Subject to change without prior notice
R. Stahl Tranberg AS
E
info@stahl-tranberg.com
Main office: Strandsvingen 6
Office Oslo: Luhrtoppen 2
TYPE 1058-5 EASY ACCESS
HT & EIT JB, PIPE & WALL MOUNTED
ZONE 1, ZONE 2 & SAFE AREA
TUM3194 REV. F 17.07.2017
|
stahl-tranberg.com
|
N-4032 Stavanger
|
Norway
|
N-1470 Lørenskog
|
Norway
JUNCTION BOX
IMPORTANT
Read this instruction carefully before installing the
product
| T
+47 51 57 89 00
| F
+47 51 57 89 50
| T
+47 24 08 44 10
USER MANUAL
Advertisement
Table of Contents
Related Manuals for Tranberg 1058-5
Summary of Contents for Tranberg 1058-5
- Page 1 JUNCTION BOX TYPE 1058-5 EASY ACCESS HT & EIT JB, PIPE & WALL MOUNTED ZONE 1, ZONE 2 & SAFE AREA USER MANUAL Subject to change without prior notice TUM3194 REV. F 17.07.2017 IMPORTANT Read this instruction carefully before installing the product R.
-
Page 2: Unpacking And Inspections
Renolit Unitemp 2 from Fuchs. for any transport damages and/or other defects. When opening the junction box, remove any foreign objects If repair or overhaul is necessary, only Tranberg spare parts that may have been inserted for transportation and/or must be used. - Page 3 TEF 1058 EASY ACCESS HEAT TRACE JUNCTION BOX FEATURES AND BENEFITS OF THE EASY ACCESS JUNCTION BOX 1. Easy accessiblity for termination. 4. Safety device. The terminal rail is equipped with ”keyholes” making it Standard holepattern for M25 cableglands, stopping plugs, possible to loosen and tilt this aside for better drainplug and pipebend.
-
Page 4: Installation
The junction box is equipped for termination of heat tracing and is ready for installation when leaving the production facili- ties of Tranberg AS. Changes made to the product which do not confirm to the approvals of this equipment, is a safety violation. - Page 5 TEF 1058-5 EASY ACCESS HEAT TRACE JUNCTION BOX INSTALLATION Assembly of pipe mounted type fig 03 Mount Junction Box either standing or hanging to pipe by pipe-strap. Remove dust protection or stopping plug and install re- quired glands. If required, drain should be inserted at Drainplug the lowest point.
- Page 6 TEF 1058-5 EASY ACCESS HEAT TRACE JUNCTION BOX DIMENSIONS SIZE 50 Easy Access JB Size 50 Easy Access JB Size 50 Heat Trace, Wall Mounted Electro-Instrument-Telecom 100A106166 100A105746 Easy Access JB Size 50 Heat Trace, Pipe Mounted 100A108925...
- Page 7 TEF 1058-5 EASY ACCESS HEAT TRACE JUNCTION BOX DIMENSIONS SIZE 55 Easy Access JB Size 55 Easy Access JB Size 55 Electro-Instrument-Telecom Heat Trace, Wall Mounted 100A105745 100A106167 Easy Access JB Size 55 Heat Trace, Pipe Mounted 100A108926...
-
Page 8: Technical Data
TEF 1058-5 EASY ACCESS HEAT TRACE JUNCTION BOX TECHNICAL DATA Terminal / Junction box basis certificates as component (empty enclosure without components): ATEX Approval Explosion category: II 2 G Ex e IIC Gb T6 Operating Temp.: -20°C to +60°C; EPDM gasket (1058, 1059 and 1060) II 2 G Ex e IIC Gb T6 Operating Temp.: -50°C to +100°C ;...
