- Page 1 OWNER’S MANUAL Assembly & Operating Instructions BBT PUSH MOWER MODEL NO. BBT-65PM...
-
Page 2: To The Owner
Please do NOT return the Push Mower without first contacting the Customer Support Department at bbt@bbta.com.au. If you have difficulty assembling this product or have any questions regarding the controls, operation, or maintenance of this Push Mower, please contact our Customer Support Department. SAVE THESE INSTRUCTIONS WWW.BBTA.COM.AU BBT-65PM... -
Page 3: Table Of Contents
OPERATIONS ............................10 Engine Starting ..............................10 Regulation of the Drive Cable (b) ........................10 MAINTENANCE CARE ...........................11 Maintenance and Storage ...........................11 Blade ..................................11 SPECIFICATIONS ............................12 WARRANTY & SERVICE ........................13 EXPLODED DIAGRAM & PARTS LIST....................14-15 YOU MAY ALSO LIKE ...........................16 BBT-65PM WWW.BBTA.COM.AU... -
Page 4: Important Safety Information
Equipment described within this manual may be optional. Some illustrations may not be applicable to your machine. WARNING! Your Responsibility—Restrict the use of this power machine to persons who have read, understood and will follow the warnings and instructions in this manual and on the machine. SAVE THESE INSTRUCTIONS! WWW.BBTA.COM.AU BBT-65PM... -
Page 5: Key To Symbols
Remove the spark plug before carrying out repairs. CAUTION! Tool surfaces can be hot. DO NOT use in the rain. Blades continue to rotate after the engine stops. Rotating blades are capable of amputating hands and feet and throwing objects. BBT-65PM WWW.BBTA.COM.AU... -
Page 6: General Safety Rules
Work only when there is sufficient light. • DO NOT use your BBT Push mower when it is raining or when the grass is wet. • Particular precautions must be taken while mowing on slopes or downing stretches. Mow across the face of slopes, NEVER down or up. -
Page 7: Spark Plug Safety Rules
DO NOT start the engine if there is spilt petrol, wipe it off the engine and equipment, and move the mower to another area, wait 5 minutes before starting the engine. • Close tightly the fuel tank cap. BBT-65PM WWW.BBTA.COM.AU... -
Page 8: Parts Location
4. Throttle control 12. Nut knobs Not all of the accessories illustrated or described are 5. Engine 13. Height adjustment lever included as standard delivery. 6. Carter 14. Wheels Grass catcher 15. Side cover* 8. Propeller bar 16. Discharge open* WWW.BBTA.COM.AU BBT-65PM... -
Page 9: Assembling
Central height adjustment: • Set the desired height by pulling and turning the height adjustment lever (13). Side Discharge Option: Pull upwards the side cover (15), attach the discharge open (16) onto the deck and release the side cover (15). BBT-65PM WWW.BBTA.COM.AU... -
Page 10: Operations
Before you begin to mow, make sure the drive system will correctly disengage and that the mower will stop. If the drive system will not disengage, take the lawn mower to an authorized service centre before you operate it. • ATTENTION: Make sure that all cables are tense enough. WWW.BBTA.COM.AU BBT-65PM... -
Page 11: Maintenance Care
To sharpen the blade, place it in a vice and file the cutting edge evenly, checking its balance. • When reassembling the blade, make sure that the cutting edges face in the direction of the engine’s rotation. The blade screw must be torque to • 3.7Kg*m/s2(37Nm) with a dynamometric tool. BBT-65PM WWW.BBTA.COM.AU... -
Page 12: Specifications
SPECIFICATIONS Model BBT-65PM Rated power 3800 W Displacement 190 cc Rated speed 2750 RPM Max torque 8 Nm Cutting height range 20 - 55 mm Number of cutting height adjustments Cutting width 21 inches Cutting height adjustment Central height adjust... -
Page 13: Warranty & Service
Parts purchases, consumable components and accessories such as chains, carry bags, batteries, hoses, grinding discs, covers, belts, cable, wheels and blades are not covered by standard warranty. Spare Parts Spare parts are available. Please see our website (www.bbta.com.au) or contact us at bbt@bbta.com.au for more details. BBT-65PM... -
Page 14: Exploded Diagram & Parts List
EXPLODED DIAGRAM & PARTS LIST WWW.BBTA.COM.AU BBT-65PM... - Page 15 Hexagon flange bolts SP-65PM-068 Cover SP-65PM-032 Adjustment handle assy. SP-65PM-069 Top cover of grass bag SP-65PM-033 10.5" Wheel(R) SP-65PM-070 Half plastic box SP-65PM-034 7.5" Wheel(R) SP-65PM-071 Collection bag frame SP-65PM-035 Hexagon flange bolts SP-65PM-036 Bracket of front wheel axle BBT-65PM WWW.BBTA.COM.AU...
-
Page 16: You May Also Like
YOU MAY ALSO LIKE Chainsaws Cultivators / Tillers Log Splitters Mulcher COPYRIGHT © BIGGER BOYZ TOYZ AUSTRALIA PTY.LTD Unit 2/3 Delta Place Albion Park Rail NSW 2527 BBT-65PM-MNL1807...
