- Page 1 USER MANUAL AF-KIT AUTO SOLDER FEEDER KIT www.thermaltronics.com...
-
Page 3: Table Of Contents
FUNCTION PANEL / BACK PANEL ............. 3 WIRE ADJUSTMENT ASSEMBLY, GUIDE PIPE ASSEMBLY ..... 4 UNPACKING/ASSEMBLY/OPERATION ........... 5-9 ORDERING GUIDE ..................11 WARRANTY All equipment and accessories are warranted by Thermaltronics to be free from defects in materials and workmanship as follows: Part Number Description Warranty Period... -
Page 4: Af-Kit Specifications
50/60 Hz Certification Marks: INTRODUCTION Congratulations on your purchase of the AF-KIT auto feeder kit. This unit has been tested and inspected by Thermaltronics prior to shipment, and with proper maintenance will give you years of reliable performance. SYSTEM FEATURES... -
Page 5: Safety Precautions
12. Do not apply excessive force when installing and removing nozzles. 13. Do not use pliers to pull the edges of the nozzle. 14. Do not use the units for any purpose other than soldering or rework. Incorrect use may cause fire. www.thermaltronics.com support email: support@thermaltronics.com... -
Page 6: Function Panel / Back Panel
(2b) Switch (2b) Switch Connection Port - Connect the AF-PEDAL-1 Auto Feeder Switch to this port. Connection Port (2c) AC Power Adapter Inlet - Connect the AF-POWER-1 AC Power Adapter to this inlet. (2c) AC Power Adapter Inlet AF-KIT User Manual... -
Page 7: Wire Adjustment Assembly, Guide Pipe Assembly
(4c) Guide Clip - Used to secure the Guide Pipe Assembly to the Soldering Hand Piece. (4d) Guide Pipe - Feeds solder wire to the soldering tip. (4e) Nozzle - Change the nozzle when using different solder wire diameters. (4d) Guide Pipe (4c) Guide Clip www.thermaltronics.com support email: support@thermaltronics.com... -
Page 8: Unpacking/Assembly/Operation
(3g) Locking Screw ● S (1) Insert Solder Tube (2) Lock Solder Tube 6. Ensure the correct (4e) Nozzle is attached to the (4d) Guide Pipe. (See: Operation - Changing the Nozzle) AF-KIT User Manual... - Page 9 Hand Piece Top Hand Piece Guide Clip AF-KIT-3 - Attach the (4c) Guide Clip to the soldering hand piece. Use a flat-blade screw driver ● to secure the (4C) Guide Clip to the soldering hand piece. (1) Push the Guide Clip onto the hand piece (2) Use a flat-blade screw driver to tighten the three screws on the Guide Clip.
- Page 10 Φ 0.5mm Nozzle Φ0.5-0.6mm Φ 0.6mm Nozzle Φ0.5-0.6mm Φ 0.8mm Nozzle Φ0.8mm Φ 1.0mm Nozzle Φ1.0mm Φ 1.2mm Nozzle Φ1.2mm For solder wire diameters not mentioned above please contact Thermaltronics or your supplier to check for compatibility. AF-KIT User Manual...
- Page 11 ● Continuous Mode - Pushing the switch down will set the feeder to Continuous mode. In Continuous Mode, solder will be fed continuously at the set speed as long Tension Adjustment Knob as the (2) Auto Feeder Switch is activated. Mode Selection www.thermaltronics.com support email: support@thermaltronics.com...
- Page 12 (3) Maximum Length 99 = longest (13.86mm) Note: To prevent solder wire from clogging inside the (5) Guide Pipe Assembly and (3) Wire Adjustment Assembly, never set the Return length to be higher than the Forward Length. AF-KIT User Manual...
-
Page 13: Ordering Guide
ORDERING GUIDE AF-KIT-1 for use with TMT-9000S PART# DESCRIPTION AF-KIT-1 Auto Solder Feeder Kit for TMT-9000S AF-KIT-1M Auto Solder Feeder Kit w/SHP-1 Soldering Handle for TMT-9000S TMT-AF100 Auto Solder Feeder (Control Unit Only) AF-HPK-1 Guide Pipe Assembly for TMT-9000S AF-HDL-1... - Page 16 Support Email: support@thermaltronics.com www.thermaltronics.com...
