Sepura SRM3500 Installation

Vehicle Installation Ordering Guide
The diagram below shows a typical Vehicle Installation, for a full list of accessories please refer to your Sepura sales contact
6. Loudspeaker
High Power Loudspeaker, 1m
300-00088
Low Profile Loudspeaker, 1m
300-00064
2. Console
300-00149
(note: each console can support two accessories)
Hands Free Kit (console)
300-00079
Sepura plc
Radio House, St Andrew's Road, Cambridge CB4 1GR, UK
7. Antenna
Power Lead Assembly, 5m
300-00066
4. Remote Control Cable
0.5m - 10m
5. Audio Accessory
Fist Mic Handset
(PTT and hook switch)
300-00062
300-00061
1. SRM3500 or SRG3500
GPS Antenna, Mag Mount, incl. cable
300-00063
(note: only needed if transceiver has GPS)
3. Console Mounting
Console Rear Panel Fixing Kit
300-00080
Console DIN Mount Kit
300-00081
(note: needs 300-00080)
Console Dash Mount Kit (Pivot)
300-00084
Transceiver Plate Mount Kit
300-00086
