13, CN14) CN13 is interrelated with the mini-PCIe slot J20. CN14 is interrelated with the M.2 slot J17. MPT-7000V User Manual...

  • Page 43: Gbe Lan Ports (Cn3, Cn4)

    Hardware Configuration 2.5.11 GbE LAN Ports (CN3, CN4) 2.5.12 USB 2.0 Ports (CN5) 2.5.13 SATA HDD Power Connector (J4, J21) J21: Assignment Assignment Ground Ground +12V MPT-7000V User Manual...

  • Page 44: Crt Connector (J5)

    2.5.14 CRT Connector (J5) Assignment Assignment Green Ground Blue DDCDATA Ground HSYNC Ground VSYNC Ground DDCCLK Ground 2.5.15 M.2 M2280 SATA Interface (J6) MPT-7000V User Manual...

  • Page 45: E2230 Usb2.0 / Pcie (X1) Interface (J8)

    Hardware Configuration 2.5.16 M.2 E2230 USB2.0 / PCIe (x1) Interface (J8) 2.5.17 DDR4 SO-DIMM Socket (J9, J10) MPT-7000V User Manual...

  • Page 46: Future Connector For Can Module Connection (J11)

    2.5.18 Future Connector for CAN Module Connection (J11) Assignment Assignment Ground USB- COM6_TX USB+ COM6_RX Ground 2.5.19 M.2 B3042 USB2.0 Interface (J17) J17 is interrelated with the SIM card slot CN14. MPT-7000V User Manual...

  • Page 47: Half-Size Mini-Pcie Usb2.0 Connector (J19)

    Hardware Configuration 2.5.20 Half-Size Mini-PCIe USB2.0 Connector (J19) 2.5.21 Full-Size Mini-PCIe USB2.0 / PCIe (x1) Connector (J20) J20 is interrelated with the SIM card slot CN13. 2.5.22 Reset Button (SW2) MPT-7000V User Manual...

  • Page 48: Digital Io Pull High To +5V Switch (Sw1)

    2.5.23 Digital IO Pull High to +5V Switch (SW1) Switch to ON to pull high to 5V. Assignment Assignment DIO1 DIO2 DIO3 DIO4 DIO5 DIO6 MPT-7000V User Manual...

  • Page 49: Chapter 3 Driver Installation

    Chapter 3 Driver Installation The information provided in this chapter includes: • ® Intel Chipset Software Installation Utility • VGA Driver Installation • HD Audio Driver Installation • LAN Driver Installation • ® Intel Management Engine Driver Installation • USB 3.0 Driver Installation...

  • Page 50: Introduction

    Chipset drivers should be installed first before the software drivers to install INF files for Plug & Play function for the chipset components. Follow the instructions below to complete the installation. Insert the disk enclosed in the package. Click Intel and then Intel(R) Skylake-U Chipset Drivers. MPT-7000V User Manual...
  • Page 51 Click Yes to accept the software license agreement and proceed with the installation process. On the Readme File Information screen, click Next for installation. The driver has been completely installed. You are suggested to restart the computer changes to take effect. MPT-7000V User Manual...

  • Page 52: Vga Driver Installation

    3.3 VGA Driver Installation Insert the disk enclosed in the package. Click Intel and then Intel(R) Skylake-U Chipset Drivers. Click Intel(R) HD Graphics Driver. MPT-7000V User Manual...
  • Page 53 When the Welcome screen appears, click Next to continue. Click Yes to agree with the license agreement and then click Install for installation. The driver has been completely installed. You are suggested to restart the computer for changes to take effect. MPT-7000V User Manual...

  • Page 54: Hd Audio Driver Installation

    3.4 HD Audio Driver Installation Insert the disk enclosed in the package. Click Intel and then Intel(R) Skylate-U Chipset Drivers. Click Realtek High Definition Audio Driver. MPT-7000V User Manual...
  • Page 55 Driver Installation On the Welcome screen of the InstallShield Wizard, click Next for installation. The driver has been completely installed. You are suggested to restart the computer for changes to take effect. MPT-7000V User Manual...

  • Page 56: Lan Driver Installation

    3.5 LAN Driver Installation Insert the disk enclosed in the package with the product. Click LAN Card and then Intel(R) Skylake-U Chipset Drivers Click Intel(R) PRO LAN Network Drivers.. MPT-7000V User Manual...
  • Page 57 Driver Installation ® On the screen of Intel Network Connections, click Install Drivers and Software.. When the Welcome screen appears, click Next to continue. Accept the license agreement and click Next to continue. MPT-7000V User Manual...
  • Page 58 Tick the checkbox for Drivers to select the related drivers and click Next. When the wizard is ready for installation, click Install. The driver has been completely installed. You are suggested to restart the computer for changes to take effect. MPT-7000V User Manual...

  • Page 59: Intel Management Engine Driver Installation

    Driver Installation ® 3.6 Intel Management Engine Driver Installation Insert the disk enclosed in the package. Click Intel and then Intel(R) Skylake-U Chipset Drivers. Click Intel(R) ME 11.x Drivers. MPT-7000V User Manual...
  • Page 60 When the Welcome screen appears, click Next to continue. Accept the licence agreement and click Next until the installation starts. The driver has been completely installed. You are suggested to restart the computer for changes to take effect. MPT-7000V User Manual...

  • Page 61: Usb 3.0 Driver Installation

    Driver Installation 3.7 USB 3.0 Driver Installation Insert the disk enclosed in the package. Click Intel and then Intel(R) Skylake-U Chipset Drivers. Click Intel(R) USB 3.0 Drivers. MPT-7000V User Manual...
  • Page 62 Accept the license agreement and click Next to continue. On the Readme File Information screen, click Next for installation. The driver has been completely installed. You are suggested to restart the computer for changes to take effect. MPT-7000V User Manual...

  • Page 63: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup This chapter the different settings available in the AMI describes BIOS that comes with the board. The topics covered in this chapter are as follows: • Main Settings • Advanced Settings • Security Settings • Boot Settings •...

  • Page 64: Introduction

    These defaults have been carefully chosen by both AMI and your system manufacturer to provide the absolute maximum performance and reliability. Changing the defaults could make the system unstable and crash in some cases. MPT-7000V User Manual...

  • Page 65: Main Settings

    BIOS Setup 4.3 Main Settings BIOS Setting Description System Date Sets the date. Use the <Tab> key to switch between the data elements. System Time Set the time. Use the <Tab> key to switch between the data elements. MPT-7000V User Manual...

  • Page 66: Advanced Settings

    4.4 Advanced Settings This section allows you to configure, improve your system and allows you to set up some system features according to your preference. MPT-7000V User Manual...

  • Page 67: Acpi Settings

    BIOS Setup 4.4.1 ACPI Settings BIOS Setting Description Enable Hibernation Enables or disables the System ability to Hibernate (OS/S4 Sleep State). This option may not be effective with some OS. MPT-7000V User Manual...

  • Page 68: Power Board Configuration

    Allows to set the delay timer for turning on or Control off the power board. Power On Delay Sets the power-on-delay timer for minutes / (minutes) / (seconds) seconds. Power Off Delay Sets the power-off-delay timer for minutes / (minutes) / (seconds) seconds. MPT-7000V User Manual...

  • Page 69: Super Io Configuration

    J11, and is reserved for future use to connect to CAN module. Watchdog Mode Sets the Watchdog mode as Second or Miniute. Watchdog Timer Sets the Watchdog timer. 00 disables the timer. MPT-7000V User Manual...
  • Page 70 Serial Port 1 Configuration BIOS Setting Description Serial Port Enables / Disables the serial port (COM). Change Settings Selects an optimal settings for the Super I/O device. F81866 Serial Port1 Changes the mode of serial port. Mode Seelct MPT-7000V User Manual...
  • Page 71 BIOS Setup 4.4.3.2. Serial Port 2 Configuration BIOS Setting Description Serial Port Enables / Disables the serial port (COM). Change Settings Selects an optimal settings for the Super I/O device. MPT-7000V User Manual...
  • Page 72 4.4.3.3. Serial Port 3 Configuration BIOS Setting Description Serial Port Enables / Disables the serial port (COM). Change Settings Selects an optimal settings for the Super I/O device. MPT-7000V User Manual...
  • Page 73 BIOS Setup 4.4.3.4. Serial Port 4 Configuration BIOS Setting Description Serial Port Enables / Disables the serial port (COM). Change Settings Selects an optimal settings for the Super I/O device. MPT-7000V User Manual...
  • Page 74 Serial Port 5 Configuration 4.4.3.6. Serial Port 6 Configuration BIOS Setting Description Serial Port Enables / Disables the serial port (COM). Change Settings Selects an optimal settings for the Super I/O device. Device Mode Changes the mode of serial port. MPT-7000V User Manual...

  • Page 75: Hardware Monitor

    Options: Disabled (default). 70 °C, 80 °C, 90 °C Temperatures / Voltages These fields are the parameters of the hardware monitoring function feature of the motherboard. The values are read-only values as monitored by the system and show the PC health status MPT-7000V User Manual...

  • Page 76: Nvme Configuration

    4.4.6 USB Configuration BIOS Setting Description Legacy USB Support Enables / Disables Legacy USB support. • Auto disables legacy support if there is no USB device connected. • Disable keeps USB devices available only for EFI applications. MPT-7000V User Manual...
  • Page 77 Hub descriptor. Generic Flash Disk 8.07 Mass storage device emulation type. Auto enumerates devices according to their media format. Optical drivers are emulated as “CD-ROM”, drives with no media will be emulated according to a drive type. MPT-7000V User Manual...

  • Page 78: Cpu Configuration

    Speed Shift Technology. If enabled, it will expose the CPPC v2 interface to allow for hardware controlled P states. Intel(R) SpeedStep(tm) Enables / Disables to support more than two frequency ranges. Turbo Mode Enables / Disables the turbo mode. MPT-7000V User Manual...

  • Page 79: Sata Configuration

    SATA Mode Selection Selects AHCI / RAID Mode. SATA Controller Speed Indicates the maximum speed that the SATA controller supports. Serial ATA Port 0/1/2 Enables / Disables Serial Port 0/1/2. HotPlug Designates the SATA port as hot pluggable. MPT-7000V User Manual...

  • Page 80: Csm Configuration

    4.4.9 CSM Configuration BIOS Setting Description Network Controls the execution of UEFI and Legacy PXE OpROM. MPT-7000V User Manual...

  • Page 81: Security Settings

    BIOS Setup 4.5 Security Settings BIOS Setting Description Administrator Password Sets an administrator password for the setup utility. User Password Sets a user password. MPT-7000V User Manual...

  • Page 82: Boot Settings

    Sets the system boot order. Hard Disk Drive BBS Specifies the boot device priority sequence from Priorities available Hard Disk Drives. USB Key Drive BBS Specifies the boot device priority sequence from Priorities available USB key drives. MPT-7000V User Manual...

  • Page 83: Save & Exit Settings

    4.7 Save & Exit Settings BIOS Setting Description Save Changes and Reset Resets the system after saving the changes. Discard Changes and Resets system setup without saving any Reset changes. Restore Defaults Restores the user defaults to all the setup options. MPT-7000V User Manual...

  • Page 84: Appendix

    Appendix This section provides the mapping addresses of peripheral devices and the sample code of watchdog timer configuration. • I/O Port Address Map • Interrupt Request Lines (IRQ) • Watchdog Timer Configuration • Software Development Kit for WDT.DLL...

  • Page 85: I/O Port Address Map

    IRQ0 System Timer IRQ3 Serial Port #2 IRQ4 Serial Port #1 IRQ5 Serial Port #4 IRQ6 Serial Port #3 IRQ7 Serial Port #6 IRQ8 System CMOS/real time clock IRQ10 Serial Port #5 IRQ18 High Definition Audio Controller MPT-7000V User Manual...

  • Page 86: Watchdog Timer Configuration

    Fintek 81866, program abort.\n"); return(1); }//if (SIO == 0) if (argc != 2) printf(" Parameter incorrect!!\n"); return (1); bTime = strtol (argv[1], endptr, 10); printf("System will reset after %d seconds\n", bTime); if (bTime) EnableWDT(bTime); } else DisableWDT(); } return 0; MPT-7000V User Manual...
  • Page 87 //--------------------------------------------------------------------------- void DisableWDT(void) unsigned char bBuf; Set_F81866_LD(0x07); //switch to logic device 7 bBuf = Get_F81866_Reg(0xFA); bBuf &= ~0x01; Set_F81866_Reg(0xFA, bBuf); //disable WDTO output bBuf = Get_F81866_Reg(0xF5); bBuf &= ~0x20; bBuf |= 0x40; Set_F81866_Reg(0xF5, bBuf); //disable WDT //--------------------------------------------------------------------------- MPT-7000V User Manual...
  • Page 88 Init_Finish; } F81866_BASE = 0x00; result = F81866_BASE; Init_Finish: return (result); //--------------------------------------------------------------------------- void Unlock_F81866 (void) outportb(F81866_INDEX_PORT, F81866_UNLOCK); outportb(F81866_INDEX_PORT, F81866_UNLOCK); //--------------------------------------------------------------------------- void Lock_F81866 (void) outportb(F81866_INDEX_PORT, F81866_LOCK); //--------------------------------------------------------------------------- void Set_F81866_LD( unsigned char LD) Unlock_F81866(); outportb(F81866_INDEX_PORT, F81866_REG_LD); outportb(F81866_DATA_PORT, LD); Lock_F81866(); MPT-7000V User Manual...
  • Page 89 //--------------------------------------------------------------------------- #defineF81866_INDEX_PORT (F81866_BASE) #defineF81866_DATA_PORT (F81866_BASE+1) //--------------------------------------------------------------------------- #defineF81866_REG_LD 0x07 //--------------------------------------------------------------------------- #define F81866_UNLOCK 0x87 #defineF81866_LOCK 0xAA //--------------------------------------------------------------------------- unsigned int Init_F81866(void); void Set_F81866_LD( unsigned char); void Set_F81866_Reg( unsigned char, unsigned char); unsigned char Get_F81866_Reg( unsigned char); //--------------------------------------------------------------------------- #endif // F81866_H MPT-7000V User Manual...

  • Page 90: Software Development Kit For Wdt.dll

    Installation ⚫ For 32-bit environment: Step 1: Copy the file KMUI32_1K.SYS to <%WINDIR%>\SYSTEM32\DRIVERS. Step 2: The following parameters must be written to your registry. HKLM,"System\CurrentControlSet\Services\KMUI32_1K","ErrorCo ntrol",%REG_DWORD%,0x00000001 HKLM,"System\CurrentControlSet\Services\ KMUI32_1K","Type",%REG_DWORD%,0x00000001 HKLM,"System\CurrentControlSet\Services\ KMUI32_1K","Start",%REG_DWORD%,0x00000000 HKLM,"System\CurrentControlSet\Services\ KMUI32_1K","DisplayName",%REG_SZ%,"KMUI32_1K" Step 3: Restart the system. MPT-7000V User Manual...
  • Page 91 The following parameters must be written to your registry. HKLM,"System\CurrentControlSet\Services\KMUI64_1K","ErrorCo ntrol",%REG_DWORD%,0x00000001 HKLM,"System\CurrentControlSet\Services\ KMUI64_1K","Type",%REG_DWORD%,0x00000001 HKLM,"System\CurrentControlSet\Services\ KMUI64_1K","Start",%REG_DWORD%,0x00000000 HKLM,"System\CurrentControlSet\Services\ KMUI64_1K","DisplayName",%REG_SZ%,"KMUI64_1K" Step 3: Restart the system. Note: Do not install both of the 32-bit and 64-bit drivers on an operating system. MPT-7000V User Manual...
  • Page 92 Output : Always return 1. Note: This function should be invoked before the program closes and it will release the device driver and memory for ib_wdt.dll. If the program is closed without calling this routine, resource leak may occur. MPT-7000V User Manual...
  • Page 93 Output : Always return “0” For further information, refer to the datasheet for WDT or contact your sales representative. extern "C" __declspec(dllexport) int __stdcall DisableWDT(int); Input : Dummy data and will be ignored. Output : Always return “0” MPT-7000V User Manual...
  • Page 94 GPIO_6 are the output functions. Output : Dummy data and should be ignored. extern "C" __declspec(dllexport) int __stdcall SetDioOutputMask(int); Input : Hardware parameter for digital I/O output function call For further information, refer to the following explanation of “SetDioInputMask” routine. MPT-7000V User Manual...
  • Page 95 Set GPIO_5 to GPIO_6 to HIGH\n"); Sleep(500); if (_kbhit()) break; }//if (kbhit()) }//while(1) }//if ((*lpIsDioAvailable)(0)) Note: Be sure to set up the input / output for GPIO bits in BIOS identically with the GPIO hardware information above. MPT-7000V User Manual...

  • Page 96: Motherboard Mcu Isp Specifications

    THL max setting value, MCU trigger THL delay timer. ⚫ Setting THL Low Temperature MCU provides command to set low temperature protection, when system temperature is lower than THL low setting value, MCU trigger THL delay timer. MPT-7000V User Manual...
  • Page 97 MCU provides command to set temperature offset. It can adjust temperature disparity between system and power board. ⚫ Setting CB Voltage Offset MCU provides command to set car battery voltage offset. It can adjust this voltage disparity between actual measurement and detected form MCU. MPT-7000V User Manual...
  • Page 98 Note: Before using the ISP, your software engineer has to make sure the firmware version (GET_FORMWARE_VERSION) MUST be as follows to make the ISP function workable. Major version is 0. Minor version is 0. Build version is 5 (or above). MPT-7000V User Manual...
  • Page 99 Protocol uses 16-bit CCITT CRC to verify data integrity. P(x) = X unsigned calc_crc(unsigned char *data, unsigned unsigned start) { unsigned I, k, q, c, crcval; crcval=start; (I=0; I<n; I++) { c=data(I) & 0xFF; q=(crcval^c) & 0x0F; crcval=(crcval>>4)^(q*0x1081); q=(crcval^(c>>4)) & 0x0F; crcval=(crcval>>4)^(q*0x1081); return crcval; MPT-7000V User Manual...
  • Page 100 Reply: Header Size Command Data 0xFF Size of GET_FIRMWARE_VERSION 0xEE Version Version structure Structure BSL Version Structure Field Type Description Major Version Byte Major version number Minor Version Byte Minor version number Build Byte Build version number MPT-7000V User Manual...
  • Page 101 Data1 0xFF 0x02 SET_POWER_OFF_DELAY_TIME 0xEE (mins) (secs) Reply Header Size Command Data 0xFF 0x00 SET_POWER_OFF_DELAY_TIMER None 0xEE ⚫ Getting Status Get the power-on-delay timer and power-off-delay timer. Request: Header Size Command Data 0xFF 0x00 GET_STATUS None 0xEE MPT-7000V User Manual...
  • Page 102 Reply: Header Size Command Data 0xFF 0x04 GET_STATUS Status 0xEE structure BSL Version Structure Field Type Description Power on delay timer Word Byte4+ Byte5 Power off delay timer Word Byte6+ Byte7 MPT-7000V User Manual...
