AMPLIFIER INTERFACE
CHRY-AMP-03
INSTALLATION INSTRUCTIONS
The CHRY-AMP-03 is designed to allow the user to add a 2
channel or monoblock amplifier to the Chrysler/Dodge/Jeep
vehicles listed below that are equipped with the digital amplified
sound system. These vehicles have a 2 channel fixed output at
the radio which traditional line level convertors cannot use. The
CHRY-AMP-03 will provide a non-fading output and provide a 12
volt turn on for the aftermarket amplifier.
* READ IMPORTANT WARNING ON PAGE 1
BEFORE ATTEMPTING ANY INSTALLATION
CHRYSLER
300/ 300C
Aspen
Sebring
Town & Country 2008-10
DODGE
Avenger
Caliber
Challenger
Charger
Dakota
Durango
Grand Caravan 2008-10
Magnum
Nitro
Ram 1500
• CHRY-AMP-03
• OEM Radio to CHRY-AMP-03 "T" Harness
INSTCHRY-AMP-03
1-800-221-0932
©Copyright 2010 Metra Electronics Corporation
CHRYSLER
APPLICATIONS
JEEP
2008-10
Commander
2008-09
Grand Cherokee 2008-10
2008-10
2007-10
Liberty
2008-09
Patriot
2009
Wrangler
2007-10
MITSUBISHI
2008-10
2009
Raider
2008
2009-10
2008-10
2008-09
2008-10
2008
2007-10
2009
INTERFACE COMPONENTS
www.metraonline.com
Advertisement
Summary of Contents for Metra Electronics CHRY-AMP-03
- Page 1 INSTALLATION INSTRUCTIONS MUST BE CAREFULLY FOLLOWED. THE INSTRUCTIONS ARE WORDED The CHRY-AMP-03 is designed to allow the user to add a 2 IN SUCH A MANNER TO ASSUME THAT THE INSTALLER IS CAPABLE channel or monoblock amplifier to the Chrysler/Dodge/Jeep OF COMPLETING THESE TYPE OF ELECTRONIC INSTALLATIONS.
-
Page 2: Level Adjustment
If after setting the amplifier gain properly the output is still too low or high, you can increase/decrease the level at the CHRY-AMP-03. Locate the potentiometer on the CHRY-AMP-03 which is next to the 10 way Molex plug. Turn the radio on and use a small Phillips or Flathead screwdriver turn the potentiometer up or down to adjust the level up or down.
