SAFETY INSTRUCTIONS
Read these instructions – All the safety and operating instructions should be read before this product is operated.
1.
Keep these instructions – The safety and operating instructions should be retained for future reference.
2.
Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to.
3.
Follow all instructions – All operating and use instructions should be followed.
4.
5.
Keep the radio away from heat sources such as radiators, heaters or other appliances that produce heat.
6.
Do not expose the unit to direct sunlight.
7.
Do not use the radio near water.
8.
Avoid objects or liquids getting into the radio.
9.
Do not remove screws from or open the radio casing.
10. Should not be immersed in water, used in shower or bathroom if plugged into the mains.
11. WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. The apparatus shall not be exposed
to dripping or splashing and objects filled with liquids, such as vases, shall not be placed on apparatus.
12. WARNING: The optional USB adapter is used as disconnect device, the disconnect device shall remain readily operable.
13. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
14. WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as sunshine, fire or the alike.
1
Operation Manual
Model No.: DB-15
REV. 00
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tiny Audio DB-15
Summary of Contents for Tiny Audio DB-15
- Page 1 Operation Manual Model No.: DB-15 SAFETY INSTRUCTIONS Read these instructions – All the safety and operating instructions should be read before this product is operated. Keep these instructions – The safety and operating instructions should be retained for future reference.
- Page 2 INTRODUCTION OF OPERATION BUTTONS: 1. Standby: Long press to turn on or off. 2. DAB/FM: Switch mode between DAB & FM. 3. Info: Short press to check DAB/FM information. 4. Enter/Menu: Short press to go to Menu to set Radio/AUDIO/TIME, and check the version of software. ...
- Page 3 1. Install 4xAA batteries or connect the unit to USB cable/adapter, long press POWER button to turn on, LCD display will light up to show “Welcome to Tiny Audio Digital radio” to go to Standby mode, “Time is not set” and setting of time will be displayed.
- Page 4 2. Short press Menu/Enter to go to Menu, press it again to display DAB frequency. 3. Short press TUN+/TUN- to adjust frequency between 5A to 13F, then press Menu/Enter to confirm. Screen will display signal strength where DAB is available, press Menu/Enter to store and play the searched stations. The unit will return from Manual tune automatically.
- Page 5 4. Start the pairing process on your mobile device. Do this by selecting ‘Tiny Audio’ from the list of available devices that appear on the mobile device’s screen. This will connect automatically once paired.
- Page 6 Under Bluetooth mode, short press INFO to display Time/Date Menu function Under DAB mode, short press Menu/Enter to into Menu, press TUNE+/TUNE- to choose from Full san Manual Tune DRS Prune System. Full scan: short press Menu/Enter to start full range search. Manual tune: short press Menu/Enter to start full range search.
- Page 7 DD-MM-YYYY Back Light 1. Go to choose Back Light menu 2. Set back light time-out duration and Brightness level 10 sec; 20 sec; 30 sec; 45 sec; 60 sec; 90 sec; 120 sec; 180 sec; ON Dim level: High; Medium; Low Language Setting 1.
- Page 8 2. Keep the unit far away from interference resources such as: computer, microwave oven or others. 3. Under FM mode, you can switch from stereo to mono for better signal quality. Battery and USB adaptor 1. The unit is powered by 4xAAA dry batteries, but it cant recharge the batteries. 2.
